- Page 1 OPERATION MANUAL Packaged air-cooled water chillers and packaged reversible air to water heat pumps EWAQ005ADVP EWAQ006ADVP EWAQ007ADVP EWYQ005ADVP EWYQ006ADVP EWYQ007ADVP...
-
Page 2: Table Of Contents
Before operating the unit, make sure the installation has 2.1. Features and functions been carried out correctly by a professional Daikin dealer. The digital controller is a state of the art controller that offers full If you feel unsure about operation, contact your Daikin control over your installation. -
Page 3: Name And Function Of Buttons And Icons
These icons indicate that inspection is required on the installation manual), the schedule timer button will not be operational. installation. Consult your Daikin Dealer. SET TEMPERATURE DISPLAY 9 TIME ADJUST BUTTON pi and pj The display shows the current set temperature of the installation. -
Page 4: Setting Up The Controller
■ when the desired defrost temperature is reached, required to be able to use the schedule timer. i.e. defrost stop temperature (contact your local Daikin dealer). 2.3.1. Setting the clock Heating operation restarts automatically when the Hold down the pr button for 5 seconds. - Page 5 Selection and setting of cooling (c c c c ) and heating (h h h h ) 2.5.3. Weather dependent operation (heat pump models only) Use the = button to select cooling (c) or heating (h). In weather dependent operation (icon a is shown), the controller Icon appears on the display as well as the corresponding calculates the water temperature set point based on the outdoor...
-
Page 6: Programming And Consulting The Schedule Timer
2.6. Programming and consulting the schedule timer What can the schedule timer do? The schedule timer allows the following programming of heating or 2.6.1. Getting started cooling: switch on the desired mode at a scheduled time, in Programming the schedule timer is flexible (you can add, remove or combination with a set point (automatically calculated or manually alter programmed actions whenever required) and straightforward set). - Page 7 2.6.2. Programming Programming cooling or heating is carried out as follows. Programming cooling or heating NOTE Returning to previous steps in the programming procedure without saving modified settings is done by pressing the pr button. Use the = button to select the operation mode (cooling or heating) you want to program.
- Page 8 Programming quiet mode 10 Press the < button for 5 seconds to store the programmed actions. If the < button is pressed when action number 3 is displayed, actions 1, 2 and 3 are stored but 4 and 5 are deleted. You automatically return to step 4.
-
Page 9: Maintenance
Use the pi and pj buttons to select the mode you want at regular intervals, preferably yearly. This maintenance should be to program. carried out by your local Daikin technician. The selected mode is blinking. Besides keeping the remote controller clean by means of a soft damp You can leave programming by pressing the pr button. - Page 12 4PW71885-1 10.2011...
