- Page 1 KOBE Brand Range Hood Model No. CHX20 INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE....................3 INSTALLATION .......................... 4 OPERATING INSTRUCTIONS....................8 MAINTENANCE ......................... 9 SPECIFICATIONS ........................10 MEASUREMENTS & DIAGRAMS .....................11 PARTS LIST ..........................12 TROUBLE SHOOTING ......................15 DISCLAIMER ..........................16 WARRANTY ..........................17 PRODUCT REGISTRATION .....................19 - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -... -
Page 3: Important Safety Instructions
KOBE RANGE HOODS authorized agents. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 4 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
{E} 3-1/4” x 10” Exhaust Plate {F} 3-1/4” x 10” Vent Cover {G} Top Vent Cover {H} Oil Containers (Rectangular) {I} Oil Containers (Round) FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE www.KOBERangeHoods.com CONTACT KOBE RANGE HOODS AT (626) 775-8880. -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches.) - FOR UNDER THE CABINET - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36") C = Preferred Height of Counter Top to Hood Bottom (Recommended... - Page 7 Preparation before Installation Figure 1 NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. A straight, short venting run will allow the hood to perform more efficiently.
- Page 8 Figure 5 Hood Installation CAUTION: If required to move the cooking range to install the hood, turn off the power on an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE. 5. Unscrew the three screws on the bottom casing. Remove the bottom casing if necessary;...
- Page 9 Install Accessories 11. Place the oil container (round) into keyhole under each safety screen. Turn clock-wise until firmly in place. 12. Slide oil container (oval) into plastic slot behind each safety screen. Final Installation 13. Turn power ON in control panel. Check all lights and fan operation.
-
Page 10: Operating Instructions
OPERATING INSTRUCTIONS To operate the fan function • Press button to choose from speed. = Low speed = Medium speed = High speed • Press “OFF/ON” to turn fan off. To operate the light function • Press the Light Control to turn lights on and off. -
Page 11: Maintenance
MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. Cleaning Hood Surface CAUTION NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. DO NOT USE PAPER TOWEL ON STAINLESS STEEL. For optimal operation, clean range hood and all baffle/spacer/filter/oil tunnel/oil container regularly. *** Regular care will help preserve the appearance of the hood. -
Page 12: Specifications
SPECIFICATIONS Series CHX20 Series COLOR Commercial Grade Stainless Steel VOLTAGE 120V 60Hz NUMBER OF MOTORS DESIGN Seamless / Satin Finish FAN TYPE Twin Turbine Impeller EXHAUST Top – 6" Round 3-1/4" x 10" Rectangular Rear – 3-1/4" x 10" Rectangular... -
Page 13: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***All inch measurements are converted from millimeters. Inch measurements are estimated. ***All measurements in ( ) are millimeters. -
Page 14: Parts List
PARTS LIST MODEL NO.: CHX2030PVS-OL CHX2036PVS-OL DESCRIPTION MODEL /SIZE PART NO. Hood Casing CH-20-01-0001 Transformer Support CH-20-01-0002 Transformer Bracket CH-20-01-0003 Capacitor CH-20-01-0004 Light Transformer CH-20-01-0005 Light Support CH-20-01-0006 LED Light CH-20-01-0007 Bottom Casing CH-20-01-0008 Impeller Plastic Cup CH-20-01-0009 Safety Screen CH-20-01-0010 Round Oil Container CH-20-01-0011... - Page 15 MODEL NO.: CHX2030PVS-OL CHX2036PVS-OL...
-
Page 16: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: CHX2030PVS-OL CHX2036PVS-OL... -
Page 17: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution After Installation, The power is not on. Make sure the circuit breaker and the unit’s power is both motors and ON. Use a voltage meter to check the power supply. lights are not The wire connection is not secure. Check and tighten wire connection. -
Page 18: Disclaimer
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. -
Page 19: Warranty
Any covered failure occurring within one year of original purchase arising from defective workmanship or material in manufacture will be at our discretion, replaced free of charge by KOBE Range Hoods as applicable. Keep proof of purchase (or original invoice) handy for inspection. - Page 20 Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. SERVICE For service contact: KOBE Range Hoods 11775 Clark Street Arcadia, CA 91006 U.S.A.
-
Page 21: Product Registration
This appliance has been manufactured, tested, and inspected to the standards required by KOBE Range Hoods. PLEASE MAIL IN YOUR WARRANTY REGISTRATION CARD AND PROOF OF PURCHASE TO: KOBE Range Hoods Warranty Registration 11775 Clark Street Arcadia, CA 91006 U.S.A. - Page 22 KOBE Range Hoods 11775 Clark Street Arcadia, CA 91006 USA http://www.KOBERangeHoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country.
