Functional Description............... 4 Installation..................4 Power Source..................5 Power Connection................5 Input / Output Connections ............... 5 MRT-860 Status LED Indicators............6 MRR-860 Status LED Indicators ............7 Warranty ................... 8 Service Information ................8 This unit complies with 21 CFR...
Page 4
THE INSTALLATION OF THESE UNITS SHOULD BE MADE BY A QUALIFIED SERVICE PERSON(S) AND MUST CONFORM TO ALL LOCAL CODES. To install the MRT-860 or MRR-860 it is first necessary to mount the rack flanges to the unit. For rack mounting the ears are installed on the...
Page 5
For mounting the unit flush to a wall or other rigid surface, the ears may be installed on the sides with the oval holes flush with the bottom of the unit as in Figure 2. Mount the ears with the #10 flathead screws provided.
Page 6
MRT-860 STATUS INDICATORS The MRT-860 transmitter provides the following front panel LED status indicators to aid in installation and troubleshooting: VIDEO A bi-color LED indicator is provided for each of the six video channel inputs. AC power and video status associated with each of these LEDs are summarized below.
Page 7
A bi-color LED indicator monitors the power of the optical input signal that is being received at the MRR-860 from video channels one through four of the MRT-860. AC power and optical input status associated with this LED are summarized below.
Page 8
LIFETIME WARRANTY INFORMATION American Fibertek, Inc warrants that at the time of delivery the products delivered will be free of defects in materials and workmanship. Defective products will be repaired or replaced at the exclusive option of American Fibertek. A Return Material Authorization (RMA) number is required to send the products back in case of return.
