- Page 1 ANUAL AND UIDE ONE 2 ONE Tour Guide System ™ Wireless, Portable FM Listening System Model TGS 100 Transmitter Model T1-216 Receiver Model R1-216 MAN 094D...
-
Page 3: Table Of Contents
ONE 2 ONE ™ FM T TGS 100 UIDE YSTEM ODEL & U NSTALLATION UIDE ANUAL Contents Page YSTEM VERVIEW YSTEM OMPONENTS T1-216 T RANSMITTER ICROPHONES R1-216 R ECEIVER & E EADPHONES ARPHONES AFETY NFORMATION ECYCLING NSTRUCTIONS PERATING NSTRUCTIONS T1-216 T... -
Page 4: System Overview
YSTEM VERVIEW The ONE 2 ONE ™ Tour Guide System is a portable, high-performance, wireless system composed of the T1-216 Transmitter and R1-216 Receivers and designed for use in guided tour applications. The system allows one-way transmission of a tour guide’s voice to group members using an FM radio signal. -
Page 5: System Components
YSTEM OMPONENTS Body Pack Transmitter (T1-216) with (2) AA batteries (BAT 001) Noise-cancelling headband microphone (MIC 086) (6) Personal FM Receivers (R1-216) w/batteries (BAT 001) and headphones (HED 021) (7) Belt clip cases (CCS 001) Instruction Manual (MAN 094) System carry case (CCS 030 S) T1-216 T RANSMITTER The T1-216 Transmitter is a battery-powered body-pack model used with a microphone to pick up... -
Page 6: Headphones & Earphones
EADPHONES AND ARPHONES The HED 021 Lightweight Headphone is the standard headset for the Tour Guide System. It offers excellent sound quality and wearing comfort. The foam earpads may be removed and washed in a mild detergent, rinsed thoroughly, and air dried. Replacement pads (HED 013) are available. The headphone plugs into the “EAR”... -
Page 7: Safety Information
ATTERY AFETY AND ISPOSAL Help Williams Sound protect the environment! Please take the time to dispose of your equipment properly. Product Recycling for Customers in the European Union: Please do NOT dispose of your Williams Sound equipment in the household trash. -
Page 8: Perating Nstructions
On/Off Switch Jack ON Indicator Williams Sound FM 4. Turn the power switch on top of the transmitter to “On.” 5. Position the Headset Microphone boom as close to the wearer's mouth as possible without actually touching. Lapel Clip microphones should be attached to a collar or lapel, as close to the wearer's mouth as possible. -
Page 9: R1-216 Receiver
R1-216 R SING THE ECEIVER Note: Rechargeable batteries are shipped in a discharged state and must be charged overnight before using. 1. Make sure there are two charged AA batteries in the Receiver. If batteries are not installed, see Battery Information on page 11. 2. - Page 10 INTS FOR SING THE YSTEM Normal operating distance between the transmitter and receiver is about 30 meters. The operating range will vary in different buildings and surroundings. In some locations, the signal may momentarily disappear. This is called a “drop-out” and is due to reflection and cancellation of the radio signal.
-
Page 11: Battery Installation
The battery installed in the receiver may be recharged in the receiver only if it is a NiMH battery, and only if a Williams Sound CHG 1600 Multi-Charger is used. Damage from improper charging is not covered by the Williams Sound five year warranty. - Page 12 Units may be fully charged before the green “Complete/Maintain” indicator is lit. Units may remain in the CHG 1600 Multiple Charger for more than 15 hours without harm. Williams Sound rechargeable AA batteries can be charged on a daily or less frequent basis.
- Page 13 The batteries may heat up and burst, causing possible injury and damage to the equipment. Avoid shorting the plus and minus battery terminals together with metal objects. Battery damage and burns can result! Use only Williams Sound supplied chargers and batteries.
-
Page 14: I N Case O F Difficulty
Call your Williams Sound at 1-800-328-6190 for details. OTICE Williams Sound Corp. assumes no liability for improper use or operation of this equipment. The user is cautioned to operate the volume controls at the lowest acceptable level, and in a manner that will not cause damage to hearing. -
Page 15: Compliance
OMPLIANCE This transmitter is authorized by rule under the Low Power Radio Service (47 C.F.R. Part 95) and must not cause harmful interference to TV Reception or United States Navy SPASUR installations. You do not need an FCC license to operate this transmitter. This transmitter may only be used to provide: auditory assistance to persons with disabilities, persons who require language translation, or persons in educational settings;... -
Page 16: Limited Warranty
LIMITED WARRANTY Williams Sound products are engineered, designed, and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the ONE 2 ONE ™ Tour Guide System against defects in materials and workmanship for FIVE (5) years. During the first five years from the purchase date, we will promptly repair or replace the ONE 2 ONE ™... -
Page 17: Warranty
YSTEM PECIFICATIONS FM T T1-216 RANSMITTER ODEL Dimensions: 3-5/8" L x 2-3/8" W x 7/8" H (92.1 mm x 60.3 mm x 22.2 mm) Weight: 4.4 oz (125 g) with batteries Color: Neptune blue, shatter-resistant polypropylene Battery Type: Two (2) AA 1.5 V Non-rechargeable Alkaline batteries (BAT 001), 120 mA nominal current drain, 8 hours approx. - Page 20 © 2006 Williams Sound Corp. MAN 094D...
