Page 3
Functional Description ................ 4 Installation ..................4 Power Source ..................5 Power Connection ................5 Input / Output Connections..............5 MRT-880 Status LED Indicators............6 MRR-880 Status LED Indicators ............7 Warranty..................... 8 Service Information ................8...
THE INSTALLATION OF THESE UNITS SHOULD BE MADE BY A QUALIFIED SERVICE PERSON(S) AND MUST CONFORM TO ALL LOCAL CODES. To install the MRT-880 or MRR-880 it is first necessary to mount the rack flanges to the unit. For rack mounting the ears are installed on the...
For mounting the unit flush to a wall or other rigid surface, the ears may be installed on the sides with the oval holes flush with the bottom of the unit as in Figure 2. Mount the ears with the #10 flathead screws provided.
Page 6
MRT-880 STATUS INDICATORS The MRT-880 transmitter provides the following front panel LED status indicators to aid in installation and troubleshooting: VIDEO A bi-color LED indicator is provided for each of the eight video channel inputs. AC power and video status associated with each of these LEDs are summarized below.
OLI 1 A bi-color LED indicator monitors the optical input signal that is being sent to the MRR- 880 from video channels one through four of the MRT-880. AC power and optical input status associated with this LED are summarized below.
replaced at the exclusive option of American Fibertek. A Return Material Authorization (RMA) number is required to send the products back in case of return. All returns must be shipped prepaid. This warranty is void if the products have been tampered with. This warranty shall be construed in accordance with New Jersey law and the courts of New Jersey shall have exclusive jurisdiction over this contract.
