- Page 1 Dishwasher Installation instructions DW60 models User guide NZ AU...
-
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions Introducing your dishwasher DW60CS AND DW60CD MODELS Using your dishwasher Selecting a wash programme DW60CR MODELS Using your dishwasher Selecting a wash programme Caring for your dinnerware Dishwasher standards test Loading Detergent Rinse aid Care and cleaning Fault codes Troubleshooting... -
Page 4: Safety And Warnings
Safety and warnings Important safety precautions For your safety, follow basic precautions when using your dishwasher, including the following: Please read all instructions before operating your dishwasher. The information in this user guide must be followed to minimise the risk of fire or explosion, or to prevent property damage, personal injury or loss of life. - Page 5 Safety and warnings Installation This dishwasher must be installed and positioned in accordance with the ‘Installation instructions’ before it is used. Installation and service should be performed by a qualified technician. If the power supply cord is damaged, it must be replaced by the manufacturer or Authorised Service Centre or a similarly qualified person in order to avoid a hazard.
-
Page 6: Installation Instructions
Installation instructions Before you start These instructions are intended as a guide only. It is the responsibility of the plumber and electrician to ensure that each installation complies with the Government and local government by-laws. Check packaging and dishwasher immediately for signs of transport damage. If the appliance is damaged, do not put into use but contact your Fisher &... - Page 7 Installation instructions Plumbing Drainage The recommended method of installation is shown in the diagrams below. These methods are designed to eliminate problems that occur with combined sink – dishwasher waste systems. The standpipe must have a minimum diameter of 38 mm and stand 750 mm above the floor. A drain hose support is provided to hold the drain hose in place in the standpipe (see diagrams 1 and 2).
- Page 8 Installation instructions Water inlet connections The dishwasher has a single valve water connection. We recommend a cold water connection to give the best wash performance and energy efficiency. Important! The appliance should be connected to the water main using a new hose set. Old hose sets should not be used.
- Page 9 Refer to the ‘Fault codes’ and ‘Troubleshooting’ sections. If you cannot solve the problem, contact a Fisher & Paykel Authorised Service Centre. Specifications Model details Model Colour DW60CSW1 / DW60CDW2 / DW60CRW2 White DW60CSX1 / DW60CDX2 / DW60CRX2 Stainless steel Technical Data Width...
-
Page 11: Introducing Your Dishwasher
Introducing your dishwasher Dishwasher interior Fig. 1 Dishwasher interior Upper rack Top spray arm Lower rack Bottom spray arm Drain filter Detergent and rinse aid dispenser Water inlet hose Drain hose Power supply cord Cutlery basket... -
Page 12: Using Your Dishwasher
Using your dishwasher Power button (ON/OFF) Fig. 2 Control panel for DW60CS models Programme button Programme indicator Fig. 3 Control panel for DW60CD models Power button (ON/OFF) Rinse aid indicator Reset button Programme button Delay start button Programme indicator Time remaining indicator Heater indicator Quick start Remove all food scraps and load the dishes. - Page 13 Using your dishwasher If you have forgotten to load some dishes To pause a wash programme (DW60CD models only) Press the Power button. Open the door slowly. Important! There is a risk of being sprayed with hot water. Do not open the door fully until the spray arm has stopped rotating.
- Page 14 Using your dishwasher If you want a programme to start later Delay start (DW60CD models only) This feature can delay the start of a wash programme from 1 to 12 hours. To activate the delay start: Ensure you have loaded all the dishes, added detergent, and closed the door. Turn your dishwasher ON.
-
Page 15: Selecting A Wash Programme
Selecting a wash programme HEAVY PROGRAMME NORMAL NORMAL ECO DELICATE FAST RINSE DUTY Dishes with Normally Lightly Very Rinses dishes What load Heavily normal soils soiled dishes soiled lightly that have been should I use soiled pots, for optimum for optimum delicate soiled stacked... -
Page 16: Using Your Dishwasher
Using your dishwasher Programme dial Power button ‘END’ light Turn to align with a (ON/OFF) - if flashing: number to select a a wash programme is programme underway - if steadily lit: a wash programme has Fig. 4 Control panel for DW60CR models ended or paused, the dishwasher is on Quick start... - Page 17 Using your dishwasher Turn the Programme dial to “Reset”. Press the Power button to turn the dishwasher off. The “End” light will go out. Turn off the water supply. Open the door and leave it slightly ajar. Wait for a few minutes, then remove the dishes once they are cool enough to touch. If you want to change the programme A wash programme can be changed if it has only been running for a short time.
-
Page 18: Selecting A Wash Programme
Selecting a wash programme PROGRAMME HEAVY NORMAL NORMAL ECO QUICK RINSE Dishes with Normally Very lightly Rinses dishes What load Heavily normal soils soiled dishes soiled mixed that have been should I use soiled pots, for optimum for optimum dishes. stacked it for? pans, and... -
Page 19: Caring For Your Dinnerware
Caring for your dinnerware The combination of high temperatures and dishwasher detergent may cause damage to some items if they are washed in your dishwasher. Remember, if in doubt about any items to be washed in the dishwasher, follow the instructions from the manufacturer of the items, or wash them by hand. -
Page 20: Dishwasher Standards Test
Dishwasher standards test This dishwasher is tested to AS/NZS 2007 standards for both wash and dry performance. The following are loading pattern diagrams, detergent quantities and rinse aid quantities used for the dishwasher. Normal Eco (DW60CS, DW60CD) Wash programme Normal (DW60CR) Detergent quantities 5 g prewash, +25 g main wash... -
Page 21: Loading
Loading Take care when loading dishes to ensure that the water will reach all areas, particularly the cup racks. If there are any items blocking the spray arms’ paths or the wash water, then the performance will be ineffective. Before placing the dishes in the dishwasher, remove larger food particles to prevent the filter from becoming clogged. - Page 22 Loading How to load the upper rack The upper rack is designed to hold items like glasses, cups, saucers, plates, small bowls and shallow pans. Position these items so that they cannot be moved during the wash. Upper rack adjustment for DW60CS and DW60CR models The upper rack can be adjusted for height by using the rollers located on both sides of the rack (see below).
-
Page 23: Detergent
Detergent Important! Never sprinkle or pour detergent directly onto any item in the dishwasher. Hand washing liquids, soap, laundry detergents or disinfectants will damage your dishwasher. Press button to open Filling the detergent dispenser Press the button on the top of the dispenser to open the cover. Pour the detergent for the wash cycle into the larger main detergent compartment. -
Page 24: Rinse Aid
Rinse aid We highly recommend the regular use of liquid rinse aid to give the best drying results. Rinse aid gives a streak-free, sparkling clean look to glass and chinaware. In addition it prevents metal from tarnishing. The rinse aid dispenser is located on the inside panel of the door. Filling the rinse aid dispenser Open the dispenser by turning the cap in an anticlockwise direction. -
Page 25: Care And Cleaning
Care and cleaning After each wash, turn off the water supply to the dishwasher and leave the door ajar 30°, so that moisture and odours are not trapped inside. Important! The door should not be left in the fully open position as this could present a tripping hazard. Before cleaning or performing maintenance, always remove the power plug from the wall socket. - Page 26 Care and cleaning Cleaning the drain filters and spray arms Regular inspection and maintenance of your dishwasher helps to prevent problems from occurring. You should carefully inspect your dishwasher regularly. Check that no grease or scale has accumulated on the inside of your dishwasher. If you discover any deposits, clean them thoroughly with warm water on a soft, lint-free cloth.
-
Page 27: Fault Codes
Fault codes Please read the following pages before you call for service. You can correct many of your dishwasher’s problems yourself, using the checklists on the following pages. DW60CS and DW60CD models Fault signal Fault Possible causes What to do code First 2 The door is not properly closed. -
Page 28: Dw60Cr
Fault codes Please read the following pages before you call for service. You can correct many of your dishwasher’s problems yourself, using the checklists on the following pages. DW60CR models Fault signal Possible causes What to do 2 beeps The water is not turned on or the hose Turn on the water supply and check that recurring is not properly connected. -
Page 29: Troubleshooting
Troubleshooting Problem Probable cause What to do Dishwasher will not start. Power supply is not connected. Connect the power supply. The door is not properly closed. Close the door. No programme has been selected. Select a programme. Water tap not turned on. Ensure the water is connected and turned on. - Page 30 Troubleshooting Problem Probable cause What to do Knocking or rattling Spray arm knocking against Pause cycle and reposition sound during wash. dishes. dishes. Dishes have been stacked Pause cycle and reposition incorrectly. dishes. Unclean dishes. Wash programme unsuitable for See the ‘Wash programme chart’ load or soils were too heavily for a suitable wash programme.
- Page 31 Troubleshooting Problem Probable cause What to do Glasses have dull Rinse aid set too low. Increase rinse aid setting. See appearance. the ‘Rinse aid’ section. Tea stains or traces of Not enough detergent. See the ‘Detergent’ section or lipstick have not been the detergent manufacturer’s completely removed.
-
Page 32: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance, please refer to the Service &... - Page 36 www.elba.co.nz www.elba.com.au Copyright © Fisher & Paykel 2011. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
