INSTRUCTION MANUAL

LEG PRESS (NEW MODEL)
OPTION OF X PRESS
As a quality home gym supplier we are committed to your complete satisfaction. If you have questions, or
find missing or damaged parts, we will guarantee your complete satisfaction through our authorized
dealer service centers or our home office customer service department. Please call your local dealer for
assistance or RSI at 800-990-5556 (9:00 AM - 5:00 PM). Our trained techanicians will provide immediate
assistance to you, free of charge.
We stand behind our products. Every piece, every part of this BODYCRAFT strength training system is
guranteed for as long as you own it. We will repair or replace anything that goes wrong.
Bodycraft is a division of Recreation Supply Inc.
P. O. Box 181
Sunbury, OH 43074
QUESTION?

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Option and is the answer not in the manual?

Questions and answers

Related Manuals for BodyCraft Option

Summary of Contents for BodyCraft Option

  • Page 1: Instruction Manual

    RSI at 800-990-5556 (9:00 AM - 5:00 PM). Our trained techanicians will provide immediate assistance to you, free of charge. We stand behind our products. Every piece, every part of this BODYCRAFT strength training system is guranteed for as long as you own it. We will repair or replace anything that goes wrong.

  • Page 2: Before You Begin

    7. Make certain all cables are seated within the pulleys before every use. 8. Exercise with care to avoid injury. 9. If unsure about the proper use of the BODYCRAFT LEG PRESS Ⅱ strength training system call your local BODYCRAFT dealer or our customer...

  • Page 3: Exploded View

    EXPLODED VIEW...

  • Page 4: Parts Chart

    PARTS CHART DESCRIPTION QTY. BASE STABILIZER LEG PRESS MAIN FRAME LEFT LEG PRESS HANDLE RIGHT LEG PRESS HANDLE LONG LEG PRESS CONNECTOR FRONT LEG PRESS SUPPORT WEIGHT BASE CONNECTOR REAR LEG PRESS SUPPORT FOOT PLATE CONNECTOR FOOT PLATE BACK PAD ADJUSTER BEARING HOUSING(all pre-assembled) LEG PRESS AXLE 45mm X 75mm RECT.
  • Page 5 STEP 1 1. Attach the Weight Base Connector (207) to the Base Frame (1) using two 3/8" X 3- 1/8" Hex Bolts (230), four 3/8" Washers (238) and two 3/8" Nylon Nuts (241). Look for the sticker on the Weight Base Connector (207) to determine the correct orientation.
  • Page 6 STEP 2 1. Attach the Leg Press Main Frame (202) to the Weight Base Connector (207) and the Long Leg Press Connector (205) using four 3/8" X 4" Hex Bolts (229), eight 3/8" Washers (238) and four 3/8" Nylon Nuts (241). 2.
  • Page 7 STEP 2...
  • Page 8 STEP 3 bolt end metal ball end LEG PRESS CABLE (243) 1. Screw the threaded end (approximately half way) of the Leg Press Cable (243) into the Single Pulley Block (27) as shown in Fig. 1. 2. Route the cable up and over the right side pulley in the Top Frame (5) as shown in Fig.
  • Page 9 STEP 3 bolt end metal ball end LEG PRESS CABLE (243) FIG 1 FIG 2 FIG 3 FIG 4 FIG 5 STP 1 FIG 7 FIG 1 FIG 6 STP 2 FIG 7 FIG 2 FIG 4 FIG 7 FIG 3 FIG 8 FIG 8 FIG 7...
  • Page 10 5.For better performance, apply a household lubricant (such as silicone) to any adjustable areas. 6.Enjoy many years of a Fit Lifestyle. Thank you for purchasing the BodyCraft LEG PRESS Ⅱ. If You have any questions, please call your local BodyCraft dealer or call our customer service department at 800-990-5556...
