Operating instructions
Diaphragm Metering Pump
Makro TZ, TZMb
Two sets of operating instructions are required for the safe, correct and proper operation of the metering pumps: The
product-specific operating instructions and the "General Operating Instructions for ProMinent
pumps and hydraulic accessories".
Both sets of operating instructions are only valid when read together.
Please carefully read these operating instructions before use! · Do not discard!
The operator shall be liable for any damage caused by installation or operating errors!
Part no. 985741
Technical changes reserved.
Original Operating Instructions (2006/42/EC)
P_MA_0022_SW
®
motor-driven metering
BA MA 007 11/11 EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ProMinent TZ
Summary of Contents for ProMinent TZ
-
Page 1: Operating Instructions
Makro TZ, TZMb P_MA_0022_SW Two sets of operating instructions are required for the safe, correct and proper operation of the metering pumps: The product-specific operating instructions and the "General Operating Instructions for ProMinent ® motor-driven metering pumps and hydraulic accessories". - Page 2 ProMinent Dosiertechnik GmbH Im Schuhmachergewann 5-11 69123 Heidelberg Germany Telephone: +49 6221 842-0 Fax: +49 6221 842-617 email: info@prominent.com Internet: www.prominent.com 985742, 1, en_GB © 2002...
- Page 3 General user instructions Two sets of operating instructions are required for the safe, correct and proper operation of the metering pumps: The product-specific operating instructions and the "General Operating Instructions for ProMinent motor- ® driven metering pumps and hydraulic accessories".
-
Page 4: Table Of Contents
Table of contents Table of contents Identity code..................5 About this pump................7 Safety chapter................. 8 Storage, transport and unpacking..........13 Overview of equipment, control elements........15 Functional description..............17 Assembly..................20 Installation..................23 8.1 Installation, hydraulic............. 23 8.2 Installation, electrical............. 25 Start up.................. -
Page 5: Identity Code
With valve spring Hydraulic connector Standard connection Union nut and PVC insert Union nut and PP insert Union nut and PVDF insert Union nut and SS insert Version With ProMinent ® logo, no frame Without ProMinent ® logo With ProMinent ®... - Page 6 Identity code TZMb Makro/ 5 diaphragm metering pump 3 ph, 230 V/400 V 50/60 Hz (WBS) 3 ph, 230 V/400 V, 60 Hz, (Exe, Exd) 3 ph, 230 V/400 V 50 Hz (Exe, Exd) 4 pole, variable speed motor, 230/400 V V(0) Motor with integral frequency converter V(2)
-
Page 7: About This Pump
Externally mounted pumps The Makro TZ externally mounted metering pump can be combined with the Makro TZ main power end to form a double or multiple pump. A main power end can be combined with up to four add-on power ends. -
Page 8: Safety Chapter
The general limitations with regard to viscosity limits, chemical resist‐ ance and density must be observed - see also ProMinent resistance www.prominent.com )! list (In the product catalogue or at Any other uses or modifications are prohibited. - Page 9 Safety chapter The pump is not intended for the metering of gaseous media or solids. The pump is not intended for unprotected outside use. The pump is only approved to meter flammable liquids, if the operator takes appropriate safety measures. The pump should only be operated by trained and authorised per‐...
- Page 10 Service Customer Service department refers to service technicians, who have received proven training and have been authorised by ProMinent or Pro‐ Maqua to work on the system. Safety notes WARNING!
- Page 11 – Take into account the resistance of the materials which will come into contact with the chemical when selecting the feed chemical - see the ProMinent product catalogue www.prominent.com . or under CAUTION! Danger of personnel injury and material damage The use of untested third party parts can result in personnel injuries and material damage.
- Page 12 Safety chapter Sound pressure level Sound pressure level LpA < 70 dB in accordance with EN ISO 20361:2010-10 at maximum stroke length, maximum stroke rate, maximum back pressure (water)
-
Page 13: Storage, Transport And Unpacking
WARNING! The transporting of pumps which have been used with radio‐ active feed chemicals is forbidden! They will also not be accepted by ProMinent! WARNING! Only return metering pumps for repair in a cleaned state and with a flushed liquid end - refer to the section on decommis‐... - Page 14 Storage, transport and unpacking Store the pump in a dry, sealed place in the following ambient conditions. Ambient conditions Data Value Unit Minimum storage and transport tempera‐ -10 °C ture Maximum storage and transport tempera‐ +50 °C ture Maximum air humidity * 95 % rel.
-
Page 15: Overview Of Equipment, Control Elements
Overview of equipment, control elements Overview of equipment, control elements Power end, single head P_MA_0023_SW Fig. 3: Side view (here TZMb H) Drive Liquid end Vent screw Stroke length adjustment wheel Oil inspection window Motor Oil drainage screw Power end, double head P_MA_0024_SW Fig. - Page 16 Overview of equipment, control elements Liquid end P_MA_0025_SW Fig. 5: View of the liquid end Discharge valve Dosing head Diaphragm rupture sensor Suction valve Tube nozzle for leakage Protective cover...
-
Page 17: Functional Description
The adjustment of the stroke length takes place via a finely adjustable change to the eccentricity of the shift ring (TZ) (5) which influences the oscillating stroke movement. This drive principle ensures a harmonic, purely sinusoidal stroke movement for each stroke length adjustment. - Page 18 Functional description P_MA_0029_SW Fig. 7: Cross-section through the liquid end Discharge valve Metering diaphragm Dosing head Suction valve Diaphragm rupture signaller Diaphragm rupture warning system func‐ The diaphragm rupture warning system monitors the leak-tightness of the tional description multi-layer diaphragm. Together with the diaphragm rupture sensor and downstream analysis electronics, the multi-layer diaphragm forms the dia‐...
- Page 19 Functional description P_MA_0030_SW Fig. 8: Diaphragm rupture sensor: Cross-section view and multi-layer diaphragm Safety piston Diaphragm rupture signaller Expandable point...
-
Page 20: Assembly
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. CAUTION! Warning about personal and material damage Also observe the "General Operating Instructions for ProMi‐... - Page 21 Assembly WARNING! The pump can break through the supporting floor or slide off – The supporting floor must be horizontal, smooth and per‐ manently load-bearing. Capacity too low Vibrations can disturb the valves of the liquid end. The supporting floor must not vibrate. –...
- Page 22 Assembly Take the dimensions (m) for the fastening holes from the appropriate dimensional drawings or data sheets. Fasten the pump base to the supporting floor using suitable screws. P_MOZ_0015_SW Fig. 12 Instruction Screw the pump to a support surface with 4 sufficiently strong screws through the 4 holes in the frame.
-
Page 23: Installation
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. WARNING! - Page 24 Installation CAUTION! Suction problems possible For feed chemicals with a particle size greater than 0.3 mm, the valves may no longer close properly. – Install a suitable filter in the suction line. CAUTION! Warning against the discharge line bursting With a closed discharge line (e.g. due to a clogged discharge line or by closing a valve), the pressure that the metering pump generates can reach several times the permissible pressure of the system or the metering pump.
-
Page 25: Installation, Electrical
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. CAUTION! Warning about personal and material damage Also observe the "General Operating Instructions for ProMi‐... - Page 26 The terminal wiring diagram is located in the terminal – box. Notes on the speed controlled motor with external fan – and temperature monitoring can be found in the "Gen‐ eral operating instructions for ProMinent ® motor-driven metering pumps and hydraulic accessories"!
- Page 27 Installation The external fan requires an independent mains connection. Stroke sensor (Option) Connect the stroke sensor to a suitable monitoring device according to the details in the chapter "Technical Data". Also observe its tech‐ nical data. Other units Install the other units according to their documentation.
-
Page 28: Start Up
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. CAUTION! - Page 29 Start up Eliminating suction problems (only for single ball valves with PTFE ball seat) For suction problems occurring during start up: Exclude the possibility that there are foreign bodies in – the valve. Place the valve on a stable surface. –...
- Page 30 Start up Correctly adjusting the pump: Select as large a stroke length as possible for viscous feed chemicals. Select as large a stroke length as possible for outgassing feed chemi‐ cals. Select as high a stroke rate as possible for good mixing. For precise metering using quantity-proportional metering, do not set the stroke length to less than 30 %.
-
Page 31: During Use
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. WARNING! -
Page 32: Maintenance
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. WARNING! It is mandatory that you read the safety information and specifications in the "Storage, Transport and Unpacking"... - Page 33 Interval Maintenance work Quarterly* EX pumps only: For special maintenance work see chapter "Important supplements for metering pumps in hazardous locations" of the "General Operating Instructions for ProMinent ® motor-driven metering pumps and hydraulic accessories" Check the tightening torques for the dosing head screws (1) (30 Nm) and the drive flange screws (2) (25 Nm).
- Page 34 Maintenance Under heavy loading (e.g. continuous operation): Shorter intervals. ** under normal loading. With very unfavourable metering parameters: Shorter intervals. Changing the gear oil WARNING! Risk of burns due to hot gear oil The gear oil may become very hot when the pump is heavily loaded –...
- Page 35 Maintenance Start up the pump. Slowly pour gear oil through the vent screw (1) opening until the upper oil inspection window (3) is nearly covered. Allow the pump to run for a further 1... 2 minutes. Replace the vent screw (1).
-
Page 36: Repairs
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. WARNING! It is mandatory that you read the safety information and specifications in the "Storage, Transport and Unpacking"... -
Page 37: Replacing The Membrane
Repairs 12.1 Replacing the membrane WARNING! Observe the safety instructions at the beginning of the chapter. Flush the suction line, discharge lines and liquid end (activate flushing equipment or immerse suction lance in a suitable medium and pump for a while (consider the effect of the medium on your system first!)) or proceed, as described below. - Page 38 Repairs P_MA_0039_SW Fig. 19: Cross-section through the diaphragm rupture warning system Safety piston Spring Bushing O-ring Expandable point multi-layer diaphragm Undo the safety screw and remove the protective cover (5) from the backplate (6). Unscrew the diaphragm rupture signaller from the dosing head. Unscrew the bushing (3) from the dosing head.
-
Page 39: Repair The Diaphragm Rupture Sensor
Repairs Check the tightening torque of the screws after 24-hours' – operation. With PP dosing heads, recheck the tightening torque – again after three months. 12.2 Repair the diaphragm rupture sensor 12.2.1 30 V version 30 V version Check diaphragm rupture sensor When changing the diaphragm, unscrew the diaphragm rupture sensor from the dosing head. -
Page 40: Ex Version
Repairs 12.2.2 EX Version EX Version Check diaphragm rupture sensor When changing the diaphragm, unscrew the diaphragm rupture sensor from the dosing head. Check that the monitor does not indicate a diaphragm rupture: Using a blunt insulating probe (Ø 2 ... 3 mm, no sharp edges), press into the channel of the diaphragm rupture sensor. -
Page 41: Valve Repair
Use the correct spare part kits. In case of doubt, refer to – the exploded views and ordering information contained in the "Supplementary information CD for ProMinent ® pump operating instructions". Clean the discharge and suction valves only one after another as they cannot be differentiated using the arrow markings. -
Page 42: Single Ball Valves
Repairs Slide into the valve body (1) one after another: one seal (2) and one valve seat (3) - correct! one seal (2) and one valve bushing (4) (If fitted: one spring (*) into the spring guide of the valve seat (3) one ball (5) into the valve body (1) one seal (2) and the second valve seat (3, correct!) one seal (2) and the second valve bushing (4) -
Page 43: Plate Valves
Repairs Seal Valve body Valve ball Valve seat Valve cap P_MAK_0054_SW Fig. 23: Cross-section through the single ball valve 12.3.3 Plate valves Do not scratch the finely machined sealing surfaces on the valve plates (5) and valve inserts (6). Compression spring Valve body Valve plate Valve insert... - Page 44 Repairs Place the compression spring (3) inside the valve body (4). Position the compression spring with the end (see figure: arrow N, at the bottom) as shown on one of the lugs in the valve body. Otherwise the valve plate may knock when in opera‐ tion.
-
Page 45: Troubleshooting
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent ® Motor-Driven Metering Pumps and Hydraulic Accessories" must be observed in all cases. WARNING! - Page 46 The power end motor is The discharge line is Rectify any constriction of the discharge line. Technical very hot. seriously constricted. personnel Have the safety relief valve checked. All other faults. Other causes. Call ProMinent ® or ProMaqua ® service.
-
Page 47: Decommissioning And Disposal
EX pumps only: When operating in EX areas, certain sub‐ jects must be observed. – The chapter "Important supplements for metering pumps in EX zones" of the "General Operating Instructions on ProMinent Motor-Driven Metering Pumps and Hydraulic ® Accessories" must be observed in all cases. WARNING! - Page 48 Decommissioning and disposal CAUTION! Warning of feed chemical spraying around Feed chemical can spray out of the hydraulic components if they are manipulated or opened due to pressure in the liquid end and adjacent parts of the system. – Disconnect the pump from the mains power supply and ensure that it cannot be switched on again by unauthor‐...
-
Page 49: Disposal
Decommissioning and disposal 14.2 Disposal Personnel: Technical personnel CAUTION! Environmental hazard due to gear oil The pump contains gear oil, which can cause damage to the environment. – Drain the gear oil from the pump. – Note the local guidelines currently applicable in your country! CAUTION! Note the local guidelines generally currently applicable in... -
Page 50: Technical Data
Technical data Technical data Only for "M - modified" version: WARNING! Risk of personal injuries Please observe the ”Supplement for modified version“ at the end of the chapter! It replaces and supplements the technical data! 15.1 Performance data Main pumps with motor 1500 rpm under 50 Hz operation Type Minimum pump capacity at maximum... -
Page 51: Accuracy
Technical data Main pumps with motor 1800 rpm under 60 Hz operation Type Minimum pump capacity at maximum Maximum Suction Connector size Shipping back pressure stroke rate lift weight* Strokes/min m WS G-DN 120260 81.8 1 1/2 - 25 46/54 120340 109.5 1 1/2 - 25... -
Page 52: Viscosity
500 ... 1000 mPas out installation with appropriately laid > 1000 mPas out installation and advice from ProMinent * Only when the installation is correctly adjusted 15.4 Wetted materials with DN 25 ball valve Material version Liquid end Suction/dis‐... -
Page 53: Ambient Conditions
Technical data 15.5 Ambient conditions 15.5.1 Temperatures Pump, compl. Data Value Unit Storage and transport temperature -10 ... +50 °C Ambient temperature in operation (drive + -10 ... +40 °C motor): PC liquid end Data Value Unit Max. temperature long-term at max. oper‐ 45 °C ating pressure Max. -
Page 54: Housing Degree Of Protection
Technical data 15.6 Housing degree of protection Data Value Protection against contact and humidity* IP 55 *according to DIN VDE 470 (EN IEC 60529) 15.7 Stroke sensor (option), intrinsically safe Stroke sensor (option), intrinsically safe Install the sensor according to the chapter "Installation, elec‐ trical". -
Page 55: Motor Data
The monitor / power supply must be able to evaluate the cur‐ rent variations to indicate a diaphragm rupture! 15.9 Motor data Motor data Makro TZ (TZMb) Identity code Phase, protection Rated voltage Mains supply fre‐ Rated output... -
Page 56: Filling Volumes
Technical data Identity code Phase, protection Rated voltage Mains supply fre‐ Rated output Remarks specification quency 1 ph, IP 55 400 V ±10 % 50/60 Hz 1.1 kW Variable speed motor with inte‐ grated frequency converter 3 ph, II2GEEX‐ 400 V ±10 % 50/60 Hz 1.5 kW EX variable... - Page 57 Technical data Spare parts With a modified version, it is absolutely necessary to specify the details of the serial number requesting and ordering the spare and replacement parts.
-
Page 58: Motor Data Sheet
This information is supplied without liability. Les données techniques correspondent au descriptif du fabricant des moteurs. Les données techniques des moteurs similaires chez d’ autres fabricants varient très peu. Données sont d’ ordre général. ProMinent Dosiertechnik GmbH . 69123 Heidelberg . Germany Nr./No. MD-1039212... -
Page 59: Ec Declaration Of Conformity
EC Directive, on the basis of its functional concept and design and in the version marketed by us. This declaration loses its validity in the event of a modification to the product not agreed with us. Description of the product: Metering pump, Makro TZ series TZMa..., TZKa..., TZHa..., TZMb... Product type: Please refer to nameplate on the device Serial no.:... - Page 60 EC Declaration of Conformity For pumps with explosion protection: The EC Declaration of Conformity for pumps for potentially explosive atmospheres is enclosed with the pump. The EC Declaration of Conformity, the EC type-test reports and the oper‐ ating instructions for the individual components are also enclosed with the pump.
-
Page 61: Index
Index Index Modified................. 56 Accuracy............... 51 motor............... 26, 56 Air humidity..............53 Motor data sheet............58 Ambient conditions............53 Assembly............... 20 Namur sensor............54, 55 Capacity................ 50 Oil.................. 56 Climate................53 Connector size.............. 50 Protection against contact and humidity....... 54 Contact................
