Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
FZS10A(C)
LIT-11626-24-61
1CA-28199-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FZS10A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yamaha FZS10A

Summary of Contents for Yamaha FZS10A

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL FZS10A(C) LIT-11626-24-61 1CA-28199-11...
  • Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 INTRODUCTION EAU10083 Congratulations on your purchase of the Yamaha FZS10A(C). This model is the result of Yamaha’s vast experience in the production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.

  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10193 FZS10A(C) OWNER’S MANUAL ©2010 by Yamaha Motor Corporation, U.S.A. 1st edition, September 2010 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Luggage strap holders ....4-20 Checking the throttle grip free LABELS ..........1-1 EXUP system ....... 4-21 play ........... 7-18 Sidestand ........4-21 Valve clearance ......7-18 SAFETY INFORMATION ....2-1 Ignition circuit cut-off system ..4-22 Tires ..........
  • Page 7 TABLE OF CONTENTS Replacing the fuses ......7-32 YAMAHA EXTENDED SERVICE Replacing a headlight bulb ...7-34 (Y.E.S.) ........10-9 Replacing the tail/brake light bulb ...........7-35 Replacing a turn signal light bulb ...........7-35 Replacing the license plate light bulb ...........7-36 Front wheel ........7-36 Rear wheel ........7-38...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 LOCATION OF IMPORTANT LABELS NOTICE Cleaning with alkaline or acid cleaner, gasoline or solvent will damage windshield. Use neutral detergent. 4B5-2815K-00 TIRE INFORMATION Cold tire normal pressure should be set as follows. • Up to 90 kg (198 lbs) load FRONT : 250 kPa, (2.50 kgf/cm²), 36 psi REAR...
  • Page 10 LOCATION OF IMPORTANT LABELS...
  • Page 11 LOCATION OF IMPORTANT LABELS California only...

  • Page 12: Safety Information

    SAFETY INFORMATION EAU10287 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
  • Page 13 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective Apparel...
  • Page 14 Yamaha accessories, which are avail- Shifting weights can create a sud- accessories to your motorcycle. Use able only from a Yamaha dealer, have den imbalance. Make sure that ac- extra care when riding a motorcycle been designed, tested, and approved cessories and cargo are securely that has added cargo or accessories.

  • Page 15: Specifications

    SAFETY INFORMATION modifications not specifically recom- clearance or cornering clearance, tor and may limit control ability, mended by Yamaha, even if sold and limit suspension travel, steering therefore, such accessories are installed by a Yamaha dealer. travel or control operation, or ob- not recommended.
  • Page 16 SAFETY INFORMATION Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks. Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.

  • Page 17: Description

    DESCRIPTION EAU10410 Left view 1. Front fork spring preload adjusting bolt (page 4-17) 9. Shock absorber assembly rebound damping force adjusting screw (page 4-19) 2. Front fork compression damping force adjusting screw (page 4-17) 10.Shift pedal (page 4-10) 3. Air filter element (page 7-15) 11.Engine oil drain bolt (page 7-11) 4.

  • Page 18: Right View

    DESCRIPTION EAU10420 Right view 1. Owner’s tool kit (page 7-2) 9. Brake pedal (page 4-11) 2. Rider seat lock lever (page 4-15) 10.Coolant reservoir (page 7-14) 3. Fuse box (page 7-32) 11.Rear brake light switch (page 7-22) 4. Battery (page 7-31) 12.Luggage strap holder (page 4-20) 5.

  • Page 19: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-10) 2. Left handlebar switches (page 4-9) 3. Main switch/steering lock (page 4-1) 4. Multi-function meter unit (page 4-5) 5. Front brake fluid reservoir (page 7-23) 6. Right handlebar switches (page 4-9) 7.

  • Page 20: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS EAU10460 EAU10661 To lock the steering Main switch/steering lock All electrical systems are off. The key can be removed. EWA10061 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will be switched off, which may result in loss of control or an accident.

  • Page 21: Indicator Lights And Warning Lights

    “ON”, or if the warning light remains on, have EAU11030 Turn signal indicator lights “ ” a Yamaha dealer check the electrical and “ ” circuit. The corresponding indicator light flash- es when the turn signal switch is Even if the oil level is sufficient, the pushed to the left or right.
  • Page 22 2.5 seconds. If this occurs, cally switch on or off according to have a Yamaha dealer check the the coolant temperature in the ra- vehicle. diator.
  • Page 23 INSTRUMENT AND CONTROL FUNCTIONS Display Conditions What to do Under 39 °C Message “Lo” is displayed. OK. Go ahead with riding. (Under 103 °F) 40–116 °C Coolant temperature is dis- OK. Go ahead with riding. (104–242 °F) played. Stop the vehicle and allow it to idle until 117–134 °C Coolant temperature flashes.

  • Page 24: Multi-Function Meter Unit

    If this oc- an odometer curs, have a Yamaha dealer check the two tripmeters (which show the self-diagnosis system. (See page 4-8 distance traveled since they were...
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS To switch the speedometer and ECA10031 2. Push the “SELECT” button and NOTICE odometer/tripmeter displays be- “RESET” button together for at tween kilometers and miles, press least two seconds. Do not operate the engine in the ta- the “SELECT”...
  • Page 26 Push the “SELECT” button to switch Fuel meter mately 3 seconds. If this occurs, have a the display between the odometer Yamaha dealer check the electrical cir- mode “ODO” and the tripmeter modes cuit. “TRIP A” and “TRIP B” in the following...
  • Page 27 If the display indicates any error codes, the coolant temperature is auto- note the code number, and then have a matically displayed, even if the air Yamaha dealer check the vehicle. intake temperature was displayed ECA11590 NOTICE prior to turning the key to “OFF”.

  • Page 28: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS This function allows you to adjust the EAU12348 EAU12400 Handlebar switches Dimmer switch “ ” brightness of the LCD and the tachom- Set this switch to “ ” for the high eter panel and needle to suit the out- Left beam and to “...

  • Page 29: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12711 EAU12820 EAU12871 Start switch “ ” Clutch lever Shift pedal Push this switch to crank the engine with the starter. See page 6-1 for start- ing instructions prior to starting the en- gine. EAU41700 The engine trouble warning light will come on when the key is turned to “ON”...

  • Page 30: Brake Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU26823 EAU12941 EAU13074 Brake lever Brake pedal Fuel tank cap The brake lever is located at the right handlebar grip. To apply the front brake, pull the lever toward the handle- bar grip. 1. Brake pedal 1.

  • Page 31: Fuel

    INSTRUMENT AND CONTROL FUNCTIONS EAU13221 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10881 WARNING not properly closed and locked.

  • Page 32: Fuel Tank Breather/Overflow Hose

    Before operating the motorcycle: as well as to the exhaust system. Check the fuel tank breather/over- Your Yamaha engine has been de- flow hose connection. signed to use regular unleaded gaso- Check the fuel tank breather/over-...

  • Page 33: Catalytic Converters

    INSTRUMENT AND CONTROL FUNCTIONS Make sure that the end of the fuel EAU13445 ECA10701 Catalytic converters NOTICE tank breather/overflow hose is po- This vehicle is equipped with catalytic sitioned inside of the clamp. Use only unleaded gasoline. The use converters in the exhaust system. of leaded gasoline will cause unre- EWA10862 pairable damage to the catalytic...

  • Page 34: Seats

    INSTRUMENT AND CONTROL FUNCTIONS EAU39322 Seats Passenger seat To remove the passenger seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Rider seat lock lever 2. Remove the key. To install the rider seat Rider seat 1.

  • Page 35: Storage Compartment

    INSTRUMENT AND CONTROL FUNCTIONS EAU14463 Do not exceed the maximum Storage compartment load of FZS10A 190 kg (419 lb) Make sure that the seats are properly FZS10AC 189 kg (417 lb) for the secured before riding. vehicle. 1. Storage compartment The storage compartment is located under the passenger seat.

  • Page 36: Adjusting The Front Fork

    INSTRUMENT AND CONTROL FUNCTIONS EAU39335 load thereby soften Spring preload setting: Adjusting the front fork suspension, turn the adjusting bolt on Minimum (soft): EWA14670 each fork leg in direction (b). WARNING Standard: Always adjust the spring preload on Maximum (hard): both fork legs equally, otherwise poor handling and loss of stability may result.
  • Page 37 INSTRUMENT AND CONTROL FUNCTIONS pression damping force and thereby soften the compression damping, turn Although the total number of clicks of a the adjusting screw in direction (b). damping force adjusting mechanism may not exactly match the above spec- Be sure to perform this adjustment on ifications due to small differences in the left front fork leg.

  • Page 38: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS EAU39345 Rebound damping force Adjusting the shock absorber To increase the rebound damping force assembly and thereby harden the rebound damp- This shock absorber assembly is ing, turn the adjusting screw in direction equipped with a spring preload adjust- (a).

  • Page 39: Luggage Strap Holders

    To obtain a precise adjustment, it is ad- sembly yourself. Take the shock visable to check the actual total number absorber assembly to a Yamaha of clicks or turns of the damping force dealer for any service. adjusting mechanism. This adjustment...

  • Page 40: Exup System

    EAU41941 EAU15304 this system regularly and have a EXUP system Sidestand Yamaha dealer repair it if it does not This model is equipped with Yamaha’s The sidestand is located on the left side function properly. EXUP (EXhaust Ultimate Power valve) of the frame.

  • Page 41: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS EAU44902 Ignition circuit cut-off system The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions. It prevents starting when the trans- mission is in gear and the side- stand is up, but the clutch lever is not pulled.
  • Page 42 ”. stand during this inspection. • 3. Turn the key on. If a malfunction is noted, have a Yamaha 4. Shift the transmission into the neutral position. dealer check the system before riding. 5. Push the start switch. Does the engine start? With the engine still running: The neutral switch may not be working correctly.

  • Page 43: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-14 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 44 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-18, 7-27 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-27 •...
  • Page 45 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-21 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 46: Operation And Important Riding Points

    Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position.

  • Page 47: Shifting

    NOTICE tral position. The neutral indicator light should come on. If not, ask a Even with the transmission in Yamaha dealer to check the elec- the neutral position, do not trical circuit. coast for long periods of time 3. Start the engine by pushing the with the engine off, and do not start switch.

  • Page 48: Engine Break-In

    OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped.

  • Page 49: Parking

    Yamaha dealer check the vehi- touch them and be burned. cle. Do not park on a slope or on soft...

  • Page 50: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-1 for more in- graphical location, and individual use, dealers are trained and equipped to...

  • Page 51: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 52: Periodic Maintenance Chart For The Emission Control System

    From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601...
  • Page 53 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...

  • Page 54: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU32186 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
  • Page 55 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Swingarm pivot...
  • Page 56 24 months. Front and rear brake √ √ √ √ √ √ 25 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 26 * Control cables lube or engine oil thoroughly.
  • Page 57 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 58: Removing And Installing Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18771 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1.

  • Page 59: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode Tightening torque: Spark plug: erosion and excessive carbon or other 13 Nm (1.3 m·kgf, 9.4 ft·lbf)

  • Page 60: Canister (For California Only)

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU19681 EAU19879 Canister (for California only) Engine oil and oil filter car- If a torque wrench is not available when tridge installing a spark plug, a good estimate The engine oil level should be checked of the correct torque is 1/4–1/2 turn before each ride.
  • Page 61 4. Minimum level mark An oil filter wrench is available at a 1. Engine oil drain bolt 4. If the engine oil is below the mini- Yamaha dealer. 2. Gasket mum level mark, add sufficient oil of the recommended type to raise 6.
  • Page 62 PERIODIC MAINTENANCE AND ADJUSTMENT Recommended engine oil: See page 9-1. Oil quantity: Without oil filter cartridge replace- ment: 2.90 L (3.07 US qt, 2.55 Imp.qt) With oil filter cartridge replacement: 3.10 L (3.28 US qt, 2.73 Imp.qt) 1. O-ring 1. Torque wrench Be sure to wipe off spilled oil on any parts after the engine and exhaust sys- Tightening torque:...

  • Page 63: Coolant

    C to access the coolant reser- off and have a Yamaha dealer check voir. (See page 7-9.) Make sure that the vehicle is posi- the vehicle.

  • Page 64: Replacing The Air Filter Element

    Have a periodic maintenance and lubrication be protected against frost and Yamaha dealer change the coolant. chart. Replace the air filter element corrosion. If water has been WARNING! Never attempt to remove...
  • Page 65 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Fuel tank bolt 1. Air filter element 6. Remove the air filter case cover by 2. Air intake manifold removing the screws. NOTICE: 5. Lift the front of the fuel tank, and When removing the air filter 8.

  • Page 66: Checking The Engine Idling Speed

    Yamaha dealer. are not damaged. If any fuel hose is damaged, do not start Engine idling speed: the engine but have a Yamaha 1100–1300 r/min dealer replace the hose, other- wise fuel may leak, creating a fire hazard.

  • Page 67: Checking The Throttle Grip Free Play

    To prevent this cle, note the following points regarding from occurring, the valve clearance the specified tires. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart.
  • Page 68 Rear: have a Yamaha dealer replace 290 kPa (2.90 kgf/cm², 42 psi) the tire immediately. FZS10A 90–190 kg (198–419 lb) The replacement of all wheel- FZS10AC 90–189 kg (198–417 lb): Front: and brake-related parts, includ- 250 kPa (2.50 kgf/cm², 36 psi)
  • Page 69 After extensive tests, only the tires list- tively poor grip on certain road ed below have been approved for this surfaces until they have been model by Yamaha Motor Co., Ltd. “broken in”. Therefore, it is ad- visable before doing any high- Front tire:...

  • Page 70: Cast Wheels

    Yamaha dealer check the internal specified wheels. clutch mechanism. The wheel rims should be checked for cracks, bends, warpage or oth- er damage before each ride.

  • Page 71: Checking The Brake Lever Free Play

    If there is free play, come on just before braking takes ef- have a Yamaha dealer inspect the fect. If necessary, adjust the rear brake brake system. light switch as follows, but the front...

  • Page 72: Checking The Front And Rear Brake Pads

    EAU39371 Checking the front and rear Checking the brake fluid level touches the brake disc, have a Yamaha brake pads dealer replace the brake pads as a set. Front brake The front and rear brake pads must be...

  • Page 73: Changing The Brake Fluid

    Changing the brake fluid is above the minimum level mark and ter the brake fluid reservoir when Have a Yamaha dealer change the replenish if necessary. A low brake fluid refilling. Water will significantly brake fluid at the intervals specified in...

  • Page 74: Drive Chain Slack

    EAU22760 EAU49312 Drive chain slack To adjust the drive chain slack Consult a Yamaha dealer before ad- Using the alignment marks on each The drive chain slack should be justing the drive chain slack. side of the swingarm, make sure that checked before each ride and adjusted 1.

  • Page 75: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23025 may contain substances that Tightening torques: Cleaning and lubricating the could damage O-rings. Axle nut: drive chain 150 Nm (15 m·kgf, 108 ft·lbf) [ECA11111] The drive chain must be cleaned and Locknut: 16 Nm (1.6 m·kgf, 12 ft·lbf) lubricated at the intervals specified in the periodic maintenance and lubrica- 7.

  • Page 76: Checking And Lubricating The Cables

    Yamaha dealer at the intervals speci- ed if necessary. If a cable is damaged fied in the periodic maintenance chart.

  • Page 77: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23142 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease Clutch lever: Brake lever Lithium-soap-based grease Clutch lever The operation of the brake and clutch levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 78: Checking And Lubricating The Centerstand And Sidestand

    If the centerstand or sidestand does several times to check if the front not move up and down smoothly, fork compresses and rebounds have a Yamaha dealer check or re- smoothly. pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.

  • Page 79: Checking The Steering

    Yamaha dealer check or re- tion chart. If there is play in the wheel ward and backward. If any free pair it.

  • Page 80: Battery

    To charge the battery once a month and fully charge it if Electrolyte is poisonous and Have a Yamaha dealer charge the bat- necessary. dangerous since it contains sul- tery as soon as possible if it seems to 3.

  • Page 81: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT is turned to “OFF”, then con- EAU43012 Replacing the fuses nect the positive lead before The main fuse, the fuel injection system connecting the negative lead. fuse, and the fuse box, which contains [ECA16840] the fuses for the individual circuits, are 4.
  • Page 82 1. Starter relay cover the electrical circuit in question to 2. Fuel injection system fuse check if the device operates. 3. Fuel injection system spare fuse 6. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 7-33...
  • Page 83 4. Install the headlight bulb cover, be adversely affected. Thor- and then connect the coupler. oughly clean off any dirt and fin- 5. Have a Yamaha dealer adjust the gerprints on the headlight bulb headlight beam if necessary. using a cloth moistened with al- cohol or thinner.

  • Page 84: Replacing The Tail/Brake Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU24115 EAU43003 Replacing the tail/brake light Replacing a turn signal light bulb bulb 1. Remove the passenger seat. (See 1. Remove the turn signal light unit page 4-15.) by removing the screw. 2. Remove the tail/brake light bulb socket (together with the bulb) by turning it counterclockwise.

  • Page 85: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU24313 EAU24360 Replacing the license plate Front wheel light bulb EAU40201 1. Remove the license plate light unit To remove the front wheel by removing the screws. EWA10821 WARNING To avoid injury, securely support the vehicle so there is no danger of it falling over.
  • Page 86 PERIODIC MAINTENANCE AND ADJUSTMENT 3. Remove the brake hose holder on EAU40211 Tightening torques: To install the front wheel each side by removing the bolt and Wheel axle: 1. Lift the wheel up between the fork nut. 72 Nm (7.2 m·kgf, 52 ft·lbf) legs.

  • Page 87: Rear Wheel

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU25080 NOTICE: Do not apply the brake Rear wheel after the wheel has been re- moved together with the brake EAU40022 disc, otherwise the brake pads To remove the rear wheel will be forced shut. EWA10821 [ECA11071] WARNING To avoid injury, securely support the...

  • Page 88: Troubleshooting

    2. Retainer for checking these vital systems your- self. However, should your motorcycle 2. Install the drive chain onto the rear require any repair, take it to a Yamaha sprocket. dealer, whose skilled technicians have 3. Install the axle nut.
  • Page 89 PERIODIC MAINTENANCE AND ADJUSTMENT heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 7-40...

  • Page 90: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 91 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 92: Motorcycle Care And Storage

    Be ble. Rust and corrosion can develop Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA10772 used. A rusty exhaust pipe may go un- advice on what products to use be- NOTICE fore cleaning the vehicle.
  • Page 93 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.

  • Page 94: Storage

    WARNING ing it with a tarp, while it is still Contaminants on the brakes or tires Consult a Yamaha dealer for ad- wet, will allow water and humid- can cause loss of control. vice on what products to use.
  • Page 95 MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.

  • Page 96: Specifications

    Spark plug gap: –20 –10 0 10 20 30 40 50 ˚C Curb weight: 0.7–0.8 mm (0.028–0.031 in) FZS10A 220 kg (485 lb) Clutch: Recommended engine oil grade: FZS10AC 221 kg (487 lb) Clutch type: API service SG type or higher, JASO...
  • Page 97 2nd: Loading: Rim size: 2.063 (33/16) 17M/C x MT6.00 Maximum load: 3rd: Front brake: FZS10A 190 kg (419 lb) 1.762 (37/21) FZS10AC 189 kg (417 lb) Type: 4th: (Total weight of rider, passenger, cargo and Dual disc brake 1.522 (35/23)
  • Page 98 SPECIFICATIONS Charging system: Engine trouble warning light: AC magneto Battery: Fuses: Model: Main fuse: YTZ14S 50.0 A Voltage, capacity: Headlight fuse: 12 V, 11.2 Ah 20.0 A Headlight: Signaling system fuse: 10.0 A Bulb type: Ignition fuse: Halogen bulb Bulb voltage, wattage × quantity: 15.0 A Radiator fan fuse: Headlight:...

  • Page 99: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 100 This information illustration. This label shows specifica- will be needed when ordering spare tions related to exhaust emissions as parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...

  • Page 101: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 102: Motorcycle Noise Regulation

    CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 103: Maintenance Record

    CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 104 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...

  • Page 105: Yamaha Motor

    CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period...
  • Page 106 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.
  • Page 107 This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 108 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 109 INDEX Engine trouble warning light ....4-5 EXUP system ........4-21 Air filter element, replacing ....7-15 Neutral indicator light ......4-2 Noise regulation........10-4 Front and rear brake pads, checking ..7-23 Battery ..........7-31 Front fork, adjusting ......4-17 Brake and clutch levers, Oil level warning light ......
  • Page 110 INDEX Turn signal light bulb, replacing .... 7-35 Turn signal switch ........4-9 Valve clearance ........7-18 Vehicle Emission Control Information label ............ 10-2 Vehicle identification number ....10-1 Warranty, extended....... 10-9 Warranty, limited ........10-7 Wheel bearings, checking..... 7-30 Wheel (front) .........
  • Page 112 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2010.10-0.3×1 CR...
