Model No. IMSB71620
IMSG71620
Serial No.
The serial number is on a sign
behind the access panel. Write the
serial number in the space above.
Access
Panel
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The technicians on our customer
hot line will provide immediate
assistance, free of charge.
CUSTOMER HOT LINE:
1-877-897-7493
Mon.–Fri., 8 a.m.–5 p.m. CST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.workoutwarehouse.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading

Related Manuals for Image Renew 716

Summary of Contents for Image Renew 716

  • Page 1 Model No. IMSB71620 IMSG71620 USER’S MANUAL Serial No. The serial number is on a sign behind the access panel. Write the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory.

  • Page 2: Table Of Contents

    Table of Contents Posting the Warning Sign ..............2 Important Safety Instructions .

  • Page 3: Important Safety Instructions

    Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 10.
  • Page 4 20. DANGER—Risk of electric shock. Keep all physician before using the hydrotherapy spa. electrical appliances such as radios, tele- Pregnant women should not use the spa if phones, televisions, and lights at least five the water temperature is above 100°F; the feet away from the water.
  • Page 5 35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.

  • Page 6: Before You Begin

    IMAGE ® RENEW 716. If you have ques- RENEW 716 allows you to enjoy all the benefits of tions after reading the manual, please call our hydrotherapy in the comfort and privacy of your home. Customer Service Department toll-free at 1-877-897- 7493, Monday through Friday, 8 a.m.

  • Page 7: Choosing A Location For The Hydrotherapy Spa

    Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa.

  • Page 8: Assembly

    Assembly Before beginning assembly, carefully read the ASSEMBLY REQUIRES THE FOLLOWING following information and instructions: TOOLS (not included): • Place all parts in a cleared area and remove the • One phillips screwdriver packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is A wire connector is provided on the electronics completed and the spa is operating.
  • Page 9 3. Insert the three pillows (47) into the lounge seat receptacles. The pillows can be rotated 180º to change between the high or low positions. 4. The hydrotherapy spa operates on a 240 volt power source and must be wired directly to a 240 volt Ground Fault Circuit Interrupter (GFCI) installed in your home.

  • Page 10: Using The Hydrotherapy Spa

    Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat seven Once you have tested the GFCI, you should verify the adults. The spa holds approximately 375 gallons of water flow from the pumping unit. Set the air control water and offers a heating system (80°F to 104°F), a on the console to the lowest setting (see USING THE filtration system, and adjustable hydrotherapy jets.

  • Page 11: Spa Shell Diagram

    Spa Shell Diagram A. The filter can be removed for cleaning or replace- H. The console controls the spa jets, turns the under- ment (see CHECKING AND CLEANING THE FIL- water light on and off, and adjusts the water tem- TER on page 13).

  • Page 12: Using The Controls

    Using the Controls Air Controls 1 and 2 Display Temperature Temperature Light Button Button Button Button hydrotherapy. If the button is pressed twice, the spa jets will run at high speed, providing moderate-pres- sure hydrotherapy. If the button is pressed again, the jets will shut off.

  • Page 13: Maintenance

    Maintenance The hydrotherapy spa is designed to provide years of MAINTAINING THE SPA COVER enjoyment. Please follow the guidelines below to properly maintain your spa. The spa cover should be cleaned monthly. To clean the spa cover, use water and a non-abrasive cleaner MAINTENANCE SCHEDULE on the entire cover.
  • Page 14 3. Do not exceed the recommended amounts of desired time is reached. Press the jet button to con- chemicals—follow the directions on the label. firm the selection. As spa usage increases, the dura- 4. Keep all chemicals out of the reach of children tion of the filter cycle may need to be increased.
  • Page 15 To drain the hydrotherapy spa, follow the steps below: pumps. WINTER USE AND CARE 1. Using the console, adjust the temperature to the lowest setting. The hydrotherapy spa is designed for year-round use. 2. Shut off the power to the spa, at the circuit breaker If you decide to store the spa for the winter, store it in or GFCI.

  • Page 16: Troubleshooting

    Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1.
  • Page 17 9. SYMPTOM: THE WATER LEVEL DROPS 10. SYMPTOM: THE SPA JET UNIT CONTINUES TO RUN AFTER IT HAS BEEN SHUT OFF a. A clamp or seal inside the pump compartment may be loose. Check inside the pump compart- a. To turn the main jets off, press pump button 1 ment for excess water and watch the pump unit once or twice.

  • Page 18: Part List

    Part List —Model No. IMSB71620/IMSG71620 R0802A Key No. Qty. Description Key No. Qty. Description Thermometer Fitting Heater Collar With Screw Jet Pump/Motor Power Cord Flared Nozzle Filter Cover Nozzle Housing Rubber Washer Small Rotator Filter Large Rotary Jet Rubber Isolator Face Ring Blue Light Cover Small Nozzle...

  • Page 19: Exploded Drawing

    Exploded Drawing —Model No. IMSB71620/IMSG71620) R0802A...

  • Page 20: Ordering Replacement Parts

    • The NAME of the product (IMAGE ® RENEW 716 hydrotherapy spa) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAW-...
