- Page 1 Active wheelchair User manual...
- Page 2 This product complies with Directive 93/42/EEC concerning medical devices. © Küschall AG, Switzerland Every effort has been made to ensure that the contents of this publication are fully up-to-date at the time of going to print. As part of its ongoing improvement of products, Küschall® AG re- serves the right to modify existing models at any time.
-
Page 3: Table Of Contents
K-Junior Contents Contents General 4.10 Seat cushion 4.11 Seat position Information about the User Manual 4.12 Accessories Symbols Guarantee Set-up Service life Using the wheelchair Copyright protection Safety information Safety Braking during use Safety information Getting in and out of the wheelchair... - Page 4 K-Junior Contents After use 10.1 Re-use 10.2 Disposal...
-
Page 5: General
K-Junior General 1 General IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided. 1.1 Information about the User Manual Tips and recommendations Thank you for choosing a Küschall® wheelchair. Gives useful tips, recommendations and information This User Manual contains important information about using for efficient, trouble-free use. -
Page 6: Service Life
K-Junior General arising from the rectification of defects such as freight and travel expenses, labour costs, fees etc. Term of the guarantee The term of the guarantee is 24 months. The frame is guaranteed for 5 years. Wearing parts are not covered by the guarantee. -
Page 7: Safety
K-Junior Safety WARNING! Risk due to wheelchair being out of 2 Safety control At high speed you could lose control of your This section contains important safety information for the wheelchair and overturn. protection of the wheelchair user and assistant and for safe, - Never exceed a speed of 7 km/h. -
Page 8: Correct Use
K-Junior Safety 2.2 Correct use The wheelchair is propelled manually and should only be used for independent or assisted transport of a disabled person with mobility difficulties. When used without an assistant, it should only be used by persons who are physically able to use the wheelchair safely (e.g. -
Page 9: Technical Data
K-Junior Technical data 3 Technical data 3.1 Dimensions and weight Seat width (SB) Seat depth (ST) 240 – 360 mm 250 – 400 mm Lower leg length Seat height front (UL) 150 – 410 mm (SHv) 380 – 450 mm... -
Page 10: Environmental Conditions
K-Junior Technical data 3.2 Environmental conditions 3.4 Identification label Do not expose the wheelchair to temperatures below -20°C or The identification label is attached to the frame of your above 40°C. wheelchair and gives the following information: 3.3 Tyre pressure... -
Page 11: Components And Their Function
Footrest Front wheel fork with front wheel Short description The Küschall K-Junior is a rigid frame wheelchair with folding backrest. The equipment of your wheelchair may differ from the diagram as each wheelchair is manufactured individually to the specifications in the order. -
Page 12: Parking Brakes
K-Junior Components and their function Standard brake 4.2 Parking brakes The parking brakes are used to immobilise the wheelchair when it is stationary to prevent it from rolling away. WARNING! Risk of overturning if you brake sharply... -
Page 13: Backrest
K-Junior Components and their function Active brake Adjusting the backrest cover To apply the brake, pull the brake lever forwards beside or between your knees as far as possible. To release the brake, push the brake lever backwards beside or between your knees. -
Page 14: Push Handles
K-Junior Components and their function Backrest angle The angle of the backrest can be adjusted. The adjustment must be carried out by the specialist dealer. Backrest bar WARNING! Risk of accidents The backrest bar is not suited for lifting or carrying the wheelchair with the user sitting in it as it can break. -
Page 15: Buggy-Pushhandle
K-Junior Components and their function Height adjustable, angled push handles Buggy-Pushhandle fixation (optional) The buggy-pushhandle is attached to the wheelchair by an adapter, which is mounted to the axle tube. The infinitely height adjustable push handles allow any assistant to adjust the handles to a comfortable level. -
Page 16: Sides
K-Junior Components and their function Pushhandle height adjustment 4.6 Sides Simple armrest, height-adjustable, swivelling Loosen the release handle and swing the handle into the required position. Removing Refasten the release handle again ... -
Page 17: Antitipper
K-Junior Components and their function Swivelling CAUTION! Risk of tipping Raise the armrest a little and swivel it outwards. An activated antitipper can catch when negotiating a step or an edge. Mudguard Always deactivate the antitipper before driving over In order to prevent dirt from the wheels spraying upwards, a a step or kerb. -
Page 18: Rear Wheel Extension
K-Junior Components and their function 4.9 Rear wheel extension Your wheelchair can be fitted with a rear wheel extension. The rear wheel extension makes it possible to alter the position of the rear wheel and thus the tipping stability of the wheelchair. -
Page 19: Seat Position
K-Junior Components and their function 4.11 Seat position 4.12 Accessories The seat position and thus the tipping stability of your Postural belt wheelchair can be altered. The adjustment must be carried Your wheelchair can be fitted with a postural belt. The out by the specialist dealer. -
Page 20: Air Pump
K-Junior Components and their function Air pump The air pump is fitted with a universal valve connection. Remove the dust cap from the valve connection. Push the valve connection onto the open valve on the wheel and pump the wheel up. - Page 21 K-Junior Components and their function Prior to removing the rear wheels, the distance between the lowered transit wheels and the floor should not be more than 2 cm. Switching from transit wheels to rear wheels Move the wheelchair to a stable object, which you can use for support and hold onto it firmly with one hand.
-
Page 22: Set-Up
K-Junior Set-up 5 Set-up CAUTION! Before using the wheelchair, check its general condition and its main functions. (See Section 8 – Maintenance) Your specialist dealer will supply your wheelchair ready for use. Your dealer will explain the main functions and ensure that the wheelchair meets your needs and requirements . -
Page 23: Using The Wheelchair
K-Junior Using the wheelchair 6.2 Braking during use 6 Using the wheelchair Whilst you are moving, you brake by transferring force to the handrim with your hands. 6.1 Safety information Hold the handrims and press evenly with both hands until CAUTION! Risk of crushing the wheelchair stops. -
Page 24: Getting In And Out Of The Wheelchair
K-Junior Using the wheelchair 6.3 Getting in and out of the wheelchair Hold the wheelchair and, if necessary, also hold a fixed object in the vicinity. WARNING! Risk of overturning 6.4 Driving and steering the wheelchair There is a high risk of overturning during the transfer. -
Page 25: Negotiating Steps And Kerbs
K-Junior Using the wheelchair Finding the tipping point - Do not go up or down steps that are higher than 25 cm. CAUTION An activated antitipper prevents the wheelchair from tipping backwards. - Deactivate the antitipper before going up or down steps or kerbs. -
Page 26: Going Up And Down Stairs
K-Junior Using the wheelchair Going down a step Move the wheelchair right up to the kerb and hold the handrims. The assistant should hold both push handles, place one foot on the tipper aid (if installed) and tilt the wheelchair backwards so that the front wheels lift off the ground. -
Page 27: Negotiating Ramps And Slopes
K-Junior Using the wheelchair 6.7 Negotiating ramps and slopes WARNING! Risk due to wheelchair being out of control When negotiating slopes or gradients your wheelchair could tip backwards, forwards or sideways. - Always have an assistant behind the wheelchair when approaching long slopes. -
Page 28: Stability And Balance When Seated
K-Junior Using the wheelchair Bend your upper body forwards and propel the Lean back and carefully allow the handrims to run wheelchair with quick, powerful strokes on both through your hands. You should be able to stop the handrims. - Page 29 K-Junior Using the wheelchair Leaning forwards When leaning forwards your upper body must remain over the front wheels. WARNING! Risk of falling out Reaching backwards If you lean forwards out of the wheelchair you could fall out of it. Never bend too far forwards and do not WARNING! Risk of falling out shift forwards in your seat to reach an object.
-
Page 30: Transport
K-Junior Transport 7.2 Folding and unfolding the wheelchair 7 Transport The wheelchair has a rigid frame. Nevertheless, the backrest can be folded forwards and fixed there. 7.1 Safety information Folding the wheelchair WARNING! Risk of injury if wheelchair is not secured during transport ... -
Page 31: Removing And Fitting The Rear Wheels
K-Junior Transport Pull the backrest backwards using the backrest brace, until the backrest tube engages on both sides of the frame. Fold the clothes-guard back into position on both sides. IMPORTANT! When unfolding the wheelchair, do not pull the backrest brace without previously releasing the backrest using the cord. - Page 32 K-Junior Transport Fitting the rear wheels Release the brakes. With one hand, hold the wheelchair upright. With the other, hold the wheel through the external spoke rim around the wheel hub. Using your thumb, press the removable axle button and hold it down.
-
Page 33: Maintenance
K-Junior Maintenance Check the tyre pressure 8 Maintenance Check the tyre pressure ( Pressure table in Section 3 - Technical data). 8.1 Maintenance schedule Inflate the tyres to the required pressure. To ensure safe and reliable operation, carry out the following ... - Page 34 K-Junior Maintenance Clean the front wheels IMPORTANT The parking brakes must be reset after replacing the Check that the front wheels turn freely. rear wheels or changing their position. Remove any dirt or hair from the front wheel bearings.
-
Page 35: Cleaning
K-Junior Maintenance If the wheelchair is dirty, wipe off the dirt as soon as check all the way round to ensure that the inner tube is possible with a damp cloth and dry it carefully. not trapped between the tyre and the rim. -
Page 36: Troubleshooting
K-Junior Troubleshooting 9 Troubleshooting Faults may arise as a result of daily use, adjustments or changing demands on the wheelchair. The table below shows how to identify and repair faults. CAUTION! Contact your specialist dealer immediately if you notice a fault with your wheelchair, e.g. -
Page 37: Identifying And Repairing Faults
K-Junior Troubleshooting 9.1 Identifying and repairing faults Fault Possible cause Action The wheelchair does not travel Incorrect tyre pressure on one rear wheel Correct tyre pressure (Section 3 - Technical data) in a straight line One or more spokes broken Replace faulty spoke(s) (specialist dealer) -
Page 38: After Use
K-Junior After use 10 After use 10.1 Re-use The wheelchair is suitable for re-use. The following actions should be taken: Cleaning and disinfection according to Section 8 - Cleaning in this manual. Inspection according to Chapter 8 - Maintenance schedule in this manual. - Page 39 küschall® distributors Belgium & Luxemburg: Invacare nv • Autobaan 22 • B-8210 Loppem Tel: (32) (0)50 83 10 10 • Fax: (32) (0)50 83 10 11 • belgium@invacare.com Danmark: Invacare A/S • Sdr. Ringvej 37 • DK-2605 Brøndby Tel: (45) (0)36 90 00 00 • Fax: (45) (0)36 90 00 01 • denmark@invacare.com Deutschland: Invacare Aquatec GmbH •...
- Page 40 Küschall AG Benkenstrasse 260 CH-4108 Witterswil kueschall@invacare.com www.kueschall.com ENGLISH 2011-04 1492199...
