Honeywell HSVR-16 User Manual

Honeywell hsvr-16 digital video recorder user manual
Hide thumbs Also See for HSVR-16:
Table of Contents

Advertisement

Quick Links

Honeywell
Honeywell HSVR-16

Digital Video Recorder

User Manual

© 2009 Honeywell International Inc. All rights reserved.
http://www.security.honeywell.com/
Rev. A

Advertisement

Table of Contents
loading

Related Manuals for Honeywell HSVR-16

Summary of Contents for Honeywell HSVR-16

  • Page 1: Digital Video Recorder

    Honeywell Honeywell HSVR-16 Digital Video Recorder User Manual © 2009 Honeywell International Inc. All rights reserved. http://www.security.honeywell.com/ Rev. A...

  • Page 3: Table Of Contents

    Honeywell Contents Welcome ................................ i Important Safeguards and Warnings......................ii 1 Features and Specifications........................1 Overview............................1 Features ............................1 Specification ............................2 2 Overview and Controls..........................5 Front Panel ............................5 Rear Panel............................6 Connection Sample ...........................7 Remote Controller..........................8 Mouse Control ...........................9 3 Installation and Connections........................12 Check Unpacked DVR........................12...
  • Page 4 Honeywell Auto Resume after Power Failure.....................20 Replace Button Battery......................20 Manual Record ..........................20 Live Viewing ..........................20 Manual Record .........................20 Search & Playback ..........................22 Search Menu ..........................22 Basic Operation ........................23 Calendar ...........................24 Schedule............................25 Schedule Menu.........................25 Detect ..............................26 Go to Detect Menu ........................26 Motion Detection........................26...
  • Page 5 Honeywell Schedule ..........................45 RS232 ............................45 Network ............................46 Alarm ............................53 Detect ............................53 Pan/Tilt/Zoom ...........................53 Display............................54 Default ............................56 Search .............................57 Advanced............................57 HDD Management........................58 Abnormity ..........................59 Alarm Output ..........................59 Manual Record .........................60 Account ............................60 Auto Maintain..........................61 TV Adjust ..........................61 Information............................62 HDD Information........................62 BPS ............................63 Log ............................64...
  • Page 6 Honeywell 8 Appendix...............................111 HDD Capacity Calculation ......................111 Compatible USB Drive List ......................112...

  • Page 7: Welcome

    Honeywell Welcome Thank you for purchasing our DVR! Please refer to this user’s manual for the installation and operation of HSVR-16. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.

  • Page 8: Important Safeguards And Warnings

    Honeywell Important Safeguards and Warnings 1. Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.

  • Page 9: Features And Specifications

    Honeywell 1 Features and Specifications Overview HSVR-16 is an excellent digital video surveillance product. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detail analysis. It has various functions such as record, playback, monitor at the same time and can guarantee audio video synchronization.

  • Page 10: Specification

    Support Pelco-D protocol to allow the PTZ to control the speed dome. • Intelligent operation Support USB Mouse operation function In the menu, support copy and paste for settings. Specification Parameter HSVR-16 Main Processor High-performance industrial embedded micro controller Embedded LINUX System Multiplex operations: simultaneous 16-channel recording, 16-channel Resources...
  • Page 11 Honeywell PAL/NTSC Real-time monitor： 704×576/704×480 Playback： Resolution Channel1: D1 704×576/704×480, CIF 352×288/ 352×240, QCIF (PAL/NTSC) 176×144/176×120 Channel9 : D1 704×576/704×480, CIF 352×288/ 352×240, QCIF 176×144/176×120 Other channels: CIF 352×288/ 352×240, QCIF 176×144/176×120 Support dual streams: extra stream resolution QCIF 176×144/176×120 Zone setup: support max 396(22×18) zones.
  • Page 12 Honeywell Duplex transparent COM Intercom Zone setup: support 396(22×18) detection zones. Various sensitivity levels Motion Detection Can activate recording or external alarm or screen message prompt in specified period. Video Loss Alarm can activate external alarm or screen message prompt.

  • Page 13: Overview And Controls

    DVR for the first time, please refer to this part first. Front Panel The front panel is shown in Figure 2-1. Figure 2-1 The Front Panel of HSVR-16 Please refer to the following sheet for front panel button information. Name Icon Function...

  • Page 14: Rear Panel

    System is recording or not. It becomes on when system is Record light Alarm recording. IR Receiver It is to receive the signal from the remote control. Rear Panel HSVR-16 rear panel is shown as below. See Figure 2-2. Figure 2-2 The Rear Panel of HSVR-16...

  • Page 15: Connection Sample

    Honeywell Please refer to the following table for detailed information. Description Video input Audio input Video CVBS output Audio output Network port USB port HDMI port RS232 port Video VGA output Alarm input/alarm output/RS485 port Power input port Power button When connect the Ethernet port, please use straight cable to connect the PC and use the crossover cable to connect to the switcher or router.

  • Page 16: Remote Controller

    Honeywell Figure 2-3 Device Connection Remote Controller The remote controller interface is shown as in Figure 2-4. Figure 2-4 Remote Controller...

  • Page 17: Mouse Control

    Honeywell Serial number Function Record search Multiple-window switch 0-9 number keys ESC, Cancel Reserved, not effective for HSVR-16 Confirm /menu key Direction keys Auxiliary function key Remote address switch Previous Backward playback Slow play Play/Pause Fast play Next Record Mouse Control System pops up password input dialogue box if you have not logged in.
  • Page 18 Honeywell In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character.
  • Page 19 Honeywell Page up or page down Move mouse Select current control or move control Select motion detection zone Drag mouse Select privacy mask zone.

  • Page 20: Installation And Connections

    Honeywell 3 Installation and Connections All the installation and operations here should conform to your Note local electrical safety rules Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.

  • Page 21: Connecting Power Supply

    Honeywell 4. Place the HDD in accordance 5. Turn the device upside down 6. Fix the HDD firmly. with the four holes in the chassis. and then turn the screw in firmly. 7. Connect the HDD cable and 8. Place the upper cover back power cable.

  • Page 22: Connecting Video Output

    Honeywell If the distance is too long, you should use twisted pair cable, and you can add video compensation devices or use optical fiber to ensure video quality. You should keep the video signal away from the strong electromagnetic interference, especially the high tension current.

  • Page 23: Alarm Input And Output Connection

    Honeywell Alarm Input and Output Connection Please refer to the following sheet for alarm input and output connection. There are two alarm input types for you to select: normal open (NO) and normal close (NC). 1. Alarm input Please make sure alarm input mode is grounding alarm input.

  • Page 24: Alarm Output Port

    Use the same ground with that of DVR if you use external power to the alarm device. Only indoor devices are recommended being connected to Note HSVR-16 alarm inputs. Figure 3-2 Sample of Alarm Input (Normal Close Type) Alarm Output Port •...

  • Page 25: Rs232

    Honeywell Temperature +70 ℃ ℃ RS232 RS232 port is reserved for technical support diagnosis and upgrade. RS485 When the DVR receives a camera control command, it transmits that command up the coaxial cable to the PTZ device. RS485 is a single-direction protocol; the PTZ device can’t return any data to the unit.

  • Page 26: Overview Of Navigation And Controls

    Honeywell 4 Overview of Navigation and Controls Before operation, please make sure you have properly installed HDD and all the cable connections. Login, Logout & Main Menu Login After system booted up, default video display is in multiple-window mode. Click Enter or left click mouse, you can see the login interface. See Figure 4-1.

  • Page 27: Logout

    Honeywell There are total six icons: search, information, setting, backup, advanced and shutdown. You can move the cursor to highlight the icon, and then double-click mouse to enter the sub-menu. Figure 4-2 Main Menu Logout There are two ways for you to log out.

  • Page 28: Auto Resume After Power Failure

    Honeywell Auto Resume after Power Failure The system can automatically backup video and resume previous working status after power failure. Replace Button Battery Please make sure to use the same battery model if possible. We recommend replace battery regularly (such as one-year) to guarantee system time accuracy.
  • Page 29 Honeywell • Automatic: Channel recording follows the set in recording schedule setup (Main Menu Setting Schedule) • Closed: the channel stops recording. Figure 4-5 Recording Control Menu Enable/disable recording in specified channels Please check current channel status: “○” means it is not in recording status, “●”...

  • Page 30: Search & Playback

    Honeywell • Manual recording in all channels Highlight “ALL” after “Manual.” See Figure 4-8. When system is in manual recording, all scheduled set up you have set in will be null (Main menu Setting Schedule). You can see indication light in front panel turns on, system begins manual record now.

  • Page 31: Basic Operation

    Honeywell Figure 4-10 Record Search Menu Please refer to the following sheet for more information. Serial Number Function Play Backward Stop Slow play Fast play Previous frame Next frame Volume Previous file Next channel Next file Previous channel Search Backup...

  • Page 32: Calendar

    Honeywell Input time (h/m/s) in the time column and then click playback button, system can operate accurate playback. Synchronized playback function when playback During playback process, click numeral key, system can switch to the corresponding channel video of the same time.

  • Page 33: Schedule

    Honeywell The highlighted date means there are record files in that day. You can click blue date to view file list. 4-11, there are video files in March 13th and 14th. Double-click the date Figure to view file list. Figure 4-11 Sample of the Calendar Schedule After system booted up, it is in default 24-hour regular mode.

  • Page 34: Detect

    Honeywell Figure 4-12 Schedule Menu Quick Setup This function allows you to copy one channel setup to another. After setting one channel, you can click Copy button and switch to another channel and then click Paste button. You can finish setting one channel and then click Save button to keep the setting of that channel, or you can finish all setup and then click Save button to keep all the modified settings.
  • Page 35 Honeywell • Show message: System can pop up a message to alarm you in the local host screen if you enabled this function. • Send email: System can send out email to alert you when alarm occurs. • PTZ activation: Here you can set PTZ movement (of any video channels) such as going to a preset when motion is detected in current video channel.
  • Page 36 Honeywell Figure 4-14 Motion Detection Zone Setting Figure 4-15 PTZ Activation Setting Figure 4-16 Armed Period Setting...

  • Page 37: Video Loss

    Honeywell Figure 4-17 Business Day and Non-Business Day Setting Video Loss 4-13, select “Video Loss” from the type list. You can see the interface is Figure shown in 4-18. This function allows you to be informed when video loss Figure phenomenon occurred.

  • Page 38: Alarm Setup And Alarm Activation

    Honeywell In “Detect” interface, copy/paste function is only valid for the Note same type, which means you can not copy a channel setup in video loss mode to camera masking mode. Figure 4-19 Menu of Camera Masking Alarm Setup and Alarm Activation Before operation, make sure you have properly connected alarm devices such as buzzer.
  • Page 39 Honeywell • Record channel: You can select proper channel to record alarm video (Multiple choices). At the same time you need to set alarm recording in schedule interface (Main Menu Setting Schedule) and select automatic record in manual record interface (Main Menu Advance Manual Record).

  • Page 40: Backup

    Honeywell Figure 4-22 Period Setup Figure 4-23 The Settings of Business Day and Non-Business Day Backup DVR support various backup devices such as CD-RW, DVD driver, USB backup and network download. The records can be played in PC by Record Player in the CD.

  • Page 41: Backup

    Honeywell Figure 4-24 Device Detection Menu of Backup Backup Select backup device and then set channel, file start time and end time. Click Add, and system begins searching. All matched files are listed below. System automatically calculates the capacity needed and remained. See Figure 4-25.

  • Page 42: Ptz Control And Color Setup

    PTZ Control and Color Setup The operations described here are mainly based on Note PELCO-D protocol for Honeywell HSPT-120 speed dome. For other protocols, there might be a little difference. Cable Connection Please follow the procedures below to go on cable connection •...

  • Page 43: Ptz Setup

    Honeywell PTZ Setup The camera video should be in the current screen. Before setup, check whether the following connections are right: • PTZ and decoder connection is right. Decoder address setup Note is right. • Decoder A (RS485 +) / B (RS485 -) line connects with DVR A/B line.

  • Page 44: Ptz Trace

    Honeywell Figure 4-28 The Context Menu Click Pan/Tilt/Zoom, and the interface is shown as below. See Figure 4-29. Here you can set the following items: Step: value ranges from 1 to 8. • 8 direction arrows for PTZ position adjustment •...

  • Page 45: Preset/Tour/Pattern/Scan Operations

    Honeywell Here is a table of front panel key functions in PTZ operation for your reference. Function Shortcut Function Shortcut Name function function Zoom Near Focus Near │ ►│ Iris close Open ► Preset/Tour/Pattern/Scan Operations 4-29, click Set. The interface is shown as below. See...

  • Page 46: Preset Setup

    Honeywell Figure 4-31 Function Menu Preset, tour and pattern all need the value to be the control • parameter. You can define it as you require. You need to refer to your speed dome user’s manual for • Note auxiliary function definition. In some cases, it can be used for special process.

  • Page 47: Patrol Setup (Tour Setup)

    Honeywell Patrol setup (Tour Setup) 4-30, click Patrol. The interface is shown in 4-33. Input the preset Figure Figure number and add this preset to a patrol (tour). For each patrol (tour), you can input 80 presets at most. Figure 4-33 Tour Setup Activate Patrol (tour) 4-30, input patrol (tour) number in the No.

  • Page 48: Auto Scan Setup

    Honeywell Auto Scan Setup 4-30, click Border. The interface is shown in Figure Figure 4-27. Please go to 4-29, use direction arrows to select camera left limit. Figure Then please go to and click left limit button Figure 4-35 Repeat the above procedures to set right limit.

  • Page 49: Understanding Of Menu Operations And Controls

    Honeywell 5 Understanding of Menu Operations and Controls Menu Tree This series DVR menu tree is shown as below. Search Information HDD Info Version Online Users Setting General Encode Schedule RS232 Menu Network Alarm Detect Pan/ Tilt/Zoom Display Default Backup...

  • Page 50: Main Menu

    Honeywell Main Menu After you logged in, the system main menu is shown as below. See Figure 5-1. There are totally six buttons: Search, Info, Setting, Backup, Advanced, and Shutdown. Move the cursor to highlight the icon, then double-click to enter the sub-menu.
  • Page 51 Honeywell Pack duration: Here is for you to specify maximum length of each record file • from 1 to 120 minutes. Default value is 60 minutes. The change will take effect in the new record file. DVR No: When you are using one remote control to control several DVRs, you •...

  • Page 52: Encode

    Honeywell Encode Encode setting includes the following items. See Figure 5-5. Note that some series do not support extra stream. Channel: Select the channel you want. • Compression: System supports H.264. • Resolution: System supports various resolutions, you can select from the •...

  • Page 53: Schedule

    Honeywell Figure 5-5 Encode Menu Figure 5-6 Overlay Menu Schedule Refer to on page 25. Schedule RS232 RS232 interface is shown as follows. There are five items. See Figure 5-7. Function: There are two modes for you to select. Console is for serial port or •...

  • Page 54: Network

    Honeywell Data bit:8 • Stop bit:1 • Parity: None • After completing all the settings, click Save, and the system goes back to the previous menu. Figure 5-7 The RS232 Setup Menu Network Here is for you to input network information. See Figure 5-8.

  • Page 55: Advanced Setup

    Honeywell Figure 5-8 Network Setup Menu Advanced Setup Advanced setup interface is shown as in 5-9. Draw a circle to enable the Figure corresponding function and then double-click the current item to go to the setup interface. Figure 5-9 Advanced Settings...

  • Page 56: Ntp Setup

    Honeywell Figure 5-10 IP Filter Menu PPPoE PPPoE interface is shown in Figure 5-11. Input “PPPoE name” and “PPPoE password” you get from your ISP (Internet service provider). Click Save, you need to restart to activate your configuration. After rebooting, DVR will connect to internet automatically. The IP in the PPPoE is the DVR dynamic value.

  • Page 57: Ddns Setup

    Honeywell City/Region Name Time Zone London GMT+0 Berlin GMT+1 Cairo GMT+2 Moscow GMT+3 New Deli GMT+5 Bangkok GMT+7 Beijing (Hong Kong) GMT+8 Tokyo GMT+9 Sydney GMT+10 Hawaii GMT-10 Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7 American Central Time(C.T) GMT-6 American Eastern Time(E.T)
  • Page 58 Note that the NNDS type includes: CN99 DDNS、NO-IP DDNS、Private DDNS、Dyndns DDNS and sysdns DDNS. Private DDNS function is reserved for integration, and currently is not effective on HSVR-16 You need to download or buy FTP service tool (such as Ser-U FTP SERVER) to establish FTP service.
  • Page 59 Honeywell Figure 5-15 The FTP Login Window System also supports upload multiple DVRs to one FTP server. You can create multiple folders under this FTP. 5-8, select FTP and then double-click mouse. You can see the following Figure interface. See Figure 5-16.
  • Page 60 Take Google Mail for example: the Gmail SMTP server URL is known as smtp.google.com. On a PC of Windows OS in the same LAN of HSVR-16, open the Windows • Command Prompt by entering “cmd” in Start Run and click OK.

  • Page 61: Alarm

    Honeywell Figure 5-18 The Command Window Alarm Refer to on page 30. Alarm Setup and Alarm Activation Detect Refer to on page 26. Detect Pan/Tilt/Zoom The pan/tilt/zoom setup includes the following items. Please select channel first. Figure 5-19. Protocol: Select corresponding PTZ protocol such as PELCOD.

  • Page 62: Display

    Honeywell Figure 5-19 The PTZ Setup Menu Display Display setup interface is shown as below. See Figure 5-20. Transparency: Here is for you to adjust transparency. The value ranges from • 128 to 255. Channel name: Here is for you to modify channel name. System max support •...
  • Page 63 Honeywell Figure 5-20 The Display Setup Menu 5-20, click Modify after channel. You can see an interface shown in Figure 5-21. Note that all your modification here applies to local end only. You need Figure to refresh web or client-end to get the latest channel name. System max support 25-digital character.

  • Page 64: Default

    Honeywell Figure 5-22 The Sample of Tour Mode Default Click Default, the system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 5-23. Select all • General • Encode • Schedule • RS232 •...

  • Page 65: Search

    Honeywell Figure 5-23 The Default Setup Menu Search Refer to on page 22. Search & Playback Advanced Double-click Advanced on the main window, and the interface is shown as follows. 5-24. There are totally seven function keys: HDD management, alarm Figure output, abnormity, manual record, account, auto maintenance, and TV adjust.

  • Page 66: Hdd Management

    Honeywell HDD Management Here is for you to view and implement hard disk management. See Figure 5-25. You can see current HDD type, status, capacity and record time. You can select HDD mode from the dropdown list such as read-only or you can erase all data in the HDD.

  • Page 67: Abnormity

    Honeywell Abnormity Abnormity interface is shown as in Figure 5-27. Event type: There are several options for you such as disk error, no disk and etc. • Alarm output: alarm activation output port (multiple choices). The 3-ch is • controllable 12V output.

  • Page 68: Manual Record

    Honeywell Figure 5-28 The Alarm Output Setup Menu Manual Record Refer to on page 20. Manual Record Account Here is for you to implement account management. See 5-29. Here you can: Figure Add new user • Modify user • Add group •...

  • Page 69: Auto Maintain

    Honeywell Figure 5-29 The Account Management Menu Auto Maintain Here you can set auto-reboot time and auto-delete old files setup. See Figure 5-30. You can select proper setup from dropdown list. After all the setups please Save, and the system goes back to the previous menu.

  • Page 70: Information

    Honeywell Figure 5-31 The TV Adjust Menu Information Here is for you to view system information. There are total five items: HDD (hard disk information), BPS (data stream statistics), Log and version, and online user. Figure 5-32. Figure 5-32 The Info Menu HDD Information Here is to list hard disk type, total space, free space, video start time and status.

  • Page 71: Bps

    Honeywell Once there is a hard disk confliction, please check hard disk time and system time is the same or not. Please go to setting then general to modify system time. At last, reboot the system to solve this problem.

  • Page 72: Log

    Honeywell Figure 5-34 The BPS Display Menu Here is for you to view system log file. System lists the following information. See Figure 5-35. Log types include system operation, configuration operation, data management, alarm event, record operation, log clear and etc.

  • Page 73: Version

    Honeywell Version Here is for you to view some version information. See Figure 5-36. Channel • Alarm in • Alarm out • System version: • Build Date • Figure 5-36 The Version Menu Online Users Here is for you manage online users. See Figure 5-37.

  • Page 74: Shutdown

    Honeywell Figure 5-37 The Online Users Menu Shutdown Double click shutdown button, system pops up a dialogue box for you to select. Figure 5-38. Logout menu user: log out menu. You need to input password when you login • the next time.

  • Page 75: Web Client Operation

    Honeywell 6 Web Client Operation All the operations here are based on our 16-ch DVR. • Note There might be slightly difference in the interface due to • different series. Network Connection Before the web client operation, please check the following items: Network connection is right •...
  • Page 76 Honeywell Figure 6-1 Sample of IE Login Input your IP address here. System pops up warning information to ask you whether install webrec.cab control or not. Please click yes button. If you can’t download the ActiveX file, please modify your settings as follows. See...
  • Page 77 Honeywell Figure 6-3 The Settings for ActiveX After installation, the interface is shown as below. See Figure 6-4. Please input your user name and password. Default factory name is admin and password is admin. For security reasons, please modify your password after you Note first login.
  • Page 78 Honeywell Section 1: there are five function buttons: configuration (chapter 7.3), search • (chapter 7.4), alarm (chapter 7.5), about (chapter 7.6), log out (chapter 7.7). Section 2: there are channel number and three function buttons: start dialog and • local play, refresh.

  • Page 79: Real-Time Monitor

    Honeywell Real-Time Monitor In section 2, left click the channel name you want to view, you can see the corresponding video in current window. On the top left corner, you can view device IP, channel number, network monitor bit stream.
  • Page 80 Honeywell Figure 6-10 Switch between the Main Stream and Extra Stream Open All You can click it to open all channels. Refresh You can use button to refresh camera list. Start Dialogue You can click this button to enable audio talk.

  • Page 81: Ptz

    Honeywell Figure 6-11 Selection Menu of Local Play File Before PTZ operation, make sure you have properly set PTZ protocol. (Please refer to chapter 6.3.2 Setting-> Pan/Tilt/Zoom). Click PTZ, and the interface is shown as in Figure 6-12 Figure 6-12 PTZ Control Menu...

  • Page 82: Auto Scan

    Honeywell Speed System supports eight-level speed. You can select from the dropdown list. Speed 2 is faster than speed 1. Zoom/Focus/Iris Here is a sheet for you reference. Name Function key Function Function key Function Zoom Near Focus Near Iris...

  • Page 83: Color

    Honeywell Auto tour 6-13, input auto tour value and preset value. Click add button, you have Figure added one preset in the tour. Repeat the above procedures you can add more presets in one tour. Assistant You can select the assistant item from the dropdown list. See Figure 6-14.

  • Page 84: Picture Path And Record Path

    Honeywell Picture Path and Record Path Click “More” in 6-15, and you can see an interface shown in Figure Figure 6-16. Figure 6-16 The More Setup Menu Click PIC Path, and you can see an interface shown in Figure 6-17.

  • Page 85: Configure

    Honeywell Configure System Information Version Information Here you can view device hardware feature and software version information. See Figure 6-20. Figure 6-20 Version Information Menu HDD information Here you can view local storage status and network status including, free capacity and total capacity.
  • Page 86 Honeywell Figure 6-21 HDD Information Menu Here you can view system log. See Figure 6-22. Figure 6-22 Log Information Menu Click Backup, and the interface is shown in Figure 6-23.

  • Page 87: System Configuration

    Honeywell Figure 6-23 Log Backup Menu Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type management, alarm event, record operation, user management, log clear and file operation. You can select log type from the drop-down list and then click Search to view Search the list.
  • Page 88 Honeywell Figure 6-24 General Setup Menu Figure 6-25 DST Setup Menu (Date) Figure 6-26 DST Setup Menu (Week) Please refer to the following table for detailed information.
  • Page 89 Honeywell Parameter Function Here is for you to modify system time. Please click Save after your System Time completed modification Sync PC You can click this button to save the system time as your PC current time. Data Format Here you can select data format from the dropdown list.
  • Page 90 Honeywell Figure 6-28 The Color Setting Menu Please refer to the following table for detailed information. Parameter Function Channel Here is for you to select a monitor channel. Channel Name Here is to display current channel name. You can modify it.
  • Page 91 Honeywell Parameter Function You can enable this function so that system overlays channel information in video window. Channel Title OSD transparent value is not applicable in current DVR version. You can use the mouse to drag the channel title position.
  • Page 92 Honeywell Figure 6-30 The Schedule Setup Menu Figure 6-31 The Date and Time Setup Menu Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel first. Please input pre-record value here. Pre-record System can record the three to five seconds video before activating the record operation into the file.
  • Page 93 Honeywell Parameter Function the current time period setup. It is a shortcut menu button. You can copy current channel setup to one or more Copy (all) channels. The interface is shown as in Figure 6-29. You can click Save after you complete setup for one channel, or you can Save complete the whole setups and then click Save.
  • Page 94 Honeywell Parity: None. • Network The network interface is shown as in Figure 6-33. Figure 6-33 The Network Setup Menu Please refer to the following sheet for detailed information. Parameter Function Ethernet Please select the network card first. Dynamically get IP address. You can get the device IP from the DHCP DHCP server if you enabled this function.
  • Page 95 Honeywell Figure 6-34 The Email Setup Menu Please refer to the following sheet for detailed information. Parameter Function SMTP Server Input server address and then enable this function. Port Default value is 25. You can modify it if necessary. User Name The sender email account user name.
  • Page 96 Honeywell Figure 6-35 The DDNS Setup Menu Please refer to the following sheet for detailed information. Parameter Function You can select DDNS protocol from the dropdown list and then enable Server Type DDNS function. The private DDNS protocol means you use your self- defined private protocol to realize DDNS function.
  • Page 97 Honeywell Figure 6-36 The NAS Setup Menu Please refer to the following sheet for detailed information. Parameter Function Please select network storage protocol and then enable NAS NAS enable function. Server IP Input remote storage server IP address. Port Input Remote storage server-port number.
  • Page 98 Honeywell Figure 6-37 The NTP Setup Menu Alarm Alarm setup interface is shown as in Figure 6-38. Figure 6-38 The Alarm Setup Menu Please refer to the following sheet for detailed information. Parameter Function It includes local alarm/network alarm. Event Type Local alarm: Device detects alarm from input port.
  • Page 99 Honeywell Parameter Function Enable You need to draw a circle here so that system can detect the alarm signal. There are two options: normal open and normal close. NO becomes activated in Type low voltage, NC becomes activated in high voltage.
  • Page 100 Honeywell Figure 6-39 The Detection Setup Menu Figure 6-40 The Detection Zone Setup Please refer to the following sheet for detailed information. Parameter Function Event Type There are three types: Motion detection/video loss/Camera Masking. Channel Select channel name from the dropdown list.
  • Page 101 Honeywell Motion detection function becomes activated in the specified periods. There are six periods in one day. Please draw a circle to enable corresponding period. Period Select date. If you do not select, current setup applies to today only. You can select all week column to apply to the whole week.
  • Page 102 Honeywell Figure 6-41 The PTZ Setup Menu Please refer to the following sheet for detailed information. Parameter Function Channel You can select monitor channel from the dropdown list. . Protocol Select the corresponding dome protocol.(such as PELCOD) Set corresponding dome address. Default value is 1. Please note your setup here shall comply with your dome address;...

  • Page 103: Advanced

    Honeywell Figure 6-42 The Default Setup Menu Please refer to the following sheet for detailed information. Parameter Function Select All Restore the factory default settings. Export Configuration Export system configuration to the local PC. Import Configuration Import configuration from PC to the system.
  • Page 104 Honeywell Figure 6-43 The HDD Management Menu Please refer to the following sheet for detailed information. Parameter Function Format Clear data in the disk. Read/write Set current SD card as read/write Read only Set current card as read. Recover Recover dada after error occurs.
  • Page 105 Honeywell Figure 6-44 The Alarm Out Menu Please refer to the following sheet for detailed information. Parameter Function Alarm output There are three output channels. Save You can click save button after you complete Refresh Search alarm output status. Record...

  • Page 106: Auto Maintenance

    Honeywell Parameter Function Schedule System enables the auto record function as you set in record schedule setup. (Auto) Enable corresponding channel to record no matter what period applied in the Manual record setup. Stop Stop current channel record no matter what period applied in the record setup.
  • Page 107 Honeywell Figure 6-47 The Auto Maintain Menu Abnormity The abnormity interface is shown as below. Figure 6-48 The Abnormity Setup Menu Please refer to the following sheet for detailed information. Parameter Function The abnormal events include: no disk,disk no space, disk error, net eeror.

  • Page 108: Search

    Honeywell The alarm output can delay for the specified time after alarm stops. Then system disables alarm and corresponding activation output. Latch The value ranges from 10s to 300s. Send email If you enable this function, system can send out email to alarm the specified user.
  • Page 109 Honeywell Figure 6-50 The Record Save Menu Now you can see the system begins to download and the Download button changes to the Stop button. You can click it to terminate current operation. At the bottom of the interface, there is a process bar for your reference. See Figure 6-51.
  • Page 110 Honeywell Type Parameter Function Record Search general record, alarm record and motion detection record. Alarm Search alarm record. Motion Search motion detection record. Detection Type Local Search local record. Snapshot Search snapshot file. Card This function is not available in current device.

  • Page 111: Alarm

    Honeywell Figure 6-53 The Playback Menu The IP address of playback device and channel number. Playback control bar Alarm Click alarm function, and you can see an interface is shown in Figure 6-54. Here you can set device alarm type and alarm sound setup.

  • Page 112: About

    Honeywell Please refer to the following table for detailed information. Type Parameter Function Video loss System alarms when video loss occurs. Motion detect System alarms when motion detection alarm occurs, Disk full System alarms when disk is full. Alarm Type Disk error System alarms when disk error occurs.

  • Page 113: Un-Install Web Control

    Honeywell Figure 6-56 The Logout Interface Un-install Web Control You can use web un-install tool “uninstall webrec.bat” in the CD to un-install web control. Before un-installation, please close all web pages, otherwise the Note un-installation might result in error.

  • Page 114: Faq

    Honeywell 7 FAQ 1. DVR can not boot up properly. There are following possibilities: Input power is not correct. • Power connection is not correct. • Power switch button is damaged. • Program upgrade is wrong. • HDD malfunction or something wrong with HDD ribbon.
  • Page 115 Honeywell 5. Real-time video color is distorted. There are following possibilities: When using BNC output, NTSC and PAL setup is not correct. The real- • time video becomes black and white. DVR and monitor resistance is not compatible. • Video transmission is too long or degrading is too huge.
  • Page 116 Honeywell 10. Time display is not correct. There are following possibilities: Setup is not correct • Battery contact is not correct or voltage is too low. • Crystal is broken. • 11. DVR can not control PTZ. There are following possibilities: Front panel PTZ error •...
  • Page 117 Honeywell Client-end resources are limit. • There is multiple-cast group setup in DVR. This mode can result in mosaic. • Usually we do not recommend this mode. There is privacy mask or channel protection setup. • Current user has no right to monitor.
  • Page 118 Honeywell Alarm setup is not correct. • Alarm cable connection is not correct. • Alarm input signal is not correct. • There are two loops connect to one alarm device. • 20. Remote control does not work. There are following possibilities: Remote control address is not correct.

  • Page 119: Appendix

    Honeywell 8 Appendix HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). 1. According to formula (1), calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 120: Compatible Usb Drive List

    Honeywell Compatible USB Drive List Please upgrade the DVR firmware to latest version to ensure the Note accuracy of the table below. If you use the USB drive, please confirm the format FAT or FAT32. Manufacturer Model Capacity Sandisk Cruzer Micro...
  • Page 121 35F Tower A, City Center, 100 Zun Yi Road, Shanghai 200051, China TEL +86 21 52574568 FAX +86 21 62370740 Honeywell Security (China) Co., Ltd. Building 9 Tower B, Huaide Industrial Zone, Fuyong Town, Baoan District, Shenzhen, China TEL +86 0755 27326500 FAX +86 0755 27391736 ©...
