Specifications

DC VOLTAGE
RANGE
50.00 mV
500.0 mV
5.000V, 50.00V, 500.0V, 1000V
NMRR: >60dB @ 50/60Hz, CMRR: >120dB @ DC, 50/60Hz, Rs=1kΩ
Input impedance: 10MΩ, 16pF nominal (44pF nominal for 50mV & 500mV
ranges)
AC VOLTAGE
RANGE
50Hz/60Hz
50.00mV, 500.0mV, 5.000V, 50.00V, 500.0V, 1000V 0.5% + 3d
40Hz to 500Hz
50.00mV, 500.0mV
5.000V, 50.00V, 500.0V
1000V
Up to 20kHz
50.00mV, 500.0mV
5.000V, 50.00V, 500.0V
1000V
*Specified from 30% to 100% of range
CMRR: >60dB @ DC to 60Hz, Rs=1kΩ
Input Impedance: 10MΩ, 16pF nominal (44pF nominal for 50mV &
500mV ranges)
DC CURRENT
RANGE
500.0µA, 5000µA
50.00mA, 500.0mA
5.000A, 10.00A*
*10A continuous, 20A for 30 seconds max with a 5 minute cool down
interval
Accuracy
0.2% + 4d
Accuracy
0.12% + 2d
0.06% + 2d
0.08% + 2d
Accuracy
0.8% + 3d
1.0% + 4d
1.2% + 4d
0.5dB*
3dB*
Unspecified
Burden Voltage
0.15mV/µA
3.3mV/mA
0.03V/A
4
