Icom IC-F7000 Service Manual page 48

6-3 HM-146
[MAIN UNIT]
REF ORDER
NO. NO.
MIC
IC1 1130008990 S.IC
Q1 1590003340 S.TRANSISTOR
D1 1730002500 S.ZENER
X1 6060000700 S.CERAMIC
L5 6200008620 S.COIL
R1 7030009370 S.RESISTOR
R13 7030009360 S.RESISTOR
R14 7030009410 S.RESISTOR
R15 7030009450 S.RESISTOR
R17 7030009430 S.RESISTOR
R18 7030009350 S.RESISTOR
R19 7030009430 S.RESISTOR
R20 7030009430 S.RESISTOR
R22 7030009380 S.RESISTOR
R23 7030009390 S.RESISTOR
R24 7030009470 S.RESISTOR
R25 7030009470 S.RESISTOR
R26 7030009470 S.RESISTOR
R27 7030009470 S.RESISTOR
R28 7030009470 S.RESISTOR
R29 7030009470 S.RESISTOR
R30 7030009470 S.RESISTOR
R31 7030009470 S.RESISTOR
R35 7030009360 S.RESISTOR
R36 7030011020 S.RESISTOR
C1 4030014380 S.CERAMIC
C2 4030014380 S.CERAMIC
C3 4030014370 S.CERAMIC
C4 4030014410 S.CERAMIC
C13 4030014370 S.CERAMIC
C15 4030014400 S.CERAMIC
C16 4030014360 S.CERAMIC
C17 4030014370 S.CERAMIC
C18 4030018730 S.CERAMIC
C19 4030014390 S.CERAMIC
C20 4030014400 S.CERAMIC
C21 4030014410 S.CERAMIC
C22 4030014400 S.CERAMIC
C24 4030014400 S.CERAMIC
C25 4030014400 S.CERAMIC
C26 4030014400 S.CERAMIC
C28 4030014390 S.CERAMIC
C29 4030014390 S.CERAMIC
J1 6510021010 CONNECTOR
DS1 5040002380 S.LED
DS2 5040002380 S.LED
DS3 5040002380 S.LED
DS4 5040002380 S.LED
MC1 7700002410 MICROPHONE
S1 2230001020 S.SWITCH
S2 2220000620 S.SWITCH
S3 2260002500 SWITCH
S4 2260002500 SWITCH
W1 8900007971 CABLE
EP1 0910057261 PCB
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LC7366NM-TRM <KN>
DTA114EUA T106 <KN>
MA8062-M (TX) <KN>
PRBC 3.58AR <KN>
LK1608-R82K-T <KN>
MCR03EZHJ 220 — (221) <KN> T
MCR03EZHJ 100 — (101) <KN> T
MCR03EZHJ 2.2 k — (222) <KN>
MCR03EZHJ 5.6 k — (562) <KN>
MCR03EZHJ 3.3 k — (332) <KN>
MCR03EZHJ 10 — (11) <KN>
MCR03EZHJ 3.3 k — (332) <KN>
MCR03EZHJ 3.3 k — (332) <KN>
MCR03EZHJ 470 — (471) <KN> T
MCR03EZHJ 1 k — (102) <KN>
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 47 k — (473) <KN> T
MCR03EZHJ 100 — (101) <KN> T
MCR03EZHJ 330 — (331) <KN> T
UMK107 CH 200JZ-T <KN>
UMK107 CH 200JZ-T <KN>
LMK212 BJ 105KG-T <KN>
TMK107 B 103KZ-T <KN>
LMK212 BJ 105KG-T <KN>
TMK107 B 102KZ-T <KN>
EMK212 BJ 334KG-T <KN>
LMK212 BJ 105KG-T <KN>
C1608 JB 1E 104K-T <KN>
UMK107 SL 470JZ-T <KN>
TMK107 B 102KZ-T <KN>
TMK107 B 103KZ-T <KN>
TMK107 B 102KZ-T <KN>
TMK107 B 102KZ-T <KN>
TMK107 B 102KZ-T <KN>
TMK107 B 102KZ-T <KN>
UMK107 SL 470JZ-T <KN>
UMK107 SL 470JZ-T <KN>
52018-8835 <KN>
SML-311YT T86 <KN>
SML-311YT T86 <KN>
SML-311YT T86 <KN>
SML-311YT T86 <KN>
KUB2823-011500 <KN>
JPM1990-2013R <KN>
SSSS81560A
SKHHLM
SKHHLM
OPC-762A <KN>
B 6021A
S.=Surface mount
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
B
B
B
T
T
T
T
B
B
B
B
B
T
T
T
T
T
6 - 17
