5-3-3. Using the Power Control Settings

Select Radio Triggering Mode and ControlTL
Radio System Preference within Custom Setting to use
the Power Control Function.
* Be sure to set the T (shutter speed) and ISO
sensitivity values desired in the Measuring screen
before adjusting power levels and metering the
controlled flash intensity.
1. Touch the Measuring mode icon to open the
Measuring Mode Selection screen, then touch
the icon to activate Radio Triggering Mode
and return the screen view to the Measuring
screen (See P25 for details.)
2. Touch the Power Control icon (
the Power Control screen.
3. Adjust flash intensity for ControlTL
* Please set the ControlTL
channels in advance. (See P39 for details.)
a. Touch the ControlTL
bottom to select A, B, C
b. The Power Bar
be activated as each Zone (A,B,C) is
selected. The current level appears at the
top of the bar.
c. Touch the +/- icons or slide finger up/
down on the slider to set values.
d. Repeat a to c above to select other zones and
set values.
e. Pressing the Measuring button on the side
of meter will display the F value (f-stop) for
each zone
set T (shutter speed) and ISO sensitivity
value.
f. The total F value (f-stop) for selected
zones will be displayed in item
g. Touch the
ON or OFF studio flash modeling lamps.
h. Touch the Radio Triggering Mode icon
to return to the Measuring screen.
4. In this screen, Zones of Standard CH can be
turned ON or OFF
32. If the standard CH is set to 1 to 16, receivers
are set to ON or OFF toggle the [CL] icon
5. Be sure the Channels and Zones are the same for
meter and the radio receivers in use.
)
and Standard
®
Zone buttons at the
®
6
.
4 3
and values
5
as measured value for the
7
modeling lamp icon
2
for the Channel from 17 to
under
®
1
to display
.
®
will
ControlTL
zone display
8
.
to turn
9
2
.
40
Measuring Screen
(Radio Trigger mode)
1
Power Control Screen
(ControlTL +
®
Standard 17~32 Channels)
3
4
5
6
Power Control Screen
(ControlTL +
®
Standard 1~16 Channels)
channel &
®
Measuring value (f-stop)
Setting
value
9
2
8
7
2
Standard
channel &
zone display
Percentage
of flash
