- Page 1 USER GUIDE G3 Gemini Series ® Coffee Brewing System READ AND SAVE THESE INSTRUCTIONS NOTICE TO INSTALLER: Please leave this booklet with the machine.
-
Page 2: Table Of Contents
........................ES35 ..............................................ES37 ......................................................................................................EC4 ..............................Contact Information Wilbur Curtis Co., Inc. 6913 Acco Street | Montebello, CA 90640 US Phone: 323-837-2300 | Toll Free: 800-421-6150 Email: csrassistance@wilburcurtis.com | Web: www.wilburcurtis.com . - 4:00 . PT Email: techsupport@wilburcurtis.com... -
Page 3: Fs20
KEY FEATURES/SPECIFICATIONS/SYSTEM REQUIREMENTS FS20 Key Features • Gold Cup Series™ – digital control module provides precise control over all aspects of brewing: time, temperature, volume plus specialty coffee needs from pre-infusion to pulse-brewing to water bypass. • gourmet results every time. •... -
Page 4: Is2
INSTRUCTIONS could result in personal injury or void the warranty. • This appliance is designed for commercial use. Any service other than cleaning and preventive maintenance should be performed by an authorized Wilbur Curtis service technician. • serviceable parts inside. - Page 5 IMPORTANT SAFEGUARDS CE Requirements • This appliance must be installed in locations where it can be overseen by trained personnel. • • • • This appliance must not be cleaned by water jet. • instruction concerning use of the appliance in a safe way and if they understand the hazards involved. •...
-
Page 6: Ii2
INSTALLATION INSTRUCTIONS WARNING: WARNING: properly grounded. NOTICE: SPECIFICATIONS section. IMPORTANT: Installation Instructions Installation Requirements • A secure surface capable of supporting the weight of the appliance. • For units without an attached cord set: Appropriately sized, UL listed, grounding type power cable to meet enough •... -
Page 7: Ii1
INSTALLATION INSTRUCTIONS Installation Leveling WARNING: Use the leveling legs to level the brewer only. Do not use them to adjust brewer height. Do not extend them higher than necessary. Position the brewer on the counter top. Level it left to right and front to back by turning the bottom of the legs. - Page 8 INSTALLATION INSTRUCTIONS Connect the Brewer Wiring (cont.) Brewers With A Cord Set Attached - 12 Connect the power cord to the appropriate type of electrical outlet. WARNING: Connect the power cord to the appropriate type and size electrical outlet. If the electrical outlet is not compatible with the power cord, have it upgraded by a licensed electrician.
- Page 9 INSTALLATION INSTRUCTIONS 19 If the UCM is not already lit, push the ON/OFF button to the correct volume, the heating elements will turn on automatically. Depending on the incoming water water tank typically requires 20 to 30 minutes to the water has heated, “Ready to Brew” should be on the display.
-
Page 10: Oi17
OPERATING INSTRUCTIONS OI17 Brewing Instructions WARNING - TO AVOID SCALDING, AVOID SPLASHING. Keep body parts clear of the brewer during brewing. Do not remove the brew basket while “Brewing” appears on the display. NOTICE - Do not use IntelliFresh satellites on non-IntelliFresh brewers. The G3 Gemini brewer is factory preset for optimal performance. -
Page 11: Ci1
CLEANING INSTRUCTIONS WARNING: HOT SURFACES - To avoid injury, allow the brewer and dispenser(s) to cool before cleaning. NOTICE - Do not use cleaning liquids, compounds or powders containing chlorine (bleach) or corrosives. USE OF THESE PRODUCTS WILL VOID THE WARRANTY. Cleaning The Brewer - Daily WARNING: DO NOT immerse the brewer in water or any other liquid. -
Page 12: Ci3
CLEANING INSTRUCTIONS Cleaning the Satellite (Daily) WARNING: DO NOT immerse the satellite in water or any other liquid. Do not place the satellite in a dishwasher. Placing the satellite in a dishwasher will void the warranty. Cleaning the Liner Prepare a mild solution of detergent and warm water. Remove the satellite from the brewer and remove the lid. - Page 13 CLEANING INSTRUCTIONS Cleaning the Faucet Parts and Site Gauge (cont.) 10 Air Dry - Allow all parts to thoroughly air dry. 11 Reassemble - When dry, reassemble the handle/ bonnet. Hand tighten the handle/bonnet onto the top of the faucet assembly. Reinstall the site gauge (if applicable).
- Page 14 PROGRAMMING GUIDE To enter programming mode: With unit OFF, press and hold bottom right BREW button (4). Then press and release ON/OFF button (2). Continue to hold down BREW button until Enter Code appears. Label style may vary Enter 4 digit code. (factory default = 1-2-3-4) * “Ready”...
- Page 15 PROGRAMMING GUIDE Programming Options Some menus save and exit automatically when a parameter is updated. Other menus exit to the previous menu when a parameter is saved. To exit, press until EXIT appears on the display, then press Global Recipes Menu Select from the following coffee types: Gourmet STD (standard), Light Roast, Dark Roast, High Yield, Filter Pack or Decaf.
- Page 16 Banner Name - changes the banner name that appears on the display (the factory default is Curtis). No banner name appears when all blanks are entered. Once accessed, press to choose the letter to change.
- Page 17 PROGRAMMING GUIDE Programming Options (cont.) Brew Button Programming Menu until Exit appears on the display. Press to exit, then re-enter the Brew Button Program to program the next one. Brew by Volume - MEDIUM desired volume is reached, press the same BREW button again to stop the brew cycle and set the volume. Brew by Time - adjusts the amount of coffee brewed by time rather than by volume (the factory defaults are LARGE 5min-25sec., MEDIUM 3min-32sec., SMALL 1min-52sec).
- Page 18 PROGRAMMING GUIDE Programming Options (cont.) Language - changes the language that appears on the display (the factory default is English). This feature is programmable for changing and adding languages. Once accessed, press to choose the desired setting, then press to exit. Model Select - changes the model number and number of batches (to match the label on the universal control module, the factory default is Gemini-Twin IF, single batch).
- Page 19 ROUGH-IN DRAWINGS RD26 GEMTS - Twin Coffee Brewer 1.00 in [2.5 cm] 22.25 in* 29.75 in [56.5 cm] 11.13 in [75.6 cm] [28.3 cm] 6.88 in 5.50 in 18.13 in [17.5 cm] [14.0 cm] [46.0 cm] 4.00 in *25.63 in [65.1 cm] on model GEMTS16A1000 [10.2 cm] GEMSS - Single Coffee Brewer 1.00 in...
- Page 20 ILLUSTRATED PARTS LIST IP33 GEMTS - Main Chassis - Exploded View Water tank assembly, see section IP26 See satellite user guide for satellite replacement parts. GEMSS/GEMTS - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 051118D...
-
Page 21: Ip33
WC-13336 2 FOR SOLID STATE RELAY (INCLUDES GEMSS/GEMTS TERMINAL BLOCK) LABEL, UCM OVERLAY DUAL TWIN 3-BATCH WC-39395 HARNESS ASSY, COMPLETE TP2T19 GEMTS GEMTS CURTIS WC-13337 3 FOR SOLID STATE RELAY (INCLUDES LABEL, UCM OVERLAY GEMTS TWIN 2-BATCH TERMINAL BLOCK) WC-39439 CURTIS... - Page 22 ILLUSTRATED PARTS/RECOMMENDED PARTS IP33 GEMSS - Main Chassis - Exploded View See satellite user guide for satellite replacement parts. Water tanks assemblies: Single voltage units, see section IP31 Dual voltage units, see section IP32 GEMSS/GEMTS - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 051118D...
- Page 23 LEG, 4" ADJUSTABLE 3/8-16 THRD ITALIAN STAINLESS STEEL WC-3528 STYLE WC-1806 SEAT CUP, SILICONE USE ON WC-1809 FAUCET WC-5428 DECK, WARMER FORMED MINI-GEMS 1 GEMSS10A10000, 2 GEMSS30A1000, 3 GEMSS63A1000 older units. b Units built before 05/15/17. GEMSS/GEMTS - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 051118D...
- Page 24 ILLUSTRATED PARTS/RECOMMENDED PARTS IP26 WC-62033 - Tank Assembly WC-62033 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-54287 TANK, ASSY TPS1T/GEMTS WC-4382 GUARD, SHOCK HTNG ELMNT DOUBLE WC-62033 TANK, COMPLETE GEMTS W/ULTEM FITTINGS THERMOSTAT, HI LIMIT HEATER CONTROL DPST WC-522 277V 40A...
-
Page 25: Ip31
ILLUSTRATED PARTS LIST IP31 WC-62035 - Tank Assembly WC-62035 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-62035 TANK, COMPLETE GEMSS W/ULTEM FITTINGS THERMOSTAT, HI LIMIT HEATER CONTROL DPST WC-522 277V 40A WC-5853-102 COVER, TOP HEATING TANK GEN USE WC-43055... -
Page 26: Ip32
ILLUSTRATED PARTS LIST IP32 WC-62034 - Tank Assembly WC-62034 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION TANK, COMPLETE GEMSS DV W/ ULTEM THERMOSTAT, HI LIMIT HEATER CONTROL WC-62034 WC-522 FITINGS DPST 277V 40A WC-5853-102 COVER, TOP HEATING TANK GEN USE WC-43055... -
Page 27: Es31
ELECTRICAL SCHEMATICS ES31 SINGLE, DOMESTIC, 220 VOLT GTPS-10, ELECTRICAL SCHEMATIC 061918B... -
Page 28: Es32
ELECTRICAL SCHEMATICS ES32 SINGLE, EXPORT UCM Pin Assignments 20 Pin Connector GRINDER INTERLOCK COMMON-SOLID STATE RELAY & GRINDER +5 VDC BREW CONE LOCK NOT USED INLET VALVE BYPASS VALVE NOT USED WARMER NOT USED NOT USED NOT USED TANK TEMPERATURE SENSOR ELECTRICAL RATING TABLE TANK TEMPERATURE SENSOR # of... -
Page 29: Es33
ELECTRICAL SCHEMATICS ES33 SINGLE, DOMESTIC, DUAL VOLTAGE UCM Pin Assignments 20 Pin Connector GRINDER INTERLOCK COMMON-SOLID STATE RELAY & GRINDER +5 VDC BREW CONE LOCK NOT USED INLET VALVE BYPASS VALVE NOT USED WARMER NOT USED NOT USED NOT USED TANK TEMPERATURE SENSOR TANK TEMPERATURE SENSOR UCM GROUND... -
Page 30: Es34
ELECTRICAL SCHEMATICS ES34 TWIN, DOMESTIC... -
Page 31: Es35
ELECTRICAL SCHEMATICS ES35 TWIN, 3 PHASE WITH TRANSFORMER... - Page 32 ELECTRICAL SCHEMATICS ES36 TWIN, 3 PHASE WITHOUT TRANSFORMER...
-
Page 33: Es37
ELECTRICAL SCHEMATICS ES37 TWIN, EXPORT... - Page 34 TROUBLESHOOTING GUIDE WARNING: Electric Shock Hazard - Scald and Burn Hazard - IMPORTANT: always check all Valve Test Procedure Troubleshooting Guidelines • • • • Valve Test Procedure in either direction Water Not Hot Enough replace the temperature sensor Water Heats More Slowly Than Usual...
- Page 35 TROUBLESHOOTING GUIDE During Brewing No Power - Display Not Lit Water Tank Does Not Fill Brewer Does Not Start When Brew Button is Pressed Brewing Brewing Sensor Error Message...
- Page 36 TROUBLESHOOTING GUIDE Water Tank Does Not Fill IMPORTANT: Coffee/Tea Too Strong Dispenser Not Filled To Normal Level During Brewing Dispenser Not Filled To Normal Level During Brewing sure that the spray head is correctly aligned and that the tubing is routed properly to allow for maximum water...
- Page 37 TROUBLESHOOTING GUIDE All Of The Time No Water/Tea Flows From Brewer During Brewing Water Tank Does Not Fill Low Water Flow Warning Water Level Error Message Water Level Error Message...
- Page 38 TROUBLESHOOTING GUIDE Water Does Not Heat At All Check to see if the water level in the tank is in contact with the water level probe. If not, see Tank Does Not Fill. • The water will not heat unless it is in contact with the probe. If the water heats, but is not hot enough, see Water Not Hot Enough.
- Page 39 TROUBLESHOOTING GUIDE TG14 Warmer Does Not Heat NOTE coffee. First, check to make sure that the warmer function is not set to off in brewer program (warmers default). See the PROGRAMMING GUIDE section. Turn on power to the warmer that is not working. See the OPERATING INSTRUCTIONS to determine how the warmer operates for your model.
-
Page 40: Ec4
ERROR CODES System Fault Messages An error message will appear on the screen in the event of a malfunction under the following conditions: ERROR MESSAGE WARNING DESCRIPTION CAUSE Water Level Error G3 BREWER, ERROR CODES 042017A... - Page 41 Return Merchandise Authorization (RMA): All returned equipment must be properly re-packaged in the original carton and received by Curtis within 45 days following the issuance of a RMA. NO UNITS OR PARTS WILL BE ACCEPTED WITHOUT A RETURN MERCHANDISE AUTHORIZATION (RMA).
