3. Locate the DC CHARGER and plug it into wall(the red light on the charger will turn on
showing you have power).
4. Locate the charging port on the side of the scooter and plug in the charger to the
scooter.
5. The charging status light will have a red and green light on at the same time
indicating that the charging process has started.
7. Once the light on the charger turns green you may remove charger from the side of
the scooter.
8. You are now ready to ride the XTR-COMP II.
Note: If the light turns green right away, this is because the unit was charged at the
factory. Please continue charging for 6-8 hours prior to initial use.
Multi-function LED
The XTR-COMP II comes equipped with a multi-function LED that can tell you the
status of your batteries while riding. When the scooter is powered on and it has a full
charge over 23V the LED light will be green. Once you begin to ride your scooter and
the voltage drops between 21.5V and 23V the LED will turn yellow to show you will
need to charge your scooter soon. Once the Voltage drops under 21.5V the LED will
turn red, this means it is time to charge your scooter. If the volts drop under 19V the
LED will blink red, It is necessary for you to stop riding your scooter and charge your
batteries immediately to avoid damage your batteries.
The LED also has other function to help you troubleshoot some problems. If you have
the throttle lever depressed and you try to turn on the scooter the LED will blink red.
This is to keep the scooter from running away when you are not ready. The red LED
will also stay solid if there is a problem with your PC board. If there is a problem in the
motor the LED will blink yellow. If the motor temperature reaches 221° F the scooter will
shut off and the LED light will blink green. If that happens let the motor cool before you
attempt to ride again.
