Models Included
◆ SD2
WARNING HOT LIQUID,
Scalding may occur.
Avoid splashing.
CAUTION: Please use
this setup procedure
before attempting to use
this appliance. Failure to follow the
instructions can result in injury or the
voiding of the warranty.
CAUTION: DO NOT
connect this unit to hot
water. The inlet valve is
not rated for hot water.
WILBUR CURTIS COMPANY
Montebello, CA 90640
ISO 9001 REGISTERED
W
ilbur
Service Manual – Soluble Coffee Machine
Important Safeguards/Conventions
This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an autho-
rized Wilbur Curtis service center.
• Do NOT immerse the unit in water or any other liquid
• To reduce the risk of fire or electric shock, do NOT open top panel. No user serviceable parts inside. Repair should be done
only by authorized service personnel.
• Keep hands and other items away from hot parts of unit during operation.
• Never clean with scouring powders or harsh implements.
Conventions
WARNINGS – To help avoid personal injury
Important Notes/Cautions – from the factory
Sanitation Requirements
Your Curtis Café System is Factory Pre-Set and Ready to Go... Right from the Carton.
Following are the Factory Settings for your Soluble Delivery System:
• Tank Temperature = 190°F
• Flavor Controls= Set at 50%
• Dispensing Mode Set for Manual Dispensing
Generally there will never be a reason to change your SD2 programming. However, should you need to make slight adjustments to meet
your dispensing needs, programming instructions are provided later in this manual.
System Requirements:
• Water Source 20 – 90 PSI (Minimum Flow Rate of 1 GPM)
• Electrical: See attached schematic for standard model or visit www.wilburcurtis.com for your model.
Equipment to be installed to comply with applicable federal, state, or local plumbing/electrical codes having jurisdiction.
SETUP STEPS
The unit should be level (left to right and front to back), located on a solid counter top. Connect a water line from the water filter to the
brewer. NOTE: Some type of water filtration device must be used to maintain a trouble-free operation. (In areas with extremely hard
water, we suggest that a sedimentary and taste & odor filter be installed.) This will prolong the life of your dispensing system and enhance
coffee quality.
The National Sanitation Foundation requires the following water connection:
1. A quick disconnect or additional coiled tubing (at least 2x the depth of the unit) so that the machine can be moved for
cleaning underneath.
2. In some areas an approved backflow prevention device may be required between the brewer and the water supply.
1. Connect a water line from your facility to the 1/4" flare water inlet fitting of the valve, behind the machine. Water volume
going to the machine should be stable. Use tubing sized sufficiently to provide a minimum flow rate of one gallon per minute.
2. Plug the power cord into an electrical outlet rated at 20A.
3. Switch on the toggle switch, behind the unit, that runs power to the components in the machine. The lights (display window
and row of buttons) on the front door will activate and the heating tank will start to fill.
4. Water in the heating tank will require about 30 minutes to reach operating temperature (factory setting of 190°F). At this time
the READY LED will light.
5. Remove and fill the canisters with soluble coffee mixes.
OPERATION INSTRUCTIONS
1. Select one of the coffee dispense buttons.
2. Place your cup beneath the spout of the desired coffee flavor.
2. Press and hold the selected PUSH button. Hot coffee beverage will start dispensing.
3. Release the button when the cup is 2/3 full.
FILL CANISTERS DAILY
1. Open the front door to access the coffee canisters.
2. The canisters must be removed from the unit for filling. Turn the product delivery elbows upward.
3. Reposition the canisters on the machine, turning the product delivery elbows downward and aligning the gear socket with the
motor shaft.
C
C
urtis
ompany
, i
.
nC
1
Advertisement
Table of Contents
Related Manuals for Curtis Soluble Coffee Machine
Summary of Contents for Curtis Soluble Coffee Machine
- Page 1 Service Manual – Soluble Coffee Machine on the web www.wilburcurtis.com Important Safeguards/Conventions This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an autho- Models Included rized Wilbur Curtis service center. • Do NOT immerse the unit in water or any other liquid ◆ SD2 • To reduce the risk of fire or electric shock, do NOT open top panel. No user serviceable parts inside. Repair should be done only by authorized service personnel. • Keep hands and other items away from hot parts of unit during operation. • Never clean with scouring powders or harsh implements. Conventions WARNINGS – To help avoid personal injury WARNING HOT LIQUID, Important Notes/Cautions –...
- Page 2 Steps to Programming Your Curtis Cafe System is Factory Pre-Set for Optimum Performance. Usually this Does Not Change. WARNING HOT LIQUID, Scalding may occur. Avoid splashing. Place an empty container under the dispensing nozzles while programming. All programming is performed at the control panel (illustration, right). The Hot Water button is used for only for dispens- ing hot water and does not require any program- ming. Water is dispensed as long as the Hot Water button is held down. The STOP/WASH BUTTON has several functions. This button is used to stop a Portion Control dispense cycle. It is used to wash out the mixing and dispensing systems and it is used to enter programming functions. Product % Ratio This controls the amount of dry product that is metered from the hoppers. This can be programmed from 10% to 100% of the capacity of the dispensing system. By counting LED flashes you can determine the product % ratio currently set for this dispense button (see table). Number of Enter Program Mode – press and hold STOP/WASH for about ten [10] seconds until all lights Volume Flashes start blinking. To program Product % Ratio, press and hold the selected PUSH button for approximately one second, then release. The current setting will be indicated by LED flashes. 100% To change the product throw, press and hold the button until light starts quick flashing. Each quick flash increases the amount by 10%. Release the button when the desired throw amount is achieved. After releasing the button, the number of blinks represent the new setting. To exit the Powder Dispensing Mode, push the other PUSH button. Portion Control Liquid Dispensing Mode This program adjustment allows you to setup the machine to automatically dispense a preset volume of coffee. When the user makes a PUSH button selection, the SD2 unit dispenses only the volume of coffee programmed by the Portion Control Dispensing Mode. By setting the unit for Portion Control Dispensing, you have locked out the manual dispense feature. Enter Program Mode – press and hold STOP/WASH for about ten [10] seconds until all lights start blinking.
- Page 3 Programming Continued ... Manual Liquid Dispensing Mode This feature sets up the SD2 unit to dispense coffee only as long as the user holds down the selected PUSH button. As soon as the user stops pressing the button, coffee stops flowing into the cup. Setting the unit for Manual Liquid Dispense will turn off the Portion Control Dispense Mode. Enter Program Mode – press and hold STOP/WASH for about ten [10] seconds until all lights on the control panel are blinking. Set Manual Dispense – While you are in the programming mode, press and hold the PUSH button. Hot liquid will start to flow. Continue to hold down the PUSH button until liquid stops flowing, then release the button. At this time, you have selected the Manual Liquid Dispensing Mode and have exited out of the programming mode. Confirm/Reset Temperature These features allow you to check the heating tank temperature or change the temperature if desired. The temperature in the tank is program- mable from 170°F, in 2 degree increments up to 204°F . Temperature Settings To Confirm Temperature. Press and hold STOP/WASH button for approximately 2-3 seconds. When the READY light Number of starts blinking. Lift off from STOP/WASH button. Each blink equals 2ºF, starting with 170ºF, to a maximum of 204ºF. Blinks Temperature 170ºF To Change Tank Temperature 172ºF 174ºF 176ºF Enter Temperature Program Mode. Press and hold STOP/WASH button. READY light will 178ºF start “quick flashing”. 180ºF 182ºF 184ºF 186ºF To Change Temperature. Continue holding STOP/WASH button. Each quick flash equals 2ºF. 188ºF Release STOP/WASH when desired temperature is reached. 190ºF 192ºF 194ºF 196ºF 198ºF 200ºF...
-
Page 4: Error Codes
Error Codes ERROR CODES: Curtis Cafe systems contain various safety features in the electronic circuitry that shut down the functions of the unit in the event of a system failure. Error codes are signalled by the READY light blinking one of two patterns: WATER LEVEL PROBLEM 3 LONG AND 1 SHORT The code can be initiated by a variety of occurances. A water line is turned off or a filter needs changing. A water inlet valve may be malfunctioning. A water level probe may be grounded. There may be a loose connection or a defect in the control board. TEMPERATURE SENSOR PROBLEM 3 LONG AND 2 SHORT Power may be turned off. Temperature sensor may have a bad connection or may not be tight against the tank. Heating element may be burned out. Control board may be faulty. Flushing the Whipper Chambers CAUTION: Every three to four hours or more often if necessary flush the whipper chamber/dispensing system. DO NOT use A. Make sure power is ON. undiluted B. Press and hold the STOP/WASH button. Select one of the PUSH dispensing buttons and press. Hot rinse bleach or water will flush out the system. Lift off the STOP/WASH button when water runs clear. chlorine. C. Clean up any water that may have spilled. Cleaning A. Switch off the unit at the power toggle switch, marked CONTROL, behind the unit. -
Page 5: Illustrated Parts List
DOOR, FRONT WA WC-29047 ELBOW, OVERFLOW, PLASTIC WC-39471 LABEL, CONTROL PANEL SD2 WC-3734 * KIT, DUMP VALVE 120V 12W WC-38290 LABEL, DOOR CURTIS LOGO SD2 WC- 904-04* HEATING ELEMENT 1.6KW 120VAC W/NUTS CA-1095 CONNECTOR, ORIFICE WATER WC-1438-101 * SENSOR, TEMPERATURE TANK CA-1011-05... - Page 6 Illustrated Parts List 29 30 31...
-
Page 7: Electrical Diagram
Electrical Diagram... -
Page 8: Product Warranty Information
This includes institutional and correctional facilities. The Wilbur Curtis Company will allow up to 100 miles, round trip, per in-warranty service call.
