Pro Tools Setup
Step 1.) Open a Pro Tools session and click on the
"Setups" tab. Open the "Peripherals" menu and click on
the MIDI Controllers tab.
Step 2.) Click on the small box just below "Type" and
select "MotorMix". Since MotorMate uses the MotorMix
personality file already in ProTools, no special file is
needed.
Step 3.) Click on the small box just below "Receive From"
and select the MotorMate cable input.
Step 4.) Click on the small box just below "Send To" and
select the MotorMate cable output. At this point, the small
box under "# Ch's" should show "8".
Step 5.) Click on the "OK" box in the "Peripherals" menu.
Step 6.) If you are using Pro Tools 5.1, click on the MIDI
tab and select "Input Devices". Click on the MotorMate
listed. This will enable Pro Tools to receive its MIDI input.
Step 7.) In Pro Tools 5.1 and higher, go to the Set up
window and choose Preferences. In the Preferences box,
click on Operation. Then select 'Classic' located in the
Numeric Keypad Mode Section. Classic Numeric Keypad
allows you use the Locate function on MotorMix.
Step 8.) Press the PLAY switch on MotorMate, the
session will start to play and the Time Code display on
MotorMate will show the play time.
Step 9.) Each time you use Pro Tools you should have
MotorMate powered up first to insure that it gets a
complete update of your most recent session settings.
Digital Performer Software Setup
Step 1.) Log on to http://www.cmlabs.net and open the
MotorMix page. Click on the Digital Performer link and
follow the download instructions there.
Step 2.) Expand the MotorMix archive.
Step 3.) Put the MotorMix Plug-in into your DP Plug-ins
folder.
Step 4.) Reboot your Mac and launch Digital performer.
Step 5.) Pull down the "Basics" menu and select "Control
Surface Setup" and select MotorMix in the Hardware box.
(Since MotorMate uses the same MIDI protocols as
MotorMix).
Installation and Connections
Step 6.) In the " MIDI Communication:" box select
"MotorMate" or whatever name you have used to define it
in your MIDI device setup. Click "OK" and you'll be up
and running.
Note: CM Labs maintains the MotorMix plug-in for Digital
Performer. Please check our website for updates to the
Plug-in.

Steinberg Cubase Setup

Step 1.) Launch Cubase and click on the Devices menu.
Click on Device Setup.
Step 2.) Click on Add/Remove, then select Mackie HUI in
the Device Classes list. Click on Add. Then Click O.K.
Step 3.) Click on the Devices menu. Click on Mackie HUI
in the Device Classes list. Then select the proper MIDI
Input and MIDI Output port for MotorMate. Then click
O.K.

Steinberg Nuendo Setup

Step 1.) Launch Cubase and click on the Devices menu.
Click on Device Setup.
Step2.) Click on Add/Remove, then select Mackie HUI in
the Device Classes list. Click on Add. Then Click O.K.
Step 3.) Click on the Devices menu. Click on Mackie HUI
in the Device Classes list. Then select the proper MIDI
Input and MIDI Output port for MotorMate. Then click
O.K.
CM Labs MotorMate Owner's Manual Page 7
