Stati-Kit 2000™
Electrostatic Spraying System
Model 0292003
Register your product online at:
www.titantool.com
Proper registration will serve as proof of purchase in the event your
original receipt becomes misplaced or lost.
Owner's Manual
Do not use this equipment
before reading this manual!
NOTE: This manual contains important
warnings and instructions. Please
read and retain for reference.
© Titan Tool Inc. All Rights Reserved. Form No. 0292522G
0912
•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stati-Kit 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Titan Stati-Kit 2000

Summary of Contents for Titan Stati-Kit 2000

  • Page 1 Please read and retain for reference. Proper registration will serve as proof of purchase in the event your original receipt becomes misplaced or lost. © Titan Tool Inc. All Rights Reserved. Form No. 0292522G 0912 •...
  • Page 2 Wear a mask or respirator. Read all instructions for the mask to • DO NOT substitute any other spray gun or power pack with this insure that it will provide the necessary protection against the system. Use only identical replacement parts. inhalation of harmful vapors. © Titan Tool. All rights reserved.

  • Page 3: Table Of Contents

    Output Voltage ......80 KV Output Current max .....0.7 A Output Frequency ......17 kHz Power Cord ........9 ft. NOTE: Use only coating materials with a specific resistance of 50 - 3.5000 k Ohms. If you are not sure of the specific resistance, check with the coating supplier before using. © Titan Tool. All rights reserved.

  • Page 4: General Description

    SOCKET HIGH VOLTAGE ON - OFF SWITCH ELECTROSTATIC ON/OFF SWITCH GM 2000 HANDLE WITH HIGH VOLT- PAINT FILTER AGE GENERATOR TRIGGER AIR INLET VM200 FLUID INLET T0.2A Figure 1 GROUND CONNECTION FUSE Figure 2 © Titan Tool. All rights reserved.

  • Page 5: Mounting Arrangement

    3. Align support clamps (5) with mounting bracket (1), using the other allen wrench provided, attach the 2 pieces with the 4-1/4” lockwashers (6) and socket head screws (7), tightening down equally on both sides. Figure 3 © Titan Tool. All rights reserved.

  • Page 6: Setup

    1. Pulling the trigger part way - Only the air is on. 2. Pulling the trigger all the way - Both air and fluid are Figure 4 Power cord must remain intact. Do not clip off ground pole or plug to fit a non-grounded socket. Static build-up will result which may cause an explosion. © Titan Tool. All rights reserved.

  • Page 7: Cleanup

    • If defects in the equipment are found , DO NOT use • Clean the spray tip and air cap by removing from until repairs are completed. spray gun, rinsing in solvent, drying and replacing on spray gun. © Titan Tool. All rights reserved.

  • Page 8: Tip Change

    1. Remove air cap (H), see figure 8. between the air cap and tip body. 2. Remove flat spray tip (G) and clean it. 3. Carefully handle the carbide flat spray tip (G); avoid cleaning with a sharp-edged metal object. © Titan Tool. All rights reserved.

  • Page 9: Filter Replacement

    1. If there is evidence of material leakage past the front seal (10) lightly tighten the packing nut (11) with the universal wrench. Figure 10. Figure 11 Figure 10 Figure 12 © Titan Tool. All rights reserved.

  • Page 10: Troubleshooting

    Tip plugged. Unplug tip. Material leaks at joint between Gun barrel nut loose. Tighten nut. Do not overtighten. gun body and gun barrel when Material channel faulty. Take to Authorized Service Center. trigger is pulled. © Titan Tool. All rights reserved.
  • Page 11 Notes © Titan Tool. All rights reserved.

  • Page 12: Parts List

    Parts listing - gm 2000 Eac Figure 9 © Titan Tool. All rights reserved.
  • Page 13 Tip insert EACR 15, standard 0132724 Air cap EACR 0179536 Tip body, EACR 0179664 Locking screw 0132351 Diffuser with sealing nipple 0132516 Wrench Universal 0179901 Glove 9994682 Tip Wrench 0179902 Tip body removal tool 0179963 © Titan Tool. All rights reserved.

  • Page 14: Spare Tips

    0128215 18/50 .018 50° 0132731 R22/2 .0151 10.75 .0840 0128565 21/20 .021 20° 0128559 21/50 .021 50° 0128561 26/50 .026 50° 0128562 31/50 .031 50° 0128563 36/50 .036 50° accessories 0088154 Fluid pressure gauge © Titan Tool. All rights reserved.
  • Page 15 Notes © Titan Tool. All rights reserved.

  • Page 16: Warranty

    Titan Tool. Titan Tool will repair or replace, at its option, defective parts without charge if such parts are returned with transportation charges prepaid to the nearest authorized service agency or to Titan Tool, 1770 Fernbrook Lane, Plymouth, Minnesota, 55447.
