LevelOne
FCS-0010 10/100Mbps Network Camera /
WCS-0010 11g Network Camera
User's Manual
Ver. 1.2.0-0809
Copyright (c) 2007 Digital Data Communications Co., Ltd. All Rights Reserved
All the features and functions are subject to change without notice. Please visit
www.level1.com
for the
latest ones.
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCS-0010 and is the answer not in the manual?

Questions and answers

Related Manuals for LevelOne FCS-0010

Summary of Contents for LevelOne FCS-0010

  • Page 1 LevelOne FCS-0010 10/100Mbps Network Camera / WCS-0010 11g Network Camera User’s Manual Ver. 1.2.0-0809 Copyright (c) 2007 Digital Data Communications Co., Ltd. All Rights Reserved All the features and functions are subject to change without notice. Please visit www.level1.com for the...

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION....................1 Overview ..........................1 Physical Details ........................4 Package Contents ......................6 CHAPTER 2 BASIC SETUP ....................7 System Requirements......................7 Installation ......................... 8 Setup using the Windows Wizard ..................9 CHAPTER 3 VIEWING LIVE VIDEO .................. 12 Overview ..........................
  • Page 4 APPENDIX B STREAMING VIDEO/AUDIO SOLUTION ..........73 Overview .......................... 73 Streaming Video/Audio through Internet Camera............73...

  • Page 5: Chapter 1 Introduction

    Stream Live Video to Multiple Users. The MPEG4 encoder and HTTP server built into the camera generate a ready-to-view video stream. Just connect to FCS-0010/WCS-0010 using your Web browser or the provided Windows utility to view live video. • Suitable for Home, Business or Public Facilities .

  • Page 6: Internet Features

    DDNS Support. In order to view video over the Internet, users must know the Internet IP address of the gateway used by the FCS-0010/WCS-0010. But if the Gateway has a dynamic IP address, DDNS (Dynamic DNS) is required. Since many existing Gateways do not support DDNS, this function is incorporated into the FCS-0010/WCS-0010.

  • Page 7: Wireless Features

    Wireless Features • Standards Compliant. The WCS-0010 complies with the IEEE802.11g (DSSS) specifications for Wireless LANs. • Supports both 802.11b and 802.11g Standards. The WCS-0010 supports both 802.11b and 802.11g standards. • Speeds to 54Mbps. All speeds up to the 802.11g maximum of 54Mbps are supported.

  • Page 8: Physical Details

    Power Input Connect the supplied 5V power adapter here. Do not use other power adapters; doing so may damage the camera. LAN port Use a standard LAN cable to connect FCS-0010/WCS-0010 to a 10/100BaseT hub or switch. Note: • Attaching the LAN cable will disable the Wireless interface.
  • Page 9 address, Administrator ID, and Administrator Password settings will be set to their default values. • IP address: DHCP Client • Administrator ID: administrator • Administrator Password: null (no password) Note: !! Please aim the triangle to the reset button otherwise it may damage parts of camera. 2.

  • Page 10: Package Contents

    Package Contents The following items should be included: If any of these items are damaged or missing, please contact your dealer immediately. 1. FCS-0010/WCS-0010 2. Power adapter 3. Antenna (WCS-0010 Only) 4. Camera Stand 5. CD Manual/Utility 6. Quick Installation Guide...

  • Page 11: Chapter 2 Basic Setup

    Chapter 2 Basic Setup This Chapter provides details of installing and configuring the FCS- 0010/WCS-0010. System Requirements • To use the wired LAN interface, a standard 10/100BaseT hub or switch and network cable is required. • To use the Wireless interface on the Network Camera, other Wireless devices must be compliant with the IEEE802.11b or IEEE802.11g specifications.

  • Page 12: Installation

    For WCS-0010, screw the supplied antenna to the mounting point on the rear. Attach the Camera Mount to the camera. 2. Connect the LAN Cable Connect the FCS-0010/WCS-0010 to a 10/100BaseT hub or switch, using a standard LAN cable. For the WCS-0010 Network Camera, this disables the Wireless Interface, because only one interface can be active.

  • Page 13: Setup Using The Windows Wizard

    Setup using the Windows Wizard Initial setup should be performed using the supplied Windows-based setup Wizard. This program can locate the FCS-0010/WCS-0010 Network Camera even if its IP address is invalid for your network. You can then configure the FCS-0010/WCS-0010 Network Camera with appropriate TCP/IP settings for your LAN.
  • Page 14 4. You will be prompted to enter the Administrator Name and Administrator Password, as shown below. Enter “administrator” for the name, and leave the password blank. Otherwise, enter the Administrator Name and Administrator Password set on the Maintenance screen. 5. This screen allows you to enter a suitable Description, and set the correct Time Zone, Date, and Time.
  • Page 15 Fixed IP Address is recommended, and can always be used. Dynamic IP Address can only be used if your LAN has a DCHP Server. If you chose Fixed IP Address, the following TCP/IP Settings screen will be displayed. • Enter an unused IP Address from within the address range used on your LAN. •...

  • Page 16: Chapter 3 Viewing Live Video

    1. Use the Camera Wizard to get the IP address of the FCS-0010/WCS- 0010Network Camera. 2. Start Internet Explorer. 3. In the Address box, enter "HTTP://" and the IP Address of the FCS-0010/WCS- 0010 Network Camera. 4. When you connect, the following screen will be displayed.
  • Page 17 6. If the Administrator has restricted access to known users, you will then be prompted for a username and password. Enter the name and password assigned to you by the FCS-0010/WCS-0010 Network Camera administrator. 7. The first time you connect to the camera, you will be prompted to install an ActiveX component (OCX or CAB file), as in the example below.

  • Page 18: Connecting To A Camera Via The Internet

    Also, you need a broadband Internet connection to view video effectively. Dial-up connections are NOT supported. To establish a connection from your PC to the FCS-0010/WCS-0010 Network Camera via the Internet: 1. Obtain the following information from the Administrator of the camera you wish to connect to: •...
  • Page 19 4. When you connect, the following screen will be displayed. 5. Click View Video. 6. If the Administrator has restricted access to known users, you will then be prompted for a username and password. Enter the name and password assigned to you by the Network Camera administrator.

  • Page 20: Viewing Live Video

    Viewing Live Video After installing the ActiveX component, you will be able to view the live video stream in its own window, as shown below. There are a number of options available on this screen, accessed by select list, button or icon.

  • Page 21: Chapter 4 Advanced Viewing Setup

    If necessary, the Network Camera Administrator can adjust the Video image. To Adjust the Video Image: 1. Connect to the Web-based interface of the FCS-0010/WCS-0010 Network Camera. (See Chapter 5 - Web-based Management for details.) 2. Select Administration, then Video Image. You will see a screen like the example...
  • Page 22 3. Make the required adjustments, as explained below, and save your changes. MPEG-4 Settings Resolution Select the desired video resolution format. The default resolution is set to 320*240. • Constant Bit Rate: Select the desired bit rate. The default Video Quality is set to 1.2 Mbps.
  • Page 23 Max. Frame Rate Select the desired Maximum bandwidth for the video stream. Note that you can specify EITHER the Bandwidth OR the Frame Rate, not both. If the Bandwidth is defined, the frame rate will be adjusted as necessary to achieve the specified frame rate.

  • Page 24: Controlling User Access To The Video Stream

    Controlling User Access to the Video Stream By default, anyone can connect to the FCS-0010/WCS-0010 Network Camera and view live Video at any time. If desired, you can limit access to scheduled times, and also restrict access to known users.

  • Page 25: Making Video Available From The Internet

    This feature is normally called Port Forwarding or Virtual Servers, and is illustrated below. The Port Forwarding/Virtual Server entry tells the Router/Gateway that incoming TCP connections on port 1024 should be passed to the FCS-0010/WCS- 0010 Network Camera. If necessary, check the user manual for your Router/Gateway for further details.

  • Page 26: Network Camera Setup

    • You wish to change the port number from the default value (1024). • You wish to use the DDNS (Dynamic DNS) feature of the FCS-0010/WCS-0010 Network Camera. HTTP Port Configuration Normally, HTTP (Web) connections use port 80. Since the Network Camera uses HTTP, but port 80 is likely to be used by a Web Server, you can use a different port for the Network Camera.

  • Page 27: Viewing Live Video Via The Internet

    3. Operation is then automatic: • The Network Camera will automatically contact the DDNS server whenever it detects that the Internet IP address has changed, and inform the DDNS server of the new IP address. • Internet users can then connect to the camera using the Domain Name allocated by the DDNS service provider.

  • Page 28: Motion Detection Alerts

    Motion Detection Alerts The Motion Detection feature can generate an Alert when motion is detected. The Network Camera will compare consecutive frames to detect changes caused by the movement of large objects. But the motion detector can also be triggered by: •...

  • Page 29: Chapter 5 Web-Based Management

    Chapter 5 Web-based Management This Chapter provides Setup details of the Network Camera’s Web- based Interface. This Chapter is for the Camera Administrator only. Introduction The Network Camera can be configured using your Web Browser. The Network Camera must have an IP address which is compatible with your PC. The recommended method to ensure this is to use the supplied Camera Wizard, as described in Chapter 2 - Basic Setup.

  • Page 30: Welcome Screen

    Welcome Screen When you connect, the following screen will be displayed. The menu options available from this screen are: • View Video - View live Video using your Web Browser. See Chapter 3 - Viewing Live Video for details. • Administration - Access the Administration menu.

  • Page 31: Administration Menu

    Administration Menu Clicking on Administration on the menu provides access to all the settings for the Network Camera. The Administration menu contains the following options: Setup • System • Network • Wireless • DDNS Video Stream • Video Image • Video Access •...

  • Page 32: System Screen

    System Screen After clicking Administration on the main menu, or selecting System on the Administration menu, you will see a screen like the example below. Data - System Screen System Settings Device ID This displays the name for the Network Camera. Description This field is used for entering a description, such as the location of the Network Camera.
  • Page 33 Network Time Enable or disable the Time Server feature as required. Protocol If Enabled, the Network Camera will contact a Network Time Server at regular intervals and update its internal timer. NTP Server Enter the address for the desired NTP server. Address Update The Schedule determines how often the Network Camera...

  • Page 34: Network Screen

    Network Screen This screen is displayed when the Network menu option is clicked. Data - Network Screen Network Obtain an IP If selected, the Network Camera will obtain its IP address and Address related information from a DHCP Server. Only select this option if your LAN has a DHCP Server.
  • Page 35 Secondary Port This sets the port number for HTTP (Web) connections to the Camera, whether for administration or viewing video. If enabled, you can connect using either port 80 or the Secondary port. You must enter the Secondary port number (between 1024 to 65535) in the field provided.

  • Page 36: Wireless Screen (Wcs-0010 Only)

    Wireless Screen (WCS-0010 Only) This screen is displayed when the Wireless menu option is clicked. Data - Wireless Screen Wireless Network Network Type This determines the type of wireless communication used by the Network Camera. • If you have an Access Point, select Infrastructure. •...
  • Page 37 Security Security System Select the desired option, and then enter the settings for the selected method: • Disabled - No security is used. Anyone using the correct SSID can connect to your network. • WEP - The 802.11b standard. Data is encrypted before transmission, but the encryption system is not very strong.

  • Page 38: Ddns Screen

    DDNS Screen Many internet connections use a "Dynamic IP address", where the Internet IP address is allocated whenever the Internet connection is established. This means that other Internet users don't know the IP address, so can't establish a connection. DDNS is designed to solve this problem, as follows: •...
  • Page 39 Check WAN IP Set the schedule for checking if the Internet IP address has Address changed. If the IP address has changed, the DDNS Server will be notified. NOTE: If the DDNS Service provided some software to perform this IP address update or notification, you should NOT use this software.

  • Page 40: Video Image Screen

    Video Image Screen This screen is displayed when the Video Image menu option is clicked. Data - Video Image Screen MPEG-4 Settings Resolution Select the desired video resolution format. The default resolution is set to 320*240. • Constant Bit Rate: Select the desired bit rate. The default Video Quality is set to 1.2 Mbps.
  • Page 41 Max. Frame Rate Select the desired Maximum bandwidth for the video stream. Note that you can specify EITHER the Bandwidth OR the Frame Rate, not both. If the Bandwidth is defined, the frame rate will be adjusted as necessary to achieve the specified frame rate.

  • Page 42: Video Access Screen

    Video Access Screen This screen is displayed when the Video Access option on the Administration menu is clicked. Data - Video Access Screen User Access • If disabled - No login required, users do not have to Enable Security provide a username and password when they connect to Checking the camera to view video.
  • Page 43 Start Time Enter the start time using a 24 hr clock. End Time Enter the end time using a 24 hr clock. Click this button to add a new period.

  • Page 44: User Database Screen

    User Database Screen This screen is displayed when the User Database option on the Administration menu is clicked. Data - User Database Screen Existing Users User List This displays all users you have entered into the User database. If you have not entered any users, this list will be empty.

  • Page 45: Motion Detection Screen

    Motion Detection Screen This screen is displayed when the Motion Detection option on the Event menu is clicked. Data - Motion Detection Screen Motion Detection You can set the full screen or areas of the video image to be Set Detection Areas examined.

  • Page 46: E-Mail Screen

    E-Mail Screen This screen is displayed when the E-Mail option on the Event menu is clicked. Data - E-Mail Screen Primary/Secondary SMTP Server SMTP Server Enter the address of the SMTP (Simple Mail Transport Address Protocol) Server to be used to send E-Mail. Authentication Select the desired Authentication type for the SMTP Server.

  • Page 47: Ftp Screen

    FTP Screen This screen is displayed when the FTP option on the Event menu is clicked. Data - FTP Screen Primary/Secondary FTP FTP Server Enter the address of the FTP Server. Port Enter the Port of the FTP Server to be connected. Login name Enter your login name for the FTP Server.

  • Page 48: Http Screen

    HTTP Screen This screen is displayed when the HTTP option on the Event menu is clicked. Data - HTTP Screen HTTP Notification Enable Enable this checkbox to use the HTTP Notification. Enter the URL of your HTTP notification server. Proxy Server Specify the proxy server name in the provided field if the Name camera needs to pass through a Proxy Server to do the HTTP...

  • Page 49: Event Trigger Screen

    Event Trigger Screen This screen is displayed when the Event Trigger option on the Event menu is clicked. Data - Event Trigger Screen Event Schedule Schedule List The Event Schedule shows all of the event types currently configured in the Network Camera, along with various information about their configuration, as listed below: •...
  • Page 50 • E-Mail - If checked, an E-Mail (with "Attachment") will be Actions delivered to the SMTP server. (SMTP Server must be configured on the E-Mail page.) • FTP - If checked, an FTP upload will be activated to the FTP server. (FTP servers must be configured on the FTP page.) •...

  • Page 51: Maintenance Screen

    Maintenance Screen Data - Maintenance Screen Administrator Login Administrator Enter the name for the Administrator here. Spaces, punctuation, and special characters must NOT be used in the name. Administrator The password for the Administrator. Password Verify Re-enter the password for the Administrator, to ensure it is Password correct.
  • Page 52 Clear File This does NOT stop the Restore process if it has started. It only Name clears the input for the "Restore Configuration File" field. Restore Click Defaults button to reloads all default settings on the Factory camera. Defaults Restart Camera Click Restart button to restarts the camera.

  • Page 53: Status Screen

    Status Screen Data - Status Screen System Device Name This shows the name of the Network Camera. This shows the description of the Network Camera, such as Description location. F/W version The version of the current firmware installed. Network MAC Address The current IP address of the Network Camera.
  • Page 54 MPEG-4/MJPEG Resolution The image size of the video stream. Video Quality This displays the image quality of the video stream. Frame Rate This displays the frame rate of the video stream. Buttons Refresh Update the log and any other data on screen.

  • Page 55: Log Screen

    Log Screen This screen displays a log of system activity. Data - Log Screen System Log This is a log of system activity. Enable Syslog Check the box to enable the System Log Server feature. Service Syslog Server Enter the address of the Syslog Server. Address Click this to update the data shown on screen.

  • Page 56: Chapter 6 Troubleshooting

    Chapter 6 Troubleshooting This chapter covers the most likely problems and their solutions. Overview This chapter covers some common problems that may be encountered while using the Network Camera and some possible solutions to them. If you follow the suggested steps and the Network Camera still does not function properly, contact your dealer for further advice.
  • Page 57 If you are just trying to view Video, the User Name/Password prompt indicates that the Administrator has restricted access to specified users. Ask the Administrator for your User Name and Password. Problem 4 I can't connect to the Network Camera using a Wireless connection.

  • Page 58: Appendix A Specifications

    Appendix A Specifications Network Camera Model Network Camera Dimensions 114.3mm (W) * 141.6mm (H) * 41.4mm (D) Operating 0° C to 40° C Temperature Storage Temperature -20° C to 70° C Network Protocols: TCP/IP, DHCP, SMTP, NTP, HTTP, FTP, NTP, RTP, RTSP, UPnP (Discovery only) Network Interface: 1 Ethernet 10/100BaseT (RJ45) LAN connection...

  • Page 59: Copyright Notice

    Copyright Notice Many software components are covered by the GNU GPL (General Public License). Some are covered by other Licenses as listed in the table below. Details of each applicable license are contained in the following section. No Warranty THIS SOFTWARE IS PROVIDED BY THE AUTHOR AND CONTRIBUTORS ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
  • Page 60 ntp-4.1.71 license Copyright (c) David L. Mills 1992-2001 Permission to use, copy, modify, and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appears in all copies and that both the copyright notice and this permission notice appear in supporting documentation, and that the name University of Delaware not be used in advertising or publicity pertaining to distribution of the software without specific, written prior permission.
  • Page 61 cron license Copyright (c) 1989 The Regents of the University of California. All rights reserved. This code is derived from software contributed to Berkeley by Paul Vixie. Redistribution and use in source and binary forms are permitted provided that the above copyright notice and this paragraph are duplicated in all such forms and that any documentation, advertising materials, and other materials related to such distribution and use acknowledge that the software was developed by the University of...

  • Page 62: Gnu General Public License

    GNU General Public License GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 51 Franklin St, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.
  • Page 63 "work based on the Program" means either the Program or any derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifications and/or translated into another language. (Hereinafter, translation is included without limitation in the term "modification".) Each licensee is addressed as "you".
  • Page 64 3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following: a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange;...
  • Page 65 at all. For example, if a patent license would not permit royalty-free redistribution of the Program by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program.
  • Page 66 12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY...

  • Page 67: Lesser Gnu General Public License

    Lesser GNU General Public License GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999 Copyright (C) 1991, 1999 Free Software Foundation, Inc. 51 Franklin St, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.
  • Page 68 Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a company cannot effectively restrict the users of a free program by obtaining a restrictive license from a patent holder. Therefore, we insist that any patent license obtained for a version of the library must be consistent with the full freedom of use specified in this license.
  • Page 69 may be distributed under the terms of this Lesser General Public License (also called "this License"). Each licensee is addressed as "you". A "library" means a collection of software functions and/or data prepared so as to be conveniently linked with application programs (which use some of those functions and data) to form executables.
  • Page 70 independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a work based on the Library, the distribution of the whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.
  • Page 71 derivative work. (Executables containing this object code plus portions of the Library will still fall under Section 6.) Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work under the terms of Section 6. Any executables containing that work also fall under Section 6, whether or not they are linked directly with the Library itself.
  • Page 72 6. As an exception to the Sections above, you may also combine or link a "work that uses the Library" with the Library to produce a work containing portions of the Library, and distribute that work under terms of your choice, provided that the terms permit modification of the work for the customer's own use and reverse engineering for debugging such modifications.
  • Page 73 b) Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and explaining where to find the accompanying uncombined form of the same work. 8. You may not copy, modify, sublicense, link with, or distribute the Library except as expressly provided under this License.
  • Page 74 13. The Free Software Foundation may publish revised and/or new versions of the Lesser General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.
  • Page 75 If you would like a copy of the GPL or other open source code in this software on a physical CD medium, LevelOne (Digital Data Communications) offers to mail this CD to you upon request, for a price of US$9.99 plus the cost of shipping.
  • Page 77 Appendix B Streaming Video/Audio Solution Overview Streaming video is a sequence of "moving images" that are sent in compressed form over the Internet and displayed by the viewer as they arrive. With streaming, a Web user does not have to wait to download a large file before seeing the video or hearing the sound.
