- Page 1 TV200 Model Vibration Pen Instruction Manual reedinstruments...
-
Page 2: Table Of Contents
Content 1. STRUCTURE ............3 2. -
Page 3: Structure
1. Structure 2. Operation • Push the sensor on the plane being tested while keeping TV200 perpendicular to it. Start the test by pressing the key. • After releasing the key, the LCD will show “HOLD”. The result of the release time will be held for about 40 seconds, and then the TV200 will turn off automatically. -
Page 4: Features
3. Features Tested parameter RMS of vibration velocity (mm/s) Range 0.1mm/s ~199.9mm/s Transmission band 10Hz~1kHz Accuracy ±5% ±2 Relative error 20Hz≤f≤1000Hz, ±10% of transmission 10Hz≤f<20Hz, +10% -20% Display 3 1/2 digits LCD refresh interval about 0.5 second Power supply two button batteries (LR44 or SR44) Battery capacity 10 hours continuously or 400 times testing Operation environment... -
Page 5: Warnings
20N. Also, the pen should be perpendicular to the plane. 5. Repair If any trouble occurs, user should not try to dismantle and repair it. REED Instruments can repair this instrument for you. For information contact us at info@reedinstruments.com. When shipping this product include the warranty card and the specimen provided and a statement explaining the problem (Excluding the non-warranty parts (see below). -
Page 6: Notes
7. Notes: • Class I is a small motor (less than 15Kw), class II is a medium motor (15Kw~75Kw), class III is a big motor (hard base), class IV is a big motor (soft base). • The result should be taken from three perpendicular directions of the bearing shell. 8. - Page 7 Class I Class II Class II Class IV Velocity (RMS) mm/s 0.28 0.45 excellent excellent 0.71 excellent excellent 1.12 good good good good 11.2 forbidden forbidden forbidden forbidden reedinstruments...
- Page 8 Notes ___________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ reedinstruments...
