To switch your Pedelec off, press the diamond button on
the control panel for around two seconds whilst in the
start menu. This will take you to the sub-menu.
Navigate to the item "Shutdown" using the arrow buttons
and confirm using the diamond button.
Back
Shutdown Shutdown

5.1.2 Buttons for power-assist level

• You can specify the power-assist level using the
arrow buttons.
• Each time you press an arrow button, the power
assist changes by one level.
• If you press the upper arrow button, the level of
assistance increases by one level each time you
press it.
• If you press the lower arrow button, the assistance
becomes weaker each time you press it.
5.2

Display

2
4
1 Speed
2 Power-assist mode/energy recovery
3 Battery charge state
4 Remaining range
5 Variably adjustable display
14 VIII User Manual Pedelec Xion
The display in the middle of the handlebar is divided into
five different display panels.
1
3
5
• At the top on the right is your current
• On the left is a display showing the
assist mode you have selected or the level of
energy recovery.
• In the middle on the right hand-side is the
battery symbol, which tells you the current charge
status of your Pedelec's battery.
• The remaining range is displayed to the right
4
of the display for the
• Below this you will see
for example. In place of these, the following data
can also be called up:
Distance covered during the day (in km).
•
The journey time taken to cover this distance.
•
The average speed (in km/h).
•
The maximum speed reached
•
(in km).
The total mileage (in km).
•
The total journey time taken to cover this
•
distance.
The average speed based on this data
•
(in km/h).
Your personal contribution as the rider (in Wh).
•
The power consumption.
•
1
speed.
2
power-
3
power-assist mode.
2
5
the date or the time,
