- Page 1 Manufacturer's Warranty SAFETY AND OPERATING MANUAL Original Instructions POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 2 Congratulations on your purchase of a TITAN product from Titan Power Tool ® (UK) Ltd. We want you to continue getting the best performance from it so this handbook includes information on safety, handling and care. Please retain this handbook in case you need to refer to any of the information in the future.
-
Page 3: Safety Instructions
There is an increased risk of electric shock if your body is earthed or grounded. 3.Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. POLE HEDGE TRIMMER 400W TTB427GTM... - Page 4 2. Do not use the garden power tool if the switch does not turn it on and off. Any garden power tool that cannot be controlled with the switch is dangerous and must be repaired. 3. Disconnect the plug from the power source and/or the battery pack from the POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 5 5.Check the hedge for foreign objects before operation, e.g. wire fences. 6.Hold the product properly, e.g. with both hands if two handles are provided. Loss of control can cause personal injury. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 6 4. While operating the product, always ensure that the operating position is safe and secure. Do not use this product on steps or a ladder. 5. Do not operate the product with a damaged or excessively worn cutting device. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 7 Further Advice can be found at www.hse.gov.uk POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 8 Fast intervention can prevent serious injury and damage to property. 2. Switch off and disconnect from the power supply if there is any malfunction. Have the product checked by a qualified specialist and repaired, if necessary, before you put it into operation again. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 9 Maintain this tool in accordance with these instructions and keep well lubricated (where appropriate). Avoid using tools in temperatures of 10°C or less. Plan your work schedule to spread any high vibration tool use across a number of days. Health Surveillance. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 10 Be sure the supply is the same as the voltage given on the rating plate. The tool is fitted with a two-core cable and plug. Remove the mains plug from socket before carrying out any adjustment or servicing. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 11 To avoid potential electric shock, do not use the unit in humid or wet Switch off! Remove plug from mains before cleaning or maintenance Switch off! Remove plug from the mains immediately if the cable is damaged or cut. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 12 10M from the power line. Waste electrical products should not be disposed of with household waste, please recycle where facilities exist. Check with your local authority or retailer for recycling advice. Guaranteed sound power level POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 13 10. Main handle 11. Power cord with plug 12. Cord strain relief 13. Rear safe guard 14. Bolt 15. Soft grip 16. Cooling air vents 17. Blade protection sheath 18. Locking pin 19. Lower shaft POLE HEDGE TRIMMER 400W TTB427GTM...
-
Page 14: Technical Data
(taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time). The sound intensity level for the operator may exceed 85dB(A) and ear protection measures are necessary. ACCESSORIES HARNESS HEX KEY POLE HEDGE TRIMMER 400W TTB427GTM... - Page 15 Always use glove s during assembly. 1.INTENDED USE 1). This pole hedge trimmer TTB427GTM is designated with a rated power of 400Watts. This product is intended for cutting and trimming of high and wide hedges, bushes and shrubs in domestic gardens.
- Page 16 4. POWER CONNECTION WARNING! Before operating the pole hedge trimmer, ensure that the fastening elements are undamaged. In order to prevent risk, always switch off the motor and pull out the mains plug before starting this task. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 17 1). Unscrew the bolt (14) with a supplied hex key(See Fig.1a). 2). Push the shafts (3, 4) towards each other to shorten or pull away from each other to lengthen the shaft. 3). Tighten the bolts (14) once the desired length is adjusted. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 18 NOTE: It is not necessary to maintain pressure on the lock- off button once the switch trigger is squeezed and the motor is running. The lock-off button is a safety device to avoid Fig. 5a accidental start-up of the device. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 19 4). Cut both sides from the bottom cutting upwards to the top. This will prevent any of the cuttings falling into the path of the area still to be cut. (See Fig. 6a). Fig. 6b 5). After cutting the sides proceed to the top. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 20 (See Fig. 6d). A trapezoidal cut corresponds to the natural growth of plants and results in optimal hedge growth, as it will expose Fig. 6d more light to the bottom of the hedge. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 21 - If the cutting blade is worn or blunt it must be replaced immediately; - If the pole hedge trimmer starts to suffer from excessive vibrations, this means that the cutting blade has suffered deformation due to impacts. In this case it must be repaired or replaced. POLE HEDGE TRIMMER 400W TTB427GTM...
- Page 22 3). Always carry the product by its handle/gripping surface. 4). Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles. 5). Secure the product to prevent it from slipping or falling over. POLE HEDGE TRIMMER 400W TTB427GTM...
-
Page 23: Troubleshooting
Tighten bolts/nuts ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. For further information visit www.recycle-more.co.uk. POLE HEDGE TRIMMER 400W TTB427GTM... - Page 24 If the supply cord is damaged it must be replaced by a service agent or a similarly qualified person in order to avoid hazard. 5AMP fuse Blue to N(Neutral) Brown L(Live) Outer Cable grip sleeve POLE HEDGE TRIMMER 400W TTB427GTM...
-
Page 25: Declaration Of Conformity
EN61000-3-2:2006 + A1:2009 + A2:2009 EN61000-3-3:2008 Authorised signatory and technical file holder Date: 20/12/11 ISSUE DATE: REV3-MAR12 Signature: Name / title: Peter Harries / Quality Manager Titan Power Tools (UK)Ltd. Trade House, Mead Avenue, BA22 8RT POLE HEDGE TRIMMER 400W TTB427GTM...
