GE Security Digia Installation Manual page 28

24 Digia
Installation Manual
Various indicators showing the status of the DVR are shown as
OSD symbols. Refer to Table 12 for the meanings of the
indicators.
Table 12. OSD symbols
Symbol
Table 13. Buttons in live video mode
Button
SETUP
Meaning
Continuous recording in progress.
Manual recording in progress.
Sensor alarm recording in progress.
Motion alarm recording in progress.
Alarm indicator. When there is an alarm in the
video channel, this icon is bright red.
Indicates that an alarm output is activated.
Indicates that a network client is connected to the
DVR.
Indicates that the sequencing mode has been
enabled.
Description
Launch the setup menu.
