Template - Icom iM304 Instruction Manual

NOTE: The solid line is the line to use when cutting into the dash/helm. The dotted
line shows the outline of the IC-M304's front panel once the radio is fitted into the
hole. Do not follow the dotted line when making the hole in your dash/helm.
153.0 (6 1 ⁄ )
32
15
139.0 (5 ⁄ )
32
12

TEMPLATE

Unit: mm (inch)
11
12
39
