BEC 9800VN
®
GigaConnect
Wireless-N VoIP Active Ethernet
Point-to-Point Fiber Gateway

User Manual

Version release: v1.14
Last revised: April, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9800VN and is the answer not in the manual?

Questions and answers

Related Manuals for BEC 9800VN

Summary of Contents for BEC 9800VN

  • Page 1: User Manual

    BEC 9800VN ® GigaConnect Wireless-N VoIP Active Ethernet Point-to-Point Fiber Gateway User Manual Version release: v1.14 Last revised: April, 2014...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1: INTRODUCTION ........1 ..............1 NTRODUCTION TO YOUR OUTER & S ..............2 EATURES PECIFICATIONS ............... 5 ARDWARE PECIFICATIONS ................6 PPLICATION IAGRAM CHAPTER 2: PRODUCT OVERVIEW ......8 ..........8 MPORTANT OTE FOR SING OUTER ................
  • Page 3 ................28 OGIN TO YOUR EVICE ....................30 TATUS Device Info ......................31 System Log ......................33 Statistics ......................34 DHCP Table ......................38 ARP Table ......................38 Wireless ARP Table..................... 38 Disk Status ......................39 VoIP Status ......................39 ..................
  • Page 4 CWMP (TR-069) ......................105 Parental Control ......................107 SAMBA & FTP Server ....................108 Maintenance ....................111 User Management ..................... 111 Time Zone ........................114 License ........................115 Firmware & Configuration ..................115 System Restart ......................117 Diagnostics Tool......................118 CHAPTER 5: TROUBLESHOOTING ......

  • Page 5: Chapter 1: Introduction

    FTTH deployments. FTTH Applications The BEC 9800VN can be used for a point-to-point fibre access network. Since the Fibre WAN interface allows faster rates over even longer distances, it can support Telcom operators or ISPs to provide high quality and reliable Internet broadband services to either business users or home users.

  • Page 6: Features & Specifications

    • IPv4, IPv6, IPv4 / IPv6 dual stack • NAT,PAT, static(v4/v6) routing and RIP-1/2 • IPv6 stateless / stateful address auto-configuration • IPv6 router advertisement • IPv6 over PPP • DHCPv6 • Universal Plug and Play (UPnP) compliant BEC 9800VN User Manual...
  • Page 7 • 2.4 GHz - 2.484GHz frequency range • Up to 300 Mbps wireless operation rate • WPS (Wi-Fi Protected Setup) for easy setup • On / Off Wireless with WPS push button • 64 / 128 bits WEP supported for encryption BEC 9800VN User Manual...
  • Page 8 • Firmware upgrades and configuration data upload and download via web-based GUI • Supports DHCP server / client / relay • Supports SNMP v1, v2, v3, MIB-I and MIB-II • TR-069 supports remote management • System log monitoring • User Access Management Levels BEC 9800VN User Manual...

  • Page 9: Hardware Specifications

    • USB 2.0 for storage service • Reset Button • Wireless On/Off / WPS Push Button • Power Jack • Power On/Off Switch Physical Specifications • Dimensions (W*H*D): 9.04" x 6.10" x 1.27"(229.5mm x 155mm x 32.24mm) BEC 9800VN User Manual...

  • Page 10: Application Diagram

    Introduction Application Diagram SFP (direct connection to fiber) mode BEC 9800VN has a SFP interface for direct fibre connection. BEC 9800VN User Manual...
  • Page 11 Introduction Broadband router mode BEC 9800VN has a Gigabits Ethernet WAN port to connect to your Fibre/ Cable/ xDSL modem. BEC 9800VN User Manual...

  • Page 12: Chapter 2: Product Overview

     Do not use the router in high humidity or high temperature.  Do not use the same power source for the BEC 9800VN on other equipment.  Do not open or repair the case yourself. If the device becomes...

  • Page 13: Device Description

    Successfully registered and ready to be used. Orange Phone is off-hook, in-use Green IP connected and traffic is passing thru the device. Internet IP request failed. BEC 9800VN is either in bridged mode or WAN connection not ready. BEC 9800VN User Manual...

  • Page 14: Rear Panel Connectors

    1. It is required to use a PoE Injector / Device complied with IEEE802.at standard. Using an 802.af standard PoE device will reduce the performance of BEC 9800VN. 2. For WPS configuration, please refer to the WPS section in the User Manual.

  • Page 15: Cabling

    Make sure that all other devices (e.g. telephones, fax machines, analogue modems) connected to the same telephone line as your BEC router have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and that all line filters are correctly installed in a right way.

  • Page 16: Chapter 3: Basic Installation

    If not, please refer to your Windows-related or other operating system manuals. Any TCP/IP capable workstation can be used to communicate with or through the BEC 9800VN. To configure other types of workstations, please consult the manufacturer’s documentation. BEC 9800VN User Manual...

  • Page 17: Network Configuration - Ipv4

    Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 9800VN User Manual...
  • Page 18 In the TCP/IPv4 properties window, select the Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 9800VN User Manual...

  • Page 19: Configuring A Pc In Windows Vista (Ipv4)

    Center at the top bar. When the Network and Sharing Center window pops up, select and click Manage network connections on the left window pane. Select the Local Area Connection, and right click the icon to select Properties. BEC 9800VN User Manual...
  • Page 20 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 9800VN User Manual...

  • Page 21: Configuring A Pc In Windows Xp (Ipv4)

    3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. BEC 9800VN User Manual...

  • Page 22: Configuring A Pc In Windows 2000 (Ipv4)

    3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. BEC 9800VN User Manual...

  • Page 23: Configuring Pc In Windows 98/Me

    Network Interface Card (NIC) in your PC. 3. Select the Obtain an IP address automatically radio button. 4. Then select the DNS Configuration tab. 5. Select the Disable DNS radio button and click OK to finish the configuration. BEC 9800VN User Manual...

  • Page 24: Configuring Pc In Windows Nt4.0

    1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK. BEC 9800VN User Manual...

  • Page 25: Network Configuration - Ipv6

    Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 9800VN User Manual...
  • Page 26 In the TCP/IPv6 properties window, select the Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 9800VN User Manual...

  • Page 27: Configuring A Pc In Windows Vista (Ipv6)

    Center at the top bar. When the Network and Sharing Center window pops up, select and click Manage network connections on the left window pane. Select the Local Area Connection, and right click the icon to select Properties. BEC 9800VN User Manual...
  • Page 28 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 9800VN User Manual...

  • Page 29: Configuring A Pc In Windows Xp (Ipv6)

    1. On the Desktop, Click Start > Run, type cmd, then press Enter key in the keyboard, the following screen appears. 2. Key in command ipv6 install Installation of IPv6 is now completed. Please test it to see if it works or not. . BEC 9800VN User Manual...

  • Page 30: Default Settings

    Attention release it, to be sure you power cycle the device again. Device LAN IP Settings IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 DHCP Server: DHCP server is enabled. Start IP Address: 192.168.1.100 IP pool counts: 100 BEC 9800VN User Manual...

  • Page 31: Information From Your Isp

    DHCP Client (it can be automatically assigned by your ISP when Dynamic IP Address you connect or be set manually). IP address, Subnet mask, Gateway address, and Domain Name Static IP Address System (DNS) IP address (it is fixed IP address). Pure Bridge Bridge Mode BEC 9800VN User Manual...

  • Page 32: Chapter 4: Device Configuration

    “Go”, a user name and password window prompt appears. The default username and password is “admin” and “admin” respectively for the Administrator. NOTE: This username / password may vary by different Internet Service Providers. Congratulations! You have successfully logged on to your BEC 9800VN. BEC 9800VN User Manual...
  • Page 33 Device Configuration / Status Once you have logged on to your 9800VN via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the...

  • Page 34: Status

    Device Configuration / Status Status In this section, you can check the router working status, including Device Info, System Log, Statistics, DHCP Table, ARP Table, Wireless ARP Table, Disk Status, and VoIP Status. BEC 9800VN User Manual...

  • Page 35: Device Info

    Subnet Mask: LAN port IP subnet mask. DHCPv4 Server: LAN port DHCP role - Enabled, Relay or Disabled.  IPv6: IP Address: LAN port IPv6 address. Prefix Length: The prefix length DHCPv6 Server: The DHCP status. BEC 9800VN User Manual...
  • Page 36 DNS Server: DNS information.  IPv6: Status: The IPv6 connection status. IP Address: WAN port IPv6 address. Prefix Length: The prefix length of IPv6 address. Default Gateway: The IP address of the default gateway. DNS Server: DNS information. BEC 9800VN User Manual...

  • Page 37: System Log

    Device Configuration / Status System Log In system log, you can check the operations status and any glitches to the router. Refresh: Press this button to refresh the statistics. BEC 9800VN User Manual...

  • Page 38: Statistics

    Receive CRC Errors: This field displays the number of error packets on this port. Receive Under-size Frames: This field displays the number of under-size frames received until the latest second. Refresh: Press this button to refresh the statistics. BEC 9800VN User Manual...
  • Page 39 Receive Error Frames: This field displays the number of error frames received until the latest second. Receive Drop Frames: This field displays the number of drop frames received until the latest second. Refresh: Press this button to refresh the statistics. BEC 9800VN User Manual...
  • Page 40 Receive CRC Errors: This field displays the number of error packets on this port. Receive Under-size Frames: This field displays the number of under-size frames received until the latest second. Refresh: Press this button to refresh the statistics. BEC 9800VN User Manual...
  • Page 41 Receive CRC Errors: This field displays the number of error packets on this port. Receive Under-size Frames: This field displays the number of under-size frames received until the latest second. Refresh: Press this button to refresh the statistics. BEC 9800VN User Manual...

  • Page 42: Dhcp Table

    Internet (IP) addresses to the Wireless (MAC) addresses. SSID#: List of Wireless Access Point (AP) index. IP Address: Display current connected / associated IP Address of Wireless client(s). MAC Address: Display current connected / associated Wireless client’s MAC address that is BEC 9800VN User Manual...

  • Page 43: Disk Status

    Phone Number: The number you use to register in the Basic page of VoIP. Host: Show the IP address and port number of SIP Registrar. Status: The status of the registered SIP account. Registered Time: The duration the account has been successfully registered to the SIP registrar. BEC 9800VN User Manual...

  • Page 44: Quick Start

    Step1. Set new password of the “admin” account to access for router management. The default is “admin”. Once changed, please use this new password next time when accessing to the router. Click NEXT to continue. Step2: Choose your time zone. Click NEXT to continue. BEC 9800VN User Manual...
  • Page 45 If selected PPPoE, please enter PPPoE account information provided by your ISP. Click NEXT to continue. 3).The Setup Wizard has completed. Click on BACK to modify changes or mistakes. Click NEXT to save the current settings. Quick Start Completed! BEC 9800VN User Manual...
  • Page 46 Device Configuration / Quick Start Switch to Status > Device Info to view the status. BEC 9800VN User Manual...

  • Page 47: Configuration

    Click to access and configure the available features in the following: Interface Setup, Dual WAN, Advanced Setup, VoIP, Access Management, and Maintenance. These functions are described in the following sections. Interface Setup Here are the features under Interface Setup: Internet, LAN, Wireless and Wireless MAC Filter. BEC 9800VN User Manual...

  • Page 48: Internet

    Device Configuration / Interface Setup Internet  EWAN Multi Service Service Index: The index marks the EWAN interface of different ISP type, ranging from 0-7. BEC 9800VN User Manual...
  • Page 49 Inner VLAN ID: Specify the inner/ending VLAN ID of the final packet. Enter the VLAN ID identification, tagged: 4-4095 PPPoE (If selected PPPoE as WAN Connection Type; otherwise, skip this part) Username: Enter the user name provided by your ISP. BEC 9800VN User Manual...
  • Page 50 OUT only means the router will only send but will not accept RIP packet. TCP MTU Option: Maximum Transmission Unit, the maximum is 1500. IGMP Proxy: IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish membership in a Multicast group. Choose whether enable IGMP proxy. BEC 9800VN User Manual...
  • Page 51 MLD Proxy: MLD (Multicast Listener Discovery Protocol) is to IPv6 just as IGMP to IPv4. It is a Multicast Management protocol for IPv6 multicast packets. When router’s Internet configuration is finished successfully, you can go to status to get the connection information. BEC 9800VN User Manual...
  • Page 52 Device Configuration / Interface Setup  Multi Service Service Index: The index marks the EWAN interface of different ISP type, ranging from 0-7. Service Summary: The overall service information. BEC 9800VN User Manual...
  • Page 53 Inner VLAN ID: Specify the inner/ending VLAN ID of the final packet. Enter the VLAN ID identification, tagged: 4-4095 PPPoE (If selected PPPoE as WAN Connection Type; otherwise, skip this part) Username: Enter the user name provided by your ISP. BEC 9800VN User Manual...
  • Page 54 OUT only means the router will only send but will not accept RIP packet. TCP MTU Option: Maximum Transmission Unit, the maximum is 1500. IGMP Proxy: IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish membership in a Multicast group. Choose whether enable IGMP proxy. BEC 9800VN User Manual...
  • Page 55 MLD Proxy: MLD (Multicast Listener Discovery Protocol) is to IPv6 just as IGMP to IPv4. It is a Multicast Management protocol for IPv6 multicast packets. When router’s Internet configuration is finished successfully, you can go to status to get the connection information. BEC 9800VN User Manual...

  • Page 56: Lan

    - that is, it is forwarded to all ports. With IGMP snooping, multicast traffic of a group is only forwarded to ports that have members of that group. Dynamic Route: Select the RIP version from RIP1 or RIP2. BEC 9800VN User Manual...
  • Page 57  If set to Disabled, the DHCP server will be disabled.  If set to Relay, the BEC 9800VN acts as a surrogate DHCP server and relays DHCP requests and responses between the remote server and the clients. Enter the IP address of the actual, remote DHCP server in the Remote DHCP Server field in this case.
  • Page 58 (MAC address) and information (prefix) advertised by routers, but they can obtain such information like DNS from DHCPv6 Server.  Stateful: If selected, the PCs in LAN will be configured like in IPv4 mode, thus obtain addresses BEC 9800VN User Manual...
  • Page 59 This feature is to send Router Advertisement messages periodically which would multicast the IPv6 Prefix information (similar to v4 network number 192.168.1.0) to all LAN devices if the field is enabled. We suggest enabling this field. BEC 9800VN User Manual...

  • Page 60: Wireless

    This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as complex as a number of computers with wireless LAN cards communicating through access points which bridge network traffic to the wired LAN. BEC 9800VN User Manual...
  • Page 61 SSID Index: Select the number of SSIDs you want to use; up to 4 SSIDs are available in the list. SSID: The SSID is the unique name of a wireless access point (AP) to be distinguished from another. BEC 9800VN User Manual...
  • Page 62 Key 1 to Key 4: Enter the key to encrypt wireless data. To allow encrypted data transmission, the WEP Encryption Key values on all wireless stations must be the same as the router. There are four BEC 9800VN User Manual...
  • Page 63 It is easy to be installed, just define the peer’s MAC of the connected AP. WDS Mode: select Activated to enable WDS feature and Deactivated to disable this feature. MAC Address: Enter the AP MAC addresses (in XX:XX:XX:XX:XX:XX format) of the peer connected BEC 9800VN User Manual...
  • Page 64 Device Configuration / Interface Setup BEC 9800VN User Manual...
  • Page 65 Device Configuration / Interface Setup Wi-Fi Protected Setup (WPS) Example I: PIN Method: Configure AP as Registrar 1. Jot down the client’s Pin (e.g. 04640776). 2. Enter the Enrollee (Client) PIN code and then press Start WPS. BEC 9800VN User Manual...
  • Page 66 PIN button located on the middle left of the page to run the scan. 4. The client’s SSID and security setting will now be configured to match the SSID and security setting of the registrar (router). BEC 9800VN User Manual...
  • Page 67 2. Launch the wireless client’s WPS utility (e.g. Ralink Utility). Set the Config Mode as Registrar. Enter the PIN number in the PIN Code column then choose the correct AP (e.g. Billion_AP) from the WPS AP List before pressing the PIN button to run the scan. BEC 9800VN User Manual...
  • Page 68 4. Now to make sure that the setup is correctly done, cross check to see if the SSID and the security setting of the registrar setting match with the parameters found on both Wireless Configuration and Wireless Security Configuration page. BEC 9800VN User Manual...
  • Page 69 3. When the PBC button is pushed, a wireless communication will be established between your router and the PC. The client’s SSID and security setting will now be configured to match the SSID and security setting of the router. BEC 9800VN User Manual...

  • Page 70: Wireless Mac Filter

    Select Allow to permit access to the router, MAC addresses not listed will be denied access to the router. MAC Address: Enter the MAC addresses (in XX:XX:XX:XX:XX:XX format) of the wireless station that are allowed or denied access to the specified in these address fields. BEC 9800VN User Manual...

  • Page 71: Dual Wan

    2).The failback setting follow the same decision policy as the failover. For example, according to settings above in the screenshot, the connection probe will be carried out every 30 seconds, and 3 consecutive times of probe success is found, the router will determine failback to WAN1 (main WAN). BEC 9800VN User Manual...
  • Page 72 “Probe Cycle” to check the connectivity of the gateway of WAN1 interface.  Host: It will send ping packets to specific host and wait for response in every “Probe Cycle”. The host must be an IP address. BEC 9800VN User Manual...

  • Page 73: Advanced Setup

    Device Configuration / Advanced Setup Advanced Setup Advanced Step provides advanced features including Firewall, Routing, NAT, Static DNS, QoS, Port Isolation, Interface Grouping, and Time Schedule for advanced users. BEC 9800VN User Manual...

  • Page 74: Firewall

     Disabled: It disables the firewall function. SPI: If you enabled SPI, all traffics initiated from WAN would be blocked, including DMZ, Virtual Server, and ACL WAN side.  Enabled: It activates your SPI function.  Disabled: It disables the SPI function. BEC 9800VN User Manual...

  • Page 75: Routing

    Gateway IP Address/Interface: This is the gateway IP address or existing interface to which packets are to be forwarded. Metric: It represents the cost of transmission for routing purposes. The number need not be precise, but it must be between 1 and 15. BEC 9800VN User Manual...

  • Page 76: Nat

    Service Index: Associated to EWAN interface marking each EWAN service (0-7), to select which EWAN service the DMZ and Virtual server are applied to. Click DMZ or Virtual Server to move on to set the DMZ or Virtual Server parameters, which are represented in the following scenario. BEC 9800VN User Manual...
  • Page 77 DMZ Host IP Address: Give a static IP address to the DMZ Host when Enabled radio button is checked. Be aware that this IP will be exposed to the WAN/Internet. Select the Save button to apply your changes. BEC 9800VN User Manual...
  • Page 78 Virtual Server for: Indicate the related WAN interface which allows outside network to connect in and communicate. Protocol: Choose the application protocol. Start / End Port Number: Enter a port or port range you want to forward. (Example: Start / End: 1000 or Start: 1000, End: 2000). BEC 9800VN User Manual...
  • Page 79 PC, with an address that does not fall into the range of IP addresses that are to be issued by the DHCP server. You can configure the virtual server IP address manually, but it must still be in the same subnet as the router. BEC 9800VN User Manual...
  • Page 80 Eneter the static IP assiged to the local PC that is hosting the FTP server. Ex: 192.168.1.102 Enter ”21” to Local Start and End Port number. BEC 9800VN will forward port 21 request from WAN to the specific LAN PC (ex:192.168.1.102) in the network.

  • Page 81: Static Dns

    Static DNS is a concept relative to Dynamic DNS, in static DNS system, the IP mapped is static without change IP Address: The IP address you are going to give a specific domain name. Domain Name: The friendly domain name for the IP address. Press Save button to apply your settings. BEC 9800VN User Manual...

  • Page 82: Qos

    LAN1-4 Upstream / Downstream: Specify the upstream and downstream rate of the LAN1-LAN4 interface. Note: The above bandwidth(rate) settings will be taken as a reference by QoS rules. Click Save to save the EWAN rate settings. Click SETTING to add QoS rules (up to 32 QoS rules). BEC 9800VN User Manual...
  • Page 83 Class 1, Bronze (001110) Silver service (L) Class 2, Gold (010010) Silver service (M) Class 2, Silver (010100) Silver service (H) Class 2, Bronze (010110) Bronze service (L) Class 3, Gold (011010) Bronze service (M) Class 3, Silver (011100) BEC 9800VN User Manual...
  • Page 84 External Port: The Port number on the remote / WAN side. Time Schedule: Select or set exactly when the rule works.. For example, you can give outgoing VoIP traffic more bandwidth to ensure the quality of bandwidth-sensitive audio service. BEC 9800VN User Manual...

  • Page 85: Interface Grouping

    Interface Setup to add other EWAN interface. SFP Service: The available SFP interface. Ethernet LAN: The available Ethernet ports. Wireless LAN: The available wireless port(s). Group Summary: Press PortBinding Summary to check the current group information. BEC 9800VN User Manual...
  • Page 86 Example: Create two EWAN services, Service0 (PPPoE) and Service1 (Bridge). You are going to group the ports and services into two working group, as shown below. Group Index Group Port EWAN0,LAN1, LAN2, WLAN1 EWAN1, LAN3 Click Group Summary to show the configuration results. BEC 9800VN User Manual...
  • Page 87 Device Configuration / Advanced Setup BEC 9800VN User Manual...

  • Page 88: Port Isolation

    This is a special example, and users can change the settings to determine how the ports are belonged to the group. BEC 9800VN User Manual...

  • Page 89: Time Schedule

    Day of Week: Mon. to Sun. Specify the time interval for each timeslot from “Day of Week”. For example, user can add a timeslot named “TimeSlot1” which features a period from 9:00 of Monday to 18:00 of Tuesday. Another TimeSlot2 spanning from 09:00 to 18:00 of Friday BEC 9800VN User Manual...

  • Page 90: Voip

    Phone_1 and Phone_2, and these phone ports share the same local RTP port. Phone: Select “1”, the following parameters will be applicable to Phone1. In BEC 9800VN, Phone_1 and Phone_2 are allowed to be of different characteristics, including different SIP registrar. You need to configure individually for phone1 and phone 2 and can have up to 2 different VoIP accounts.
  • Page 91 SIP Outbound Proxy Address: Set the SIP outbound proxy address. It is usually used to realize the communication between two phones when at least one of them is located behind a NAT router. SIP Outbound Proxy Port: Set the SIP Outbound proxy port. BEC 9800VN User Manual...

  • Page 92: Media

     G.729: It is used to encoder and decoder voice information into a single packet which reduces the bandwidth consumption.  G.726: It is an ITU-T ADPCM speech codec standard covering the transmission of voice at rates of 32kbit/s. BEC 9800VN User Manual...

  • Page 93: Advanced

    DTMF Transport Mode: Select the DTMF mode. Listening Volume: Adjust the volume of listener, -6 to 6, from lowest to highest. Speaking Volume: Adjust the volume of microphone; -6 to 6, from lowest to highest. BEC 9800VN User Manual...

  • Page 94: Speed Dial

    Phone Number: The complete destination number Example: Save phone number 83455301 to the speed dial list. When you want call 83455301 through phone 1, you can simply dial 301# to make your desired call. BEC 9800VN User Manual...

  • Page 95: Call Features

    Note: Before enabling this feature, please consult with your VoIP Service Provide to be sure it can be supported. There is a ringtone list available in the BEC 9800VN, after enabling this feature, your BEC 9800VN will adapt a specific ring pattern on the list requested by your VoIP Service Provider for a specific telephone number.
  • Page 96 Device Configuration / VoIP not ring when a call comes in; while press *79 to disable Don’t Disturb feature, if a call comes with a ringing indication. BEC 9800VN User Manual...
  • Page 97 Step – 5: Bill tells Larry that it is Mark and he wants to set up a conference with Mark. Step – 6: Bill presses flash again to merge all 3 calls. Step – 7: Bill, Larry and Mark hold a 3-way conference call from now on. BEC 9800VN User Manual...

  • Page 98: Access Management

    Device Configuration / Access Management Access Management Device Management Device management offers users a way to change the embedded web server accessing port, default 80. User can change the http port to 8080 or something else here. BEC 9800VN User Manual...

  • Page 99: Snmp

    Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. BEC 9800VN serves as a SNMP agent which allows a manager station to manage and monitor the router through the network.

  • Page 100: Universal Plug & Play

    Auto-configured: Select this check box to allow UPnP-enabled applications to automatically configure the BEC 9800VN so that they can communicate through the BEC 9800VN, for example by using NAT traversal, UPnP applications automatically reserve a NAT forwarding port in order to communicate with another UPnP enabled device;...

  • Page 101: Dynamic Dns

    Dynamic DNS: Select this check box to activate Dynamic DNS. Service Provider: Select from drop-down menu for the appropriate service provider, for example: www.dyndns.org. My Host Name: Type the domain name assigned to your BEC 9800VN by your Dynamic DNS provider. Username: Type your user name.
  • Page 102 Example: How to register a DDNS account Note first users have to go to the Dynamic DNS registration service provider to register an account. User test1 register a Dynamic Domain Names in DDNS provider http://www.dyndns.org/ DDNS: www.hometest.com using username/password test/test BEC 9800VN User Manual...

  • Page 103: Access Control

    Secure IP Address: The default 0.0.0.0 allows any client to use this service to manage the BEC 9800VN. Type an IP address range to restrict access to the client(s) without a matching IP address. Application: Choose a service that you want to all access to all the secure IP clients. The drop-down menu lists all the common used applications.
  • Page 104 Default Rule 1: (Index 1), a rule to allow only clients from LAN to have access to all embedded applications (Web, FTP, etc). Under this situation, clients from WAN cannot access the router even from Ping. Default Rule 2: (Index 2), an ACL rule to open Ping to WAN side. BEC 9800VN User Manual...

  • Page 105: Packet Filter

    Select “IPv6” for IPv6 address, port number and protocol. Select “MAC” for MAC address. Source IP Address: The source IP address of packets to be monitored. 0.0.0.0 means “Don’t care”. Source Subnet Mask: Enter the subnet mask of the source network. BEC 9800VN User Manual...
  • Page 106 Destination Port: This is the Port or Port Ranges that defines the application. DSCP: show the set DSCP. Protocol: It is the packet protocol type used by the application. Select either TCP or UDP or ICMP or ICMPv6 BEC 9800VN User Manual...
  • Page 107 “Individual Active” field; if some time you want to allow access to this URL, you simply select No in individual active field. In a word, the command serves as a switch to the access of some specific URL with the filter on. URL (Host): Specified URL which is prohibited from accessing. BEC 9800VN User Manual...
  • Page 108 Device Configuration / Access Management BEC 9800VN User Manual...

  • Page 109: Cwmp (Tr-069)

    Path: Local path in HTTP URL for an ACS to make a Connection Request notification to the CPE. Username: Username used to authenticate an ACS making a Connection Request to the CPE. Password: Password used to authenticate an ACS making a Connection Request to the CPE. BEC 9800VN User Manual...
  • Page 110 Interval(s): Specify the inform interval time (sec) which CPE used to periodically send inform message to automatically connect to ACS. When the inform interval time arrives, the CPE will send inform message to automatically connect to ACS. BEC 9800VN User Manual...

  • Page 111: Parental Control

    Browser PC, you can directly check the checkbox of Browser’s MAC Address. Block Schedule: Select a timeslot throughout which the above set MAC is restricted to access internet. See Time Schedule to set the exact timeslot. Timeslot1 at Time Schedule: BEC 9800VN User Manual...

  • Page 112: Samba & Ftp Server

    SAMBA /FTP access and operation permission of objects in SAMBA and FTP server.  New user: users can create new user(s) to grant it (them) access and permission to the SAMBA & FTP server. Please see User Management. BEC 9800VN User Manual...
  • Page 113 , but if you enter \\SambaSvr, please be sure your working PC is in the same workgroup as set in the samba server set above.) 2. Enter the Username and password. 3. Users can browse and access USB storage. BEC 9800VN User Manual...
  • Page 114 2) Create ftp sites (LAN IP / WAN IP, 192.168.1.254, and set the account, port). 3) Connect to the ftp site. 2. Web FTP access 1) Enter ftp://192.168.1.254 at the address bar of the web page. 2) Enter the account's username and password. BEC 9800VN User Manual...

  • Page 115: Maintenance

    User Name: Users can create account(s) to give it (them) access to SAMBA and FTP. New Password: Enter a new password for this user account. Confirmed Password: Re-enter the new password again; you must enter the password exactly the same as in the previous field BEC 9800VN User Manual...
  • Page 116 Permission: Set the operation permission for the user, Read/Write or Read. SAMBA Authority SAMBA Access: Enable to grant the user access to the SAMBA server. Permission: Set the operation permission for the user, Read/Write or Read. BEC 9800VN User Manual...
  • Page 117 Permission: Set the operation permission for the user, Read/Write or Read. SAMBA Authority SAMBA Access: Enable to grant the user access to the SAMBA server. Permission: Set the operation permission for the user, Read/Write or Read. BEC 9800VN User Manual...

  • Page 118: Time Zone

    Greenwich Mean Time (GMT). Daylight Saving: Select this option if you use daylight savings time. NTP Server Address: Enter the IP address of your time server. Check with your ISP/network administrator if you are unsure of this information. BEC 9800VN User Manual...

  • Page 119: License

    Firmware is the software that controls the hardware and provides all functionalities which are available in the GUI. This software may be improved and/or modified; your BEC 9800VN provides an easy way to update the code to take advantage of the changes. .
  • Page 120 Device Configuration / Maintenance BEC 9800VN device when making false configurations and want to restore to the original settings. UPGRADE: Click UPGRADE to begin the upload process. This process may take up to two minutes. DO NOT turn off / power off the device or interrupt the firmware upgrading while it is still in process.

  • Page 121: System Restart

    You may also restore your router to factory settings by holding the small Reset pinhole button on the back of your router in about more than 6s seconds whilst the router is turned on. BEC 9800VN User Manual...

  • Page 122: Diagnostics Tool

    Device Configuration / Maintenance Diagnostics Tool The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. SFP: BEC 9800VN User Manual...
  • Page 123 Device Configuration / Maintenance EWAN: Click START to begin to diagnose the connection. BEC 9800VN User Manual...

  • Page 124: Chapter 5: Troubleshooting

    Troublshooting Chapter 5: Troubleshooting If your BEC 9800VN is not functioning properly, you can refer to this chapter for simple troubleshooting before contacting your service provider support. This can save you time and effort but if symptoms persist, consult your service provider.

  • Page 125: Recovery Procedures

    Please note that the router will only respond with its web interface at this address (192.168.1.1), and will not respond to ping request from your PC or other telnet operations. BEC 9800VN User Manual...

  • Page 126: Appendix: Product Support & Contact

    If you come across any problems please contact the dealer from where you purchased your product. Contact BEC @ http://www.bectechnologies.net MAC OS is a registered Trademark of Apple Computer, Inc. Windows 7/98, Windows NT, Windows 2000, Windows ME, Windows XP, and Windows Vista are registered Trademarks of Microsoft Corporation. BEC 9800VN User Manual...
  • Page 127 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. BEC 9800VN User Manual...

Table of Contents
