ESIE07-04
Service Manual
EWAD650-C18BJYNN
EWAD550-C12BJYNN/Q
EWAD650-C21BJYNN/A
EWAD600-C10BJYNN/Z
Air-cooled chillers and heat recovery chillers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWAD650-C18BJYNN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daikin EWAD650-C18BJYNN

Summary of Contents for Daikin EWAD650-C18BJYNN

  • Page 1 ESIE07-04 Service Manual EWAD650-C18BJYNN EWAD550-C12BJYNN/Q EWAD650-C21BJYNN/A EWAD600-C10BJYNN/Z Air-cooled chillers and heat recovery chillers...

  • Page 3: Table Of Contents

    ESIE07-04 Table of Contents Introduction About This Manual .................. Nomenclature..................Part 1 System Outline General Outline What Is in This Chapter? ................ 1–3 Technical Specifications: EWAD-BJYNN..........1–6 Technical Specifications: EWAD-BJYNN with OPRN ......1–8 Technical Specifications: EWAD-BJYNN with OPLN......1–10 Technical Specifications: EWAD BJYNN/Q ..........
  • Page 4 ESIE07-04 1.32 Outlook Drawing: EWAD850BJYNN/A+OPTP, EWAD850BJYNN/ A+OPRN+OPTP, EWAD850BJYNN/A+OPLN+OPTP, EWAD900BJYNN/ A+OPTP, EWAD900BJYNN/A+OPRN+OPTP and EWAD900BJYNN/ A+OPLN+OPTP..................1–56 1.33 Outlook Drawing: EWAD900-950BJYNN/Q and EWAD850BJYNN/Z ..1–58 1.34 Outlook Drawing: EWAD900BJYNN, EWAD900BJYNN+OPRN and EWAD900BJYNN+OPLN ................ 1–60 1.35 Outlook Drawing: EWAD900BJYNN+OPPR, EWAD900BJYNN+OPPR +OPRN and EWAD900BJYNN+OPPR+OPLN........1–62 1.36 Outlook Drawing: EWAD900BJYNN/A, EWAD900BJYNN/A +OPRN and...
  • Page 5 ESIE07-04 1.64 Outlook Drawing: EWAD650BJYNN/A, EWAD650BJYNN/A+OPRN and EWAD650BJYNN/A+OPLN ..............1–120 1.65 Outlook Drawing: EWAD650BJYNN/A+OPSP, EWAD650BJYNN/A+ OPSP+OPRN and EWAD650BJYNN/A+OPSP+OPLN......1–122 1.66 Outlook Drawing: EWAD650BJYNN/Q ........... 1–124 1.67 Outlook Drawing: EWAD650BJYNN/Q+OPTP ........1–126 Part 2 Functional Description Operation Range What Is in This Chapter? ................ 2–3 Operational Range: EWAD-BJYNN ............
  • Page 6 ESIE07-04 Functional Control What Is In This Chapter? ................. 2–73 ON / OFF Management ................2–75 Thermostat Control .................. 2–76 Setpoint Reset of the Chilled Water............2–81 Return Water Reset ................. 2–84 Freeze-up Control..................2–85 Enable Soft Load ..................2–87 Unit Load Limiting ..................
  • Page 7 ESIE07-04 Procedure for Software Upload/Download What is in This Chapter?................. 3–13 Copy from the Software Key to pCO² ............. 3–14 Copy from pCO² to the Software Key ............. 3–15 Installation of Winload32 on the PC and Programming a Controller..3–16 Copy Software from WinLoad32 to the Software key ......
  • Page 8 ESIE07-04 Procedure for the Changing and Configuration of the Expansion I/O Board (Optional)ì What is in This Chapter? ................. 3–45 Changing the PCO² Expansion Board ............. 3–46 Manual Upload or Download Control Test Procedure 10.1 What is in This Chapter? ................. 3–47 10.2 Manual Upload or Download Control Test Procedure ......
  • Page 9 ESIE07-04 Part 5 Maintenance Maintenance What Is in This Chapter ................5–3 System Maintenance ................5–4 Preventive Maintenance Schedule ............5–8 Start-up and Shut-down ................5–9 Seasonal Shut-down................5–10 Maintenance Shut-down ................. 5–11 Periodical Checks ................... 5–12 Table of Contents...
  • Page 10 ESIE07-04 viii Table of Contents...

  • Page 11: About This Manual

    Purpose of this This service manual contains all the information you need to carry out the necessary repair and manual maintenance tasks for the EWAD650-C18BJYNN, EWAD550-C12BJYNN/Q, EWAD650-C21BJYNN/A and EWAD600-C10BJYNN/Z. 4 different lines EWAD-BJYNN line is available with two different efficiencies in order to satisfy every kind of requirements.

  • Page 12: Nomenclature

    Introduction ESIE 07-04 Nomenclature **** Machine type ERA: Air cooled condensing unit EWW: Water cooled packaged water chiller EWL: Remote condenser water chiller EWA: Air cooled chiller, cooling only EWY: Air cooled chiller, heatpump EWC: Air cooled chiller, cooling only with centrifugal fan EWT: Air cooled chiller, cooling only with heat recovery Refrigerant D: R-134a...

  • Page 13: System Outline

    ESIE07-04 Part 1 System Outline Introduction This part contains an outline of all the relevant elements in the EWAD650-C18BJYNN, EWAD550-C12BJYNN/Q, EWAD650-C21BJYNN/A and EWAD600-C10BJYNN/Z installation. What is in this part? This part contains the following chapters: Chapter See page 1–General Outline 1–3...
  • Page 14 ESIE07-04 1–2 Part 1 – System Outline...

  • Page 15: General Outline

    ESIE07-04 General Outline Part 1 General Outline What Is in This Chapter? Introduction This chapter contains the following information: Technical specifications Electrical specifications Correction factors Outlook drawings: Outlook, dimensions, installation and service space. Overview This chapter contains the following topics: Topic See page 1.2–Technical Specifications: EWAD-BJYNN...
  • Page 16 General Outline ESIE07-04 Topic See page 1.27–Outlook Drawing: EWAD750BJYNN/Q+OPSP 1–46 1.28–Outlook Drawing: EWAD800-850BJYNN/Q 1–48 1.29–Outlook Drawing: EWAD800BJYNN/A, EWAD800BJYNN/A+OPRN and 1–50 EWAD800BJYNN/A+OPLN 1.30–Outlook Drawing: EWAD850BJYNN, EWAD850BJYNN+OPRN and 1–52 EWAD850BJYNN+OPLN 1.31–Outlook Drawing: EWAD850BJYNN/A, EWAD850BJYNN/A+OPRN and 1–54 EWAD850BJYNN/A+OPLN 1.32–Outlook Drawing: EWAD850BJYNN/A+OPTP, 1–56 EWAD850BJYNN/A+OPRN+OPTP, EWAD850BJYNN/A+OPLN+OPTP, EWAD900BJYNN/A+OPTP, EWAD900BJYNN/A+OPRN+OPTP and EWAD900BJYNN/A+OPLN+OPTP 1.33–Outlook Drawing: EWAD900-950BJYNN/Q and EWAD850BJYNN/Z...
  • Page 17 ESIE07-04 General Outline Topic See page 1.53–Outlook Drawing: EWADC16BJYNN, EWADC16BJYNN+OPRN and 1–98 EWADC16BJYNN+OPLN 1.54–Outlook Drawing: EWADC16BJYNN/A, EWADC16BJYNN/A+OPRN and 1–100 EWADC16BJYNN/A+OPLN 1.55–Outlook Drawing: EWADC17BJYNN/A, EWADC17BJYNN/A+OPRN and 1–102 EWADC17BJYNN/A+OPLN 1.56–Outlook Drawing: EWADC17BJYNN/A+OPTR, 1–104 EWADC17BJYNN/A+OPRN+OPTR and EWADC17BJYNN/A+OPLN+OPTR 1.57–Outlook Drawing: EWADC18BJYNN/A, EWADC18BJYNN/A+OPRN and 1–106 EWADC18BJYNN/A+OPLN 1.58–Outlook Drawing: EWADC19BJYNN/A, EWADC19BJYNN/A+OPRN and 1–108...

  • Page 18: Technical Specifications: Ewad-Bjynn

    General Outline ESIE07-04 Technical Specifications: EWAD-BJYNN Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN Unit size Cooling capacity (1) Power input (1) 2.94 3.01 3.01 3.03 3.15 Screw compressors N° Refrigerant circuits N° Refrigerant charge R-134a Oil charge Min % of capacity reduction 12.5 12.5...
  • Page 19 ESIE07-04 General Outline Model EWAD-BJYNN Unit size Note (2) Weight and dimensions Standard unit shipping weight 7550 7830 7830 8420 8420 Standard unit operating weight 7970 8250 8250 8830 8830 Unit length 7400 8270 8270 9200 9200 Unit width 2230 2230 2230 2230...

  • Page 20: Technical Specifications: Ewad-Bjynn With Oprn

    General Outline ESIE07-04 Technical Specifications: EWAD-BJYNN with OPRN Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN with OPRN Unit size Cooling capacity (1) Power input (1) 2.58 2.68 2.71 2.71 2.84 Screw compressors N° Refrigerant circuits N° Refrigerant charge R-134a Oil charge Min % of capacity reduction...
  • Page 21 ESIE07-04 General Outline Model EWAD-BJYNN with OPRN Unit size Note (2) Weight and dimensions Standard unit shipping weight 7550 7830 7830 8420 8420 Standard unit operating weight 7970 8250 8250 8830 8830 Unit length 7400 8270 8270 9200 9200 Unit width 2230 2230 2230...

  • Page 22: Technical Specifications: Ewad-Bjynn With Opln

    General Outline ESIE07-04 Technical Specifications: EWAD-BJYNN with OPLN Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN with OPLN Unit size Cooling capacity (1) Power input (1) 2.58 2.68 2.71 2.71 2.84 Screw compressors N° Refrigerant circuits N° Refrigerant charge R-134a Oil charge Min % of capacity reduction...
  • Page 23 ESIE07-04 General Outline Model EWAD-BJYNN with OPLN Unit size Note (2) Weight and dimensions Standard unit shipping weight 7910 8190 8190 8780 8930 Standard unit operating weight 8330 8610 8610 9190 9340 Unit length 7400 8270 8270 9200 9200 Unit width 2230 2230 2230...

  • Page 24: Technical Specifications: Ewad Bjynn/Q

    General Outline ESIE07-04 Technical Specifications: EWAD BJYNN/Q Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN/Q Unit size Cooling capacity (1) Cooling capacity (1) Power input (1) 2.35 2.43 2.48 2.48 2.47 2.39 Screw compressors N° Refrigerant circuits N°...
  • Page 25 ESIE07-04 General Outline Model EWAD-BJYNN/Q Unit size Condenser coil Coil type Lanced fins - internally spiral wound tubes Weight and dimensions Standard unit shipping weight 8190 8725 8725 9310 9310 9750 Standard unit operating weight 8610 9150 9150 9720 9720 10160 Unit length 8300...

  • Page 26: Technical Specifications: Ewad-Bjynn/A

    General Outline ESIE07-04 Technical Specifications: EWAD-BJYNN/A Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN/A Unit size Cooling capacity (1) Power input (1) 3.27 3.33 3.38 3.36 3.37 3.57 Screw compressors N° Refrigerant circuits N° Refrigerant charge R-134a Oil charge Min % of capacity reduction 12.5...
  • Page 27 ESIE07-04 General Outline Model EWAD-BJYNN/A Unit size Condenser coil Coil type Lanced fins - internally spiral wound tubes Weight and dimensions Standard unit shipping weight 6563 8420 8420 8950 8950 9390 9540 Standard unit operating weight 6967 8830 8830 9360 9360 9800 9950...

  • Page 28: Technical Specifications: Ewad-Bjynn/A With Oprn

    General Outline ESIE07-04 Technical Specifications: EWAD-BJYNN/A with OPRN Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN/A with OPRN Unit size Cooling capacity (1) Power input (1) 2.97 3.02 3.03 3.04 3.08 3.30 Screw compressors N° Refrigerant circuits N°...
  • Page 29 ESIE07-04 General Outline Model EWAD-BJYNN/A with OPRN Unit size Weight and dimensions Standard unit shipping weight 6563 8420 8420 8950 8950 9390 9540 Standard unit operating weight 6967 8830 8830 9360 9360 9800 9950 Unit length 8300 9200 9200 10100 10100 11000 11000...

  • Page 30: Technical Specifications: Ewad-Bjynn/A With Opln

    General Outline ESIE07-04 Technical Specifications: EWAD-BJYNN/A with OPLN Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN/A with OPLN Unit size Cooling capacity (1) Power input (1) 2.97 3.02 3.03 3.04 3.08 3.30 Screw compressors N° Refrigerant circuits N°...
  • Page 31 ESIE07-04 General Outline Model EWAD-BJYNN/A with OPLN Unit size Weight and dimensions Standard unit shipping weight 6803 8780 8780 9310 9310 9750 9900 Standard unit operating weight 7207 9190 9190 9720 9720 10160 10310 Unit length 8300 9200 9200 10100 10100 11000 11000...

  • Page 32: Technical Specifications: Ewad-Bjynn/Z

    General Outline ESIE07-04 Technical Specifications: EWAD-BJYNN/Z Technical The table below contains the technical specifications. specifications Model EWAD-BJYNN/Z Unit size Cooling capacity (1) 1013 Power input (1) 2,64 2,66 2,53 2,61 2,72 2,64 2,80 Screw compressors Refrigerant circuits Refrigerant charge R-134a Oil charge Min % of capacity reduction 12.5...

  • Page 33: Electrical Specifications: Ewad-Bjynn

    ESIE07-04 General Outline 1.10 Electrical Specifications: EWAD-BJYNN Electrical The tabel below contains the electrical specifications specifications Model EWAD-BJYNN Unit size Standard voltage (1) 400 V - 3f - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4) Max unit current for wires sizing (5)

  • Page 34: Electrical Specifications: Ewad-Bjynn With Oprn

    General Outline ESIE07-04 1.11 Electrical Specifications: EWAD-BJYNN with OPRN Electrical The tabel below contains the electrical specifications specifications Model EWAD-BJYNN with OPRN Unit size Standard voltage (1) 400 V - 3f - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4)

  • Page 35: Electrical Specifications Ewad-Bjiynn With Opln

    ESIE07-04 General Outline 1.12 Electrical Specifications EWAD-BJIYNN with OPLN Electrical The table below contains the electrical specifications. specifications Model EWAD-BJYNN with OPLN Unit size Standard voltage (1) 400 V - 3f - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4)

  • Page 36: Electrical Specifications: Ewad-Bjynn/Q

    General Outline ESIE07-04 1.13 Electrical Specifications: EWAD-BJYNN/Q Electrical The table below contains the electrical specifications. specifications Model EWAD-BJYNN/Q Unit size Standard voltage (1) 400 V - 3f - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4) Max unit current for wires sizing (5)

  • Page 37: Electrical Specifications: Ewad-Bjynn/A

    ESIE07-04 General Outline 1.14 Electrical Specifications: EWAD-BJYNN/A Electrical The table below contains the electrical specifications specifications Model EWAD-BJYNN/A Unit size Standard voltage (1) 400 V - 3f - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4) Max unit current for wires sizing (5)

  • Page 38: Electrical Specifications: Ewad-Bjynn/A With Oprn

    General Outline ESIE07-04 1.15 Electrical Specifications: EWAD-BJYNN/A with OPRN Electrical The table below contains the electrical specifications specifications Model EWAD-BJYNN/A with OPRN Unit size Standard voltage (1) 400 V - 3f - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4)

  • Page 39: Electrical Specifications: Ewad-Bjynn/A With Opln

    ESIE07-04 General Outline 1.16 Electrical Specifications: EWAD-BJYNN/A with OPLN Electrical The table below contains the electrical specifications specifications Model EWAD-BJYNN/A with OPLN Unit size Standard voltage (1) 400 V - 3f - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4)

  • Page 40: Electrical Specifications: Ewad-Bjynn/Z

    General Outline ESIE07-04 1.17 Electrical Specifications: EWAD-BJYNN/Z Electrical The table below contains the electrical specifications specifications Model EWAD-BJYNN/Z Unit size Standard voltage (1) 400 V - 3ph - 50 Hz Nominal unit current (2) Max compressor current (3) Fans current Max unit current (3) Max unit inrush current (4) Max unit current for wires sizing (5)

  • Page 41: Correction Factors

    ESIE07-04 General Outline 1.18 Correction Factors Evaporator fouling The table below gives the evaporator fouling factors. factors Fouling factors Cooling capacity Power input corretion m2°C / kW correction factor factor correction factor 0.0176 1.000 1.000 1.000 0.0440 0.978 0.986 0.992 0.0880 0.957 0.974...

  • Page 42: Outlook Drawing: Ewad550Bjynn/Q

    General Outline ESIE07-04 1.19 Outlook Drawing: EWAD550BJYNN/Q The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water See detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 43 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 44: Outlook Drawing: Ewad600Bjynn/Q

    General Outline ESIE07-04 1.20 Outlook Drawing: EWAD600BJYNN/Q The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water See detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 45 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 46: Outlook Drawing: Ewad600Bjynn/Q+Optp

    General Outline ESIE07-04 1.21 Outlook Drawing: EWAD600BJYNN/Q+OPTP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) ''Victaulic'' coupling-furnished Connecting pipe-furnished See detail B (Frame) Optional right hand evaporator water Fan arrangements and minimum See detail A...
  • Page 47 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Evaporator-pump water outlet victaulic connection for 139.7 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.

  • Page 48: Outlook Drawing: Ewad700Bjynn, Ewad700Bjynn+Oprn And Ewad700Bjynn+Opln

    General Outline ESIE07-04 1.22 Outlook Drawing: EWAD700BJYNN, EWAD700BJYNN+OPRN and EWAD700BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 49 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.

  • Page 50: Outlook Drawing: Ewad700Bjynn+Optp, Ewad700Bjynn+Oprn+Optp And Ewad700Bjynn+Opln+Optp

    General Outline ESIE07-04 1.23 Outlook Drawing: EWAD700BJYNN+OPTP, EWAD700BJYNN+OPRN+OPTP and EWAD700BJYNN+OPLN+OPTP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) ''Victaulic''coupling-furnished Connecting pipe-furnished detail B (Frame) Optional right hand evaporator water See detail A Fan arrangements and minimum...
  • Page 51 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator-pump water outlet victaulic connection for 139.7 O.D. tube Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.

  • Page 52: Outlook Drawing: Ewad700Bjynn/A, Ewad700Bjynn/A+Oprn And Ewad700Bjynn/A+Opln

    General Outline ESIE07-04 1.24 Outlook Drawing: EWAD700BJYNN/A, EWAD700BJYNN/A+OPRN and EWAD700BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 53 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 54: Outlook Drawing: Ewad700Bjynn/Q And Ewad650Bjynn/Z

    General Outline ESIE07-04 1.25 Outlook Drawing: EWAD700BJYNN/Q and EWAD650BJYNN/Z The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 55 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 56: Outlook Drawing: Ewad750Bjynn/Q And Ewad700Bjynn/Z

    General Outline ESIE07-04 1.26 Outlook Drawing: EWAD750BJYNN/Q and EWAD700BJYNN/Z The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 57 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 58: Outlook Drawing: Ewad750Bjynn/Q+Opsp

    General Outline ESIE07-04 1.27 Outlook Drawing: EWAD750BJYNN/Q+OPSP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) (Frame) Optional right hand evaporator water See detail A Isolators location Detail "A"...
  • Page 59 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator DN 150 PN 10 flange connection for 168.3 O.D. tube evaporator water inlet DN 125 PN 10 flange connection for 139.7 O.D. tube evaporator-pump water outlet Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles...

  • Page 60: Outlook Drawing: Ewad800-850Bjynn/Q

    General Outline ESIE07-04 1.28 Outlook Drawing: EWAD800-850BJYNN/Q The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Isolators location Detail "A"...
  • Page 61 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 62: Outlook Drawing: Ewad800Bjynn/A, Ewad800Bjynn/A+Oprn And Ewad800Bjynn/A+Opln

    General Outline ESIE07-04 1.29 Outlook Drawing: EWAD800BJYNN/A, EWAD800BJYNN/A+OPRN and EWAD800BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 63 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 64: Outlook Drawing: Ewad850Bjynn, Ewad850Bjynn+Oprn And Ewad850Bjynn+Opln

    General Outline ESIE07-04 1.30 Outlook Drawing: EWAD850BJYNN, EWAD850BJYNN+OPRN and EWAD850BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 65 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 66: Outlook Drawing: Ewad850Bjynn/A, Ewad850Bjynn/A+Oprn And Ewad850Bjynn/A+Opln

    General Outline ESIE07-04 1.31 Outlook Drawing: EWAD850BJYNN/A, EWAD850BJYNN/A+OPRN and EWAD850BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 67 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 68: Outlook Drawing: Ewad850Bjynn/A+Optp, Ewad850Bjynn/A+Oprn+Optp, Ewad850Bjynn/A+Opln+Optp, Ewad900Bjynn/A+Optp, Ewad900Bjynn/A+Oprn+Optp And Ewad900Bjynn/A+Opln+Optp

    General Outline ESIE07-04 1.32 Outlook Drawing: EWAD850BJYNN/A+OPTP, EWAD850BJYNN/A+OPRN+OPTP, EWAD850BJYNN/A+OPLN+OPTP, EWAD900BJYNN/A+OPTP, EWAD900BJYNN/A+OPRN+OPTP and EWAD900BJYNN/A+OPLN+OPTP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A...
  • Page 69 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator-pump water outlet victaulic connection for 139.7 O.D. tube Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 70: Outlook Drawing: Ewad900-950Bjynn/Q And Ewad850Bjynn/Z

    General Outline ESIE07-04 1.33 Outlook Drawing: EWAD900-950BJYNN/Q and EWAD850BJYNN/Z The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Fixing bolt (not furnished) Isolators location...
  • Page 71 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection Compressor enclosure Coil protection guards (optional) 8 isolator mounting holes 25 mm DIA.

  • Page 72: Outlook Drawing: Ewad900Bjynn, Ewad900Bjynn+Oprn And Ewad900Bjynn+Opln

    General Outline ESIE07-04 1.34 Outlook Drawing: EWAD900BJYNN, EWAD900BJYNN+OPRN and EWAD900BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 73 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 74: Outlook Drawing: Ewad900Bjynn+Oppr, Ewad900Bjynn+Oppr+Oprn And Ewad900Bjynn+Oppr+Opln

    General Outline ESIE07-04 1.35 Outlook Drawing: EWAD900BJYNN+OPPR, EWAD900BJYNN+OPPR+OPRN and EWAD900BJYNN+OPPR+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand detail B evaporator water (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 75 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 76: Outlook Drawing: Ewad900Bjynn/A, Ewad900Bjynn/A +Oprn And Ewad900Bjynn/A+Opln

    General Outline ESIE07-04 1.36 Outlook Drawing: EWAD900BJYNN/A, EWAD900BJYNN/A +OPRN and EWAD900BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum...
  • Page 77 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 78: Outlook Drawing: Ewad900Bjynn/A+Oppr, Ewad900Bjynn/A+Oprn+Oppr And Ewad900Bjynn/A+Opln+Oppr

    General Outline ESIE07-04 1.37 Outlook Drawing: EWAD900BJYNN/A+OPPR, EWAD900BJYNN/A+OPRN+OPPR and EWAD900BJYNN/A+OPLN+OPPR The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand detail B evaporator water (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 79 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 80: Outlook Drawing: Ewad950Bjynn, Ewad950Bjynn+Oprn And Ewad950Bjynn+Opln

    General Outline ESIE07-04 1.38 Outlook Drawing: EWAD950BJYNN, EWAD950BJYNN+OPRN and EWAD950BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 81 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 82: Outlook Drawing: Ewad950Bjynn+Opsp, Ewad950Bjynn+Oprn+Opsp And Ewad950Bjynn+Opln+Opsp

    General Outline ESIE07-04 1.39 Outlook Drawing: EWAD950BJYNN+OPSP, EWAD950BJYNN+OPRN+OPSP and EWAD950BJYNN+OPLN+OPSP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) L=7400 Unity with standard control panel L=7500 Unity with soft starter in the control panel See detail A Fan arrangements and minimum...
  • Page 83 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator-pump water outlet victaulic connection for 114.3 O.D. tube Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 84: Outlook Drawing: Ewad950Bjynn/A, Ewad950Bjynn/A+Oprn And Ewad950Bjynn/A+Opln

    General Outline ESIE07-04 1.40 Outlook Drawing: EWAD950BJYNN/A, EWAD950BJYNN/A+OPRN and EWAD950BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 85 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 86: Outlook Drawing: Ewad950Bjynn/A+Otpt, Ewad950Bjynn/A+Oprn+Optp And Ewad950Bjynn/A+Opln+Optp

    General Outline ESIE07-04 1.41 Outlook Drawing: EWAD950BJYNN/A+OTPT, EWAD950BJYNN/A+OPRN+OPTP and EWAD950BJYNN/A+OPLN+OPTP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 87 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator-pump water outlet connection for 139.7 O.D. tube Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 88: Outlook Drawing: Ewad950Bjynn/Z And Ewadc11Bjynn/Q

    General Outline ESIE07-04 1.42 Outlook Drawing: EWAD950BJYNN/Z and EWADC11BJYNN/Q The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Isolators location Detail "A"...
  • Page 89 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 10 isolator mounting holes 25 mm DIA.

  • Page 90: Outlook Drawing: Ewadc10Bjynn/A, Ewadc10Bjynn/A+Oprn And Ewadc10Bjynn/A+Opln

    General Outline ESIE07-04 1.43 Outlook Drawing: EWADC10BJYNN/A, EWADC10BJYNN/A+OPRN and EWADC10BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 91 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 92: Outlook Drawing: Ewadc10Bjynn/A+Opsp, Ewadc10Bjynn/A+Oprn+Opsp And Ewadc10Bjynn/A+Opln+Opsp

    General Outline ESIE07-04 1.44 Outlook Drawing: EWADC10BJYNN/A+OPSP, EWADC10BJYNN/A+OPRN+OPSP and EWADC10BJYNN/A+OPLN+OPSP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail C detail B (Frame) See detail A Fan arrangements and minimum...
  • Page 93 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Victaulic connection for tube 139.7 (evaporator) water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 94: Outlook Drawing: Ewadc10Bjynn/Z-C12Bjynn/Q

    General Outline ESIE07-04 1.45 Outlook Drawing: EWADC10BJYNN/Z-C12BJYNN/Q The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). (Control box) Air discharge detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 95 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection Compressor enclosure (optional) Coil protection guards (optional) 10 isolator mounting holes 25 mm DIA.

  • Page 96: Outlook Drawing: Ewadc10-C11Bjynn, Ewadc10-C11Bjynn+Oprn And Ewadc10-C11Bjynn+Opln

    General Outline ESIE07-04 1.46 Outlook Drawing: EWADC10-C11BJYNN, EWADC10-C11BJYNN+OPRN and EWADC10-C11BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 97 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 98: Outlook Drawing: Ewadc11Bjynn And Ewad900Bjynn/Z

    General Outline ESIE07-04 1.47 Outlook Drawing: EWADC11BJYNN and EWAD900BJYNN/Z The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 99 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection Compressor enclosure Coil protection guards (optional) 10 isolator mounting holes 25 mm DIA.

  • Page 100: Outlook Drawing: Ewadc11-C12Bjynn/A, Ewadc11-C12Bjynn/A+Oprn, Ewadc11-C12Bjynn/A+Opln, Ewadc12-C13Bjynn, Ewadc12-C13Bjynn+Oprn And Ewadc12-C13Bjynn+Opln

    General Outline ESIE07-04 1.48 Outlook Drawing: EWADC11-C12BJYNN/A, EWADC11-C12BJYNN/A+OPRN, EWADC11-C12BJYNN/A+OPLN, EWADC12-C13BJYNN, EWADC12-C13BJYNN+OPRN and EWADC12-C13BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). (Control box) Air discharge See detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 101 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection Compressor enclosure Coil protection guards (optional) 8 isolator mounting holes 25 mm DIA.

  • Page 102: Outlook Drawing: Ewadc13Bjynn/A, Ewadc13Bjynn/A+Oprn And Ewadc13Bjynn/A+Opln

    General Outline ESIE07-04 1.49 Outlook Drawing: EWADC13BJYNN/A, EWADC13BJYNN/A+OPRN and EWADC13BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). (Control box) Air discharge See detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 103 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection Compressor enclosure (optional) Coil protection guards (optional) 10 isolator mounting holes 25 mm DIA.

  • Page 104: Outlook Drawing: Ewadc14Bjynn/A, Ewadc14Bjynn/A+Oprn And Ewadc14Bjynn/A+Opln

    General Outline ESIE07-04 1.50 Outlook Drawing: EWADC14BJYNN/A, EWADC14BJYNN/A+OPRN and EWADC14BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Isolators location Detail "A"...
  • Page 105 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 10 isolator mounting holes 25 mm DIA.

  • Page 106: Outlook Drawing: Ewadc14Bjynn/A+Opsp, Ewadc14Bjynn/A+Oprn+Opsp And Ewadc14Bjynn/A+Opln+Opsp

    General Outline ESIE07-04 1.51 Outlook Drawing: EWADC14BJYNN/A+OPSP, EWADC14BJYNN/A+OPRN+OPSP and EWADC14BJYNN/A+OPLN+OPSP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) See detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Isolators location Detail "A"...
  • Page 107 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Victaulic connection for 219.1 O.D. tube evaporator water inlet Victaulic connection for 168.3 O.D. tube evaporator-pump water outlet Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 10 isolator mounting holes 25 mm DIA.

  • Page 108: Outlook Drawing: Ewadc15Bjynn/A, Ewadc15Bjynn/A+Oprn And Ewadc15Bjynn/A+Opln

    General Outline ESIE07-04 1.52 Outlook Drawing: EWADC15BJYNN/A, EWADC15BJYNN/A+OPRN and EWADC15BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 109 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection Compressor enclosure (optional) Coil protection guards (optional) 10 isolator mounting holes 25 mm DIA.

  • Page 110: Outlook Drawing: Ewadc16Bjynn, Ewadc16Bjynn+Oprn And Ewadc16Bjynn+Opln

    General Outline ESIE07-04 1.53 Outlook Drawing: EWADC16BJYNN, EWADC16BJYNN+OPRN and EWADC16BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). (Control box) Air discharge Optional right hand evaporator water detail B (Frame) Refer See detail A Detail B...
  • Page 111 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 12 isolator mounting holes 25 mm DIA.

  • Page 112: Outlook Drawing: Ewadc16Bjynn/A, Ewadc16Bjynn/A+Oprn And Ewadc16Bjynn/A+Opln

    General Outline ESIE07-04 1.54 Outlook Drawing: EWADC16BJYNN/A, EWADC16BJYNN/A+OPRN and EWADC16BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 113 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection Compressor enclosure Coil protection guards (optional) 10 isolator mounting holes 25 mm DIA.

  • Page 114: Outlook Drawing: Ewadc17Bjynn/A, Ewadc17Bjynn/A+Oprn And Ewadc17Bjynn/A+Opln

    General Outline ESIE07-04 1.55 Outlook Drawing: EWADC17BJYNN/A, EWADC17BJYNN/A+OPRN and EWADC17BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) See detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 115 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 12 isolator mounting holes 25 mm DIA.

  • Page 116: Outlook Drawing: Ewadc17Bjynn/A+Optr, Ewadc17Bjynn/A+Oprn+Optr And Ewadc17Bjynn/A+Opln+Optr

    General Outline ESIE07-04 1.56 Outlook Drawing: EWADC17BJYNN/A+OPTR, EWADC17BJYNN/A+OPRN+OPTR and EWADC17BJYNN/A+OPLN+OPTR The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) See detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 117 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 12 isolator mounting holes 25 mm DIA.

  • Page 118: Outlook Drawing: Ewadc18Bjynn/A, Ewadc18Bjynn/A+Oprn And Ewadc18Bjynn/A+Opln

    General Outline ESIE07-04 1.57 Outlook Drawing: EWADC18BJYNN/A, EWADC18BJYNN/A+OPRN and EWADC18BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). (Control box) Air discharge detail B (Frame) Refer See detail A Detail B Counter-flange furnished ''Victaulic''coupling-furnished Connecting pipe-furnished...
  • Page 119 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 12 isolator mounting holes 25 mm DIA.

  • Page 120: Outlook Drawing: Ewadc19Bjynn/A, Ewadc19Bjynn/A+Oprn And Ewadc19Bjynn/A+Opln

    General Outline ESIE07-04 1.58 Outlook Drawing: EWADC19BJYNN/A, EWADC19BJYNN/A+OPRN and EWADC19BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) (Frame) See detail B Optional right hand evaporator water Refer See detail A Detail B...
  • Page 121 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 12 isolator mounting holes 25 mm DIA.

  • Page 122: Outlook Drawing: Ewadc20Bjynn/A, Ewadc20Bjynn/A+Oprn And Ewadc20Bjynn/A+Opln

    General Outline ESIE07-04 1.59 Outlook Drawing: EWADC20BJYNN/A, EWADC20BJYNN/A+OPRN and EWADC20BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). (Control box) Air discharge detail B (Frame) Optional right hand evaporator water Refer See detail A Detail B...
  • Page 123 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 12 isolator mounting holes 25 mm DIA.

  • Page 124: Outlook Drawing: Ewadc21Bjynn/A, Ewadc21Bjynn/A+Oprn And Ewadc21Bjynn/A+Opln

    General Outline ESIE07-04 1.60 Outlook Drawing: EWADC21BJYNN/A, EWADC21BJYNN/A+OPRN and EWADC21BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). (Control box) Air discharge (Frame) See detail B Optional right hand evaporator water Refer See detail A Detail B...
  • Page 125 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 8 lifting shackles 12 isolator mounting holes 25 mm DIA.

  • Page 126: Outlook Drawing: Ewad600Bjynn/Z

    General Outline ESIE07-04 1.61 Outlook Drawing: EWAD600BJYNN/Z The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearancere quirements Detail "A"...
  • Page 127 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.

  • Page 128: Outlook Drawing: Ewad650Bjynn, Ewad650Bjynn+Oprn And Ewad650Bjynn+Opln

    General Outline ESIE07-04 1.62 Outlook Drawing: EWAD650BJYNN, EWAD650BJYNN+OPRN and EWAD650BJYNN+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 129 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.

  • Page 130: Outlook Drawing: Ewad650Bjynn+Optp, Ewad650Bjynn+Oprn+Optp And Ewad650Bjynn+Opln+Optp

    General Outline ESIE07-04 1.63 Outlook Drawing: EWAD650BJYNN+OPTP, EWAD650BJYNN+OPRN+OPTP and EWAD650BJYNN+OPLN+OPTP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) ''Victaulic''coupling-furnished Connecting pipe-furnished detail B (Frame) Optional right hand evaporator water See detail A Fan arrangements and minimum...
  • Page 131 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 219.1 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.
  • Page 132 General Outline ESIE07-04 1.64 Outlook Drawing: EWAD650BJYNN/A, EWAD650BJYNN/A+OPRN and EWAD650BJYNN/A+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements...
  • Page 133 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.
  • Page 134 General Outline ESIE07-04 1.65 Outlook Drawing: EWAD650BJYNN/A+OPSP, EWAD650BJYNN/A+OPSP+OPRN and EWAD650BJYNN/A+OPSP+OPLN The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water "Victaulic" coupling-furnished Connecting pipe-furnished detail B (Frame) See detail A...
  • Page 135 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.
  • Page 136 General Outline ESIE07-04 1.66 Outlook Drawing: EWAD650BJYNN/Q The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) Optional right hand evaporator water detail B (Frame) See detail A Fan arrangements and minimum clearance requirements Detail "A"...
  • Page 137 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Victaulic connections for 168.3 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 8 isolator mounting holes 25 mm DIA.
  • Page 138 General Outline ESIE07-04 1.67 Outlook Drawing: EWAD650BJYNN/Q+OPTP The illustration below shows the outlook, the dimensions and the installation and service space of the unit (mm). Air discharge (Control box) "Victaulic" coupling-furnished Connecting pipe-furnished detail B (Frame) Optional right hand evaporator water Fan arrangements and minimum See detail A clearance requirements...
  • Page 139 ESIE07-04 General Outline Components The table below lists the components. Component Condenser coil Evaporator Evaporator water inlet Evaporator water outlet Evaporator-pump water outlet victaulic connection for 139.7 O.D. tube Operating and control panel 360 x 150 slot for power and control panel connection 4 lifting shackles 6 isolator mounting holes 25 mm DIA.
  • Page 140 General Outline ESIE07-04 1–128 Part 1 – System Outline...

  • Page 141: Functional Description

    ESIE07-04 Part 2 Functional Description Introduction This part gives more detailed information on the functions and controls of the unit. This information is used as background information for troubleshooting. An extensive overview of the functioning of the controller is also given in this part. Knowledge of the controller is essential to gather information prior to servicing and troubleshooting.
  • Page 142 ESIE07-04 2–2 Part 2 – Functional Description...
  • Page 143 ESIE 07-04 Operation Range Part 2 Operation Range What Is in This Chapter? Introduction This chapter contains information on the functions used to control the system. Understanding these functions is vital when diagnosing a malfunction that is related to the functional control. Overview This chapter contains the following topics: Topic...

  • Page 144: Operational Range: Ewad-Bjynn

    Operation Range ESIE 07-04 Operational Range: EWAD-BJYNN Operational range The illustration below shows the operational range of EWAD-BJYNN. Ambient C standard unit with Fanspeed control device : OPFS with Low ambient operation : OPLA glycol water Leaving evaporator water temperature Unit version EWAD-BJYNN Max ambient temperature...

  • Page 145: Operational Range: Ewad-Bjynn With Option Oprn/Opln

    ESIE 07-04 Operation Range Operational Range: EWAD-BJYNN with option OPRN/OPLN Operational range The illustration below shows the operational range of EWAD-BJYNN with option OPRN and EWAD-BJYNN with option OPLN. Ambient C standard unit with Fanspeed control device : OPFS with Low ambient operation : OPLA glycol water...

  • Page 146: Operational Range: Ewad-Bjynn/Q

    Operation Range ESIE 07-04 Operational Range: EWAD-BJYNN/Q Operational range The illustration below shows the operational range of EWAD-BJYNN/Q. Ambient C glycol water Leaving evaporator water temperature Unit version EWAD-BJYNN Max ambient temperature +40°C Min ambient temperature -10°C Max leaving evaporator water temperature +9°C Min leaving evaporator water temperature (without glycol) +4°C...

  • Page 147: Operational Range: Ewad-Bjynn/A

    ESIE 07-04 Operation Range Operational Range: EWAD-BJYNN/A Operational range The illustration below shows the operational range of EWAD-BJYNN/A. Ambient C standard unit with Fanspeed control device : OPFS with Low ambient operation : OPLA glycol water Leaving evaporator water temperature Unit version EWAD-BJYNN Max ambient temperature...

  • Page 148: Operational Range: Ewad-Bjynn/A With Option Oprn/Opln

    Operation Range ESIE 07-04 Operational Range: EWAD-BJYNN/A with option OPRN/OPLN Operational range The illustration below shows the operational range of EWAD-BJYNN/A with option OPRN and EWAD-BJYNN/A with option OPLN. Ambient C standard unit with Fanspeed control device : OPFS with Low ambient operation : OPLA glycol water...

  • Page 149: Operational Range: Ewad-Bjynn/Z

    ESIE 07-04 Operation Range Operational Range: EWAD-BJYNN/Z Operational range The illustration below shows the operational range of EWAD-BJYNN/Z. Ambient C glycol water Leaving evaporator water temperature Unit version EWAD-BJYNN Max ambient temperature +40°C Min ambient temperature -10°C Max leaving evaporator water temperature +9°C Min leaving evaporator water temperature (without glycol) +4°C...
  • Page 150 Operation Range ESIE 07-04 2–10 Part 2 – Functional Description...
  • Page 151 ESIE07-04 The Digital Controller Part 2 The Digital Controller What Is in This Chapter? Introduction This chapter gives more detailed information about the controller and the software. Understanding these functions is vital when diagnosing a malfunction, which is related to system architecture or software.

  • Page 152: System Architecture

    The Digital Controller ESIE07-04 System Architecture General description The Microtech II C Plus control panel contains a microprocessor based controller which provides all monitoring and control functions required for the safe, efficient operation of the Chiller. The operator can monitor all operating conditions by using the panel’s built in 4 line by 20 character keypad/display or by using an IBM compatible computer running MicroPlant monitor software release 2.0 and later.

  • Page 153: Control Panel

    ESIE07-04 The Digital Controller Costumer Interfaces Overview This chapter contains the following topics: Topic See page 2.3.1–Control Panel 2–13 2.3.2–Main boardl 2–14 2.3.3–EEXV Valve Driver 2–16 2.3.4–Meaning of the Driver EEXV Status LEDs 2–18 2.3.5–pCO Expansion 2–19 2.3.6–Addressing of plan/RS485 2–21 2.3.1 Control Panel...

  • Page 154: Main Board

    The Digital Controller ESIE07-04 2.3.2 Main board General description The control board contains the hardware and the software necessary to monitor and to control the unit. The figure below shows the main board: Power supply G (+), G0 (-) Status LED Fuse 250Vac Universal analog inputs (NTC, 0/1V, 0/10V,0/20mA, 4/20mA) Passive analog inputs (NTC, PT1000, On- off )
  • Page 155 ESIE07-04 The Digital Controller pLAN addressing microswitches R G V Part 2 – Functional Description 2–15...
  • Page 156 The Digital Controller ESIE07-04 2.3.3 EEXV Valve Driver General description The valve drivers contain the software for the control of the electronic expansion valve and are connected to the battery group, which provides power to close valve in case of power failure. Status Led Inside view driver Addressing...

  • Page 157: Battery Assembly

    ESIE07-04 The Digital Controller Battery assembly Battery charger Chargeable Battery 10 Amp Fuse Part 2 – Functional Description 2–17...
  • Page 158 The Digital Controller ESIE07-04 2.3.4 Meaning of the Driver EEXV Status LEDs Normal conditions Under normal conditions five(5) LED indicates: POWER: (yellow) remains On in presence of supply. Remains Off in case of battery operation OPEN: (green) Flashing during the valve opening. On when valve is fully open. CLOSE: (green) Flashing during the valve closing.
  • Page 159 ESIE07-04 The Digital Controller 2.3.5 pCO Expansion Carel expansion The introduction of the Economizer functionality in the software requires the use of Carel expansion board board shown in the figure below. Power supply connector (G(+), G0 (-)) Analogue output 0 to 10 V Network connector for expansions in RS485 (GND, T+, T-) or tLAN (GND, T+) 24 Vac/Vdc digital inputs Yellow LED showing power supply voltage and 3 signalling LEDs...
  • Page 160 The Digital Controller ESIE07-04 Expansion board lan setup details Example address 1 Battery charger Battery charger As shown in the figure above, expansion boards have only four microswitches to set the net address. For more details on microswitches configuration refer to”2.3.6–Addressing of plan/RS485”. Status LEDs Three status LEDs are present, their status represents different statuses of the expansion board.
  • Page 161 ESIE07-04 The Digital Controller 2.3.6 Addressing of plan/RS485 To get the correct functionality of the pLAN net system, it is necessary to address correctly all the installed components. Each component, as previously described, has a series of microswitches that must be set as specified in the following table. pLAN component Microswitch Local DISPLAY...
  • Page 162 The Digital Controller ESIE07-04 Display and Keypad Overview This chapter contains the following topics: Topic See page 2.4.1–General Description 2–23 2.4.2–Keypad Keys and their Functions 2–24 2.4.3–Main Menu 2–27 2.4.4–User Menu 2–32 2.4.5–Setting Menu 2–39 2.4.6–Input / Output Menu 2–40 2.4.7–Manufacturer Menu 2–44 2.4.8–EXV Setting Menu...

  • Page 163: General Description

    ESIE07-04 The Digital Controller 2.4.1 General Description Introduction The display and the keypad are the main elements of the interface between the operator and the unit. All the operational conditions, the alarms and the setpoints can be monitored with this display and all the values of setpoint can be modified though the keypad.

  • Page 164: The Digital Controller Esie07-04

    The Digital Controller ESIE07-04 2.4.2 Keypad Keys and their Functions User parameters, by password it is possible to set the following parame- ters: Setpoints reset parameters Enable double setpoint Soft load parameters Unit load limiting parameters Compressor sequencing logic Fan Silent Mode values Main pump timing Digital and supervisor inputs enabling Auto restart after power failure and external alarm behaviour...
  • Page 165 ESIE07-04 The Digital Controller Maintenance parameters; by Password it is possible to set the following parameters : Hour and start counters reset (=maint) Water regulation parameters Condensation regulation parameters Setpoint limits Probes enabling Probes offset It allows to visualize the main menu It allows the passage from a control board to the other one (visualizing parameters of corresponding compressors, more precisely compressors # 1 and # 2 for board # 1 and compressors # 3 and # 4 for board # 2)
  • Page 166 The Digital Controller ESIE07-04 Using the keypad it is possible to access the different sections of the program. In particular there are 9 screen categories, shown in the following table with the keys to use to access them and with the type of operation they allow.

  • Page 167: 3-Main Menu

    ESIE07-04 The Digital Controller 2.4.3 Main Menu Operational Using this menu you can read the operational information, such as the cooling setpoint, the inlet and information outlet water temperatures, the circuit status, etc. Key : Password : Switching between control board # 1 and # 2 : Main screen 1 This screen shows information about the compressor status, unit status and setpoint.
  • Page 168 The Digital Controller ESIE07-04 Line 4 gives the setpoint origin : STP Source : Local : Double : 4-20 mA Soft Load : xx min (remaining soft load time) Unit limiting This screen is only visible when unit limiting (demand limit) is enabled in the user menu. Unit Limiting Demand Limit Demand Limit...
  • Page 169 ESIE07-04 The Digital Controller Compressor status This screen shows the compressor status. Comp. # 01 Status : Off Ready Possible status : Off Alarm : Compressor OFF for alarm Off Switch : Compressor OFF by local switch Off Ready : Compressor OFF ready to start Oil Heating : Compressor waiting for oil heating Manual Off...
  • Page 170 The Digital Controller ESIE07-04 Refrigerant This screen shows the refrigerant temperatures. temperatures Suction Temp = 00.0 ˚C Suct Superheat = 00.0 ˚C Deliv Superheat = 00.0 ˚C Valve Position = 0000 Suction Temp : Suction Temperature Suct Superheat : Suction Superheat Deliv Superheat : Discharge Superheat Valve Position : Position of the electronic expansion valve...
  • Page 171 ESIE07-04 The Digital Controller Water temperatures If 2 evaporators are present, you can scroll between circuits 1, 2 (evap 1) and circuits 3, 4 (evap 2) with the info button. When you press the info button, the following screen will appear, showing the leaving water temperature of each evaporator: Water Temperatures LVG Evap 1 =...

  • Page 172: 4-User Menu

    The Digital Controller ESIE07-04 2.4.4 User Menu Operational Using this menu you can enable or disable additional function in the unit. information Key : Password : 0003 Remark : User menu is present in control board # 1 only. Press the program button to go to the user menu. The following screen will appear: Insert User password 0000...
  • Page 173 ESIE07-04 The Digital Controller Setpoint reset This screen is only visible when setpoint reset : 4-20mA is selected. 4-20mA This screen allows you to set the parameters used for the 4-20mA setpoint reset (see page 2–32). chLWT Setpoint Override Limits Set.
  • Page 174 The Digital Controller ESIE07-04 Unit limiting This screen allows you to enable/disable the unit limiting function. Unit Limiting None Possible settings : None Demand Limit : Unit limiting with external signal Current Limit : Only available on SPN unit Superv. Demand : Unit limiting with external signal coming from BMS system Superv.

  • Page 175: Auto Restart

    ESIE07-04 The Digital Controller Pump lead time This screen allows you to set the time between the main pump and the compressor start. Time Between Main Pump / Fan and Comp. Start 030 s Time 30s : Pump lead time, the pump will operate for 30 seconds (changeable) before the compressor can start Pump lag time This screen allows you to set the delay on switching off the pump.
  • Page 176 The Digital Controller ESIE07-04 External alarm This screen allows you to enable/disable the external alarm function. Switch Off Unit On External Alarm Reset Type Auto External Alarm : N : External alarm is disabled Y : An external alarm signal (open closed contact) can be used to switch off the unit (external alarm) Reset Type : Auto : When the external alarm signal is reset (closed contact), the controller will...
  • Page 177 ESIE07-04 The Digital Controller Communication This screen allows you to select the supervisory communication. Communication Supervisor Possible settings : Supervisor : A supervisor (BMS) system will be used to control the chiller : The option EKDICN will control the chiller Communication These screens are only visible when CSC communication is selected.
  • Page 178 The Digital Controller ESIE07-04 Communication This screen is only visible when supervisor communication is selected. supervisor Protocol : CAREL Supervisor Com Speed 19200 (RS485 only) Identificat. No. : Protocol : CAREL : For BACnet communication (with gateway) LONWORKS : Direct communication to BMS (Xif pre-loaded) MODBUS : Direct communication to BMS...

  • Page 179: 5-Setting Menu

    ESIE07-04 The Digital Controller 2.4.5 Setting Menu Operational Using this menu it is possible to set and display the setpoint values. information Key : Password : Remark : Setting menu is only present on control board # 1. Cooling setpoint This screen allows you to change the cooling setpoint.

  • Page 180: 6-Input / Output Menu

    The Digital Controller ESIE07-04 2.4.6 Input / Output Menu Operational Using this menu you can read the inputs and outputs from the controller, software information and EEV information driver information. Key : Password : Switching between control board # 1 and # 2 : I/O expansion The screens below are only visible when the unit has economizer (units /A and /Z).

  • Page 181: Analog Inputs

    ESIE07-04 The Digital Controller Analog inputs These screens show you the values of the analog inputs. Analog Inputs : B1 : Oil pr. 1 00.0 bar B2 : Oil pr.2 00.0 bar B1 : Oil pressure of compressor circuit 1 B2 : Oil pressure of compressor circuit 2 Remark : The oil pressure is measured by a pressure transducer connected to the oil supply chamber of the compressor.

  • Page 182: Analog Outputs

    The Digital Controller ESIE07-04 If consulting this screen or controller # 2 : B9 : O W ev1 : Outlet water temperature of evaporator 1 B10 : O W ev2 : Outlet water temperature of evaporator 2 Analog outputs These screens show you the value of the analog outputs (VFD output signal). Analog Outputs : Y1 : 00.0 V...
  • Page 183 ESIE07-04 The Digital Controller Boot / Bios info This screen shows you the Boot and Bios of the software. Bios Version 003.64 Bios Date 18/05/05 Boot Version 003.01 Boot Date 15/04/02 Driver firmware These screens show you the EEV driver hardware and software version. version Driver Firmware Version C : 1...

  • Page 184: 7-Manufacturer Menu

    The Digital Controller ESIE07-04 2.4.7 Manufacturer Menu Operational Using this menu you can set all manufacturer data. Password is required to enter this menu. The information parameters can only be modified by trained individuals. Key : Password : blue Switching between control board # 1 and # 2 : Warning : Improper setpoints or values can cause erratic chiller operation and damage to the chiller.

  • Page 185: Unit Configuration

    ESIE07-04 The Digital Controller Economizer motor This function is used only in EWAD-BJYNNA/A and EWAD-BJYNN/Z. protection This screen allows you to set the economizer motor protection settings. Economizer Motor Protection Setp 065.0 ˚C Diff 05.0 ˚C Motor protection setp. : Economizer function is disabled when saturated discharge tempera- ture gets above setpoint Motor protection diff.
  • Page 186 The Digital Controller ESIE07-04 Interstage timer This screen allows you to set the interstage time and the double pulse setpoint. Interstage Time 0210 s Double Pulse Under 035 % Interstage Time : Interstage time used for temperature regulation Double Pulse under : Double load pulses are given below setpoint Pressure safety These screens allow you to set the high and low pressure safety preventions.

  • Page 187: Freeze Prevention

    ESIE07-04 The Digital Controller Freeze prevention This screen allows you to set the freeze prevention parameters. Freeze Prevent Setpoint 03.0 ˚C Diff. 01.0 ˚C Freeze Prevent : Setpoint : Freeze prevention activation setpoint (for evaporator leaving water) Diff. : Freeze prevention reset difference Anti-freeze alarm, 1 This screen allows you to set the anti-freeze alarm parameters.
  • Page 188 The Digital Controller ESIE07-04 Compressor This screen allows you to set the compressor load and unload pulses. load/unload pulses Number of Pulses to Load Comp. Number of Pulses to Unload Comp. Unloading This screen allows you to set the unloading parameters. parameters Unloading Pulse Time...

  • Page 189: Fan Configuration

    ESIE07-04 The Digital Controller Pump down This screen allows you to set the pump down parameters (pump down at shut down) configuration Pump Down Config. Enable Max time 030 s Min Press. 0.5 bar g Enable : N : Pump down is disabled Y : Pump down is enabled Max Time : Maximum time of pump down function Min Press : Minimum pressure during pump down function...
  • Page 190 The Digital Controller ESIE07-04 This screen can be found back in each fan step present in the unit (VFD fan has other setpoints, see next screen). Each fan step has its own setpoint and diff. setting. See Table below for fan step settings. Setpoint / Diff.
  • Page 191 ESIE07-04 The Digital Controller Fan settings for This screen is visible only when VFD or SPEEDTR is selected. units with option OPLA and OPFS If the unit is with option OPLA, these settings will be used to control the VFD fan. If the unit is with option OPFS, these settings will be used to control all the fans of the circuit.
  • Page 192 The Digital Controller ESIE07-04 HP alarm settings This screen allows you to set the high pressure alarm settings. Transducers High Pressure Alarm Setpoint 20.0 bar Diff. 05.0 bar Setpoint : High pressure alarm setpoint to activate high pressure alarm Diff. : High pressure alarm differential to be able to reset high pressure alarm (setpoint –...
  • Page 193 ESIE07-04 The Digital Controller Pressure ratio This screen allows you to set the pressure ratio alarm delay timers. alarm delay Pressure Ratio Alarm Start-Up Delay 180 s Run Delay 90 s Start-Up Delay : Pressure ratio alarm bypass timer during start-up of compressor Run Delay : Pressure ratio alarm delay time before unit goes into pressure ratio alarm when unit is in operation...
  • Page 194 The Digital Controller ESIE07-04 EXV pre-opening This screen allows you to set the EXV pre-opening setting. EXV PreOpening 50 % EXV pre-opening : Pre-opening of the electronic expansion valve during pre-purge (compressor startup) RS485 net refresh This screen allows you to reset the RS485 net (communication to expansion board). RS485 Net Time Check Refresh...
  • Page 195 ESIE07-04 The Digital Controller Reset all This screen allows you to reset all parameters to the default values. parameters to default values U : 1 Reset all Parameters to Default Values U : 1 : Reset all parameters on control board # 1 : Reset all parameters of this control board to the default values EXV settings This screen allows you to enter the EXV setting password.
  • Page 196 The Digital Controller ESIE07-04 U : 2 Reset all Parameters to Default Values U : 2 : Reset all parameters on control board # 2 : Reset all parameters of this control board to the default values 2–56 Part 2 – Functional Description...
  • Page 197 ESIE07-04 The Digital Controller 2.4.8 EXV Setting Menu Operational Using this menu you can set all EXV parameters. The parameters can only be modified by trained information individuals. EXV Setting Insert Password 0000 Password : 0013 Switching between con- trol board # 1 and # 2 : Warning screen These screens show you the warnings of the EXV driver.
  • Page 198 The Digital Controller ESIE07-04 EXV type This screen allows you to set the valve type and gas type. EXV Settings Value Type ALCO EX8 Gas Type R134a Valve Type : Type of valve used in unit Gas Type : Refrigerant used in unit Opening / Closing This screen allows you to enable / disable the extra steps at closing or opening of the expansion valve.
  • Page 199 ESIE07-04 The Digital Controller Low SH protections This screen allows you to set the low superheat protection settings. EXV Settings Low SHeat Protection Low Limit –1.0 ˚C Int. Time 01.0 ˚C Low Limit : Setpoint of the low limit function Int.
  • Page 200 The Digital Controller ESIE07-04 High temperature This screen allows you to set the high temperature condensing protection setpoints. condensing protection EXV Settings HiTcond PROTECTION HiTcond Limit 90.0 ˚C Int. Time 04.0 ˚C HiTcond Limit : Setpoint of the high temperature condensing protection Int.
  • Page 201 ESIE07-04 The Digital Controller 2.4.9 Maintenance Output Menu Operational Using this menu you can read-out all the maintenance parameters. information Key : Password : Switching between control board # 1 and # 2 : Evaporator pump This screen shows you the total evaporator pump running hours hours Hour Counter Pump Evap.
  • Page 202 The Digital Controller ESIE07-04 This screen shows you the EXV driver battery state. EXV Driver State C : 1 Batt. Resist. 000.0 Batt. Voltage 00.0 C : 1 : EXV driver state of circuit 1 Batt. Resist. : Battery resistance Batt.
  • Page 203 ESIE07-04 The Digital Controller Global PID request This screen shows you the global PID request. Global PID Request Load Unload Stand-by Load : N : No load requested Y : Load requested Unload : N : No unload requested Y : Unload requested Stand-by : N : No stand-by requested Y : Stand-by requested...
  • Page 204 The Digital Controller ESIE07-04 2.4.10 Maintenance Input Menu Operational Using this menu you can set all maintenance parameters. The parameters can only be modified only information by trained individuals. Screen : Digit maintenance password Password : Yellow blue Switching between control board # 1 and # 2 : Evaporator pump This screen allows you to settle the evaporator threshold (maintenance) and running hours.
  • Page 205 ESIE07-04 The Digital Controller This screen allows you to set the number of compressor starts. C : 1 Comp. Starts Reset Adjust 000000 C : 1 : Compressor information of compressor circuit 1 Reset Y : Reset compressor starts Adjust : Enter the compressor starts of this compressor.
  • Page 206 The Digital Controller ESIE07-04 Condensation This screen is only visible if fan type VFD or SPEEDTR is selected (units option OPFS or OPLA). setpoint This screen allows you to set the condensation setpoint. Condensation Setpoint 09.0 bar Condensation Setpoint : Condensation setpoint for phase cut fans (VFD or SPEEDTR) Temperature This screen allows you to set the minimum and maximum setpoint limits.
  • Page 207 ESIE07-04 The Digital Controller Expansion board This screen allows you to enable or disable the analog input (from the expansion board). probe screen This screen is only visible when the unit has an expansion board (units /A and /Z). The ambient sensor which can be connected to the expansion board analog input B1 is used for setpoint reset OAT.
  • Page 208 The Digital Controller ESIE07-04 Maintenance input If compressor 3 or 4 is present, you can scroll between control board # 1 (comp 1 and 2) and control menu on control board # 2 (comp 3 and 4). board # 2 (comp 3 and 4) When you press the info button, the following screens will appear for control board # 2 : Compressor running data settings for comp 3 (see page 2–64)

  • Page 209: Service Menu

    ESIE07-04 The Digital Controller 2.4.11 Service Menu Operational Using this menu you can operate the different circuits in manual mode. When the chiller is working in information manual mode and a safety prevention is met (LP prevention / HP prevention / Freeze prevention / ...), the chiller will automatically switch over to normal (auto) mode.

  • Page 210: Alarm Menu

    The Digital Controller ESIE07-04 2.4.12 Alarm Menu Operational Using this menu you can read out the actual alarm. information When an alarm condition occurs, the display buzzer starts. Pressing the alarm key displays the current fault. Pressing the alarm key twice stops the buzzer while pressing it thrice removes the alarm. Remark : Sometimes, when an alarm occurs, another spurious alarm of star/delta transition failure also occurs.
  • Page 211 ESIE07-04 The Digital Controller 2.4.13 Buffer Alarm Menu Operational Using this menu you can consult the last ten alarms of every chiller circuit. information Each mask displays the date, time and description of the alarm. Pressing the enter key when an alarm description is displayed shows the operating conditions at the time the alarm occurred (temperatures, pressures, expansion valve status and compressor load).
  • Page 212 The Digital Controller ESIE07-04 2–72 Part 2 – Functional Description...

  • Page 213: Functional Control

    ESIE07-04 Functional Control Part 2 Functional Control What Is In This Chapter? Introduction This chapter will give more detailed information about the functions used to control the system. Understanding these functions is vital when diagnosing a malfunction, which is related to functional control.

  • Page 214: Topic See Page

    Functional Control ESIE07-04 Topic See page 3.28–Heat Recovery Microprocessor Set-up 2–116 2–74 Part 2 – Functional Description...

  • Page 215: On / Off Management

    ESIE07-04 Functional Control ON / OFF Management Introduction There are four ways of switching the unit on and off: Through the local key of the controller Through a remote switch Through a supervision system (BMS) Through a time schedule Power on The initialization takes 10 seconds.

  • Page 216: Thermostat Control

    Functional Control ESIE07-04 Thermostat Control Introduction The thermostat control is used to generate a load-up or load-down according to the active PID regulation. Continuous loading and unloading uses 2 solenoid valves to control the screw compressor slide and thus its capacity. Control is performed by outlet temperature. Unit and In the following flow chart the unit startup, management and shutdown procedures are shown, as well compressor...
  • Page 217 ESIE07-04 Functional Control Unit shutdown Unit Shutdown request Compressors shutdown (see compressors shutdown in startup and management procedure) Flow switch opening within 180 s UNIT ALARM 005 (user set) (Evap Flow Alarm) Evaporator pump shutdown Compressors start up and loading management Step n.
  • Page 218 Functional Control ESIE07-04 Step n. Leader Comp. Lag 1 Comp. Lag 2 Comp. Lag 3 Comp. 16a (T in unload Fixed at 75% Fixed at 75% Unload up to 50% Start band) 16b (T out unload Fixed at 75% Fixed at 75% Fixed at 75% Start band)
  • Page 219 ESIE07-04 Functional Control Step n. Leader Comp. Lag 1 Comp. Lag 2 Comp. Lag 3 Comp. 18a (T in load Load up to 75% Stop band) 18b (T not in load Fixed at 50% Stop band) Unload up to 25% If T is approaching SetP –...
  • Page 220 Functional Control ESIE07-04 Start up ∆T : 2.7°C Other settings Shutdown ∆T : 1.7°C Regulation band : 3°C EXAMPLE: Upload If the water temperature is above 9.7°C the chiller can start (below 9.7°C the chiller will wait) Unit will start leader compressor Unit will load leader compressor till 75% If temperature is in Regulation Band wait interstage time (default 210 sec)

  • Page 221: Setpoint Reset Of The Chilled Water

    ESIE07-04 Functional Control Setpoint Reset of the Chilled Water Introduction Among the MicroTech NC controllers options, there are also several possibilities to regulate the unit with particular logics or outside signals. The setpoint reset function gives the possibility to modify the local setpoint of the chilled water according to the following logics: double setpoint external signal...
  • Page 222 Functional Control ESIE07-04 Lvg Water Temp Setpoint Reset 4-20mA chLWT Setpoint Override Limits Setp. Diff. 03.0 ˚C Outdoor ambient The OAT mode can be used to modify the setpoint in function of the ambient temperature. The user is temperature reset able to choose to use the OAT mode or not.
  • Page 223 ESIE07-04 Functional Control Explanation When the load of the unit drops (by drop in outdoor temperature), then the setpoint will be changed upwards by the setpoint diff value. Because of this the unit will evaporate at a higher temperature and thus the performance of the tunit will be better.

  • Page 224: Return Water Reset

    Functional Control ESIE07-04 Return Water Reset Introduction When return water is selected as the reset mode, the MicroTech controller will adjust the leaving chilled water setpoint to maintain a constant return water temperature equal to the return water setpoint. The return water temperature is sampled every 5 minutes and a proportional correction is made to the leaving chilled water setpoint.

  • Page 225: Freeze-Up Control

    ESIE07-04 Functional Control Freeze-up Control Introduction Freeze up control is used to protect the evaporator against accidentally freezing. Two protections are present: freeze-up prevention and Anti-freeze alarm. Freeze-up Freeze-up prevention will request a load-down when the temperature of the evaporator outlet gets prevention below 3°C (freeze prevention setpoint).
  • Page 226 Functional Control ESIE07-04 Function description Outlet Temp. possible for the compressor to upload possible to reset Anti-freeze Alarm Freeze Prevention Setpoint Freeze up prevention (load down) Anti-freeze Alarm Setpoint Anti-freeze Alarm (shutdown) Time Anti-Freeze Alarm Setpoint 02.0 ˚C Diff. 01.0 ˚C In case the unit has 2 evaporators: Evap 1 Anti-Freeze Alarm Setpoint...

  • Page 227: Enable Soft Load

    ESIE07-04 Functional Control Enable Soft Load Function The Soft load function can be enabled by keyboard in the user menu. The Soft load function limits the description unit load to a predetermined value (Max stage) for a set period (Max time). This function finds wide application where the water temperature is high at the start up but without having a consistent thermal load.

  • Page 228: Unit Load Limiting

    Functional Control ESIE07-04 Unit Load Limiting Introduction The Unit load limiting function finds application in all those situations when it is necessary to reduce the electric absorption of the unit, in determined periods of the day. Load limiting It is possible to limit the unit absorption using one of the two options available under user menu. The first way, called “Demand Limit”...

  • Page 229: Start Up With High Evaporator Water Temperature

    ESIE07-04 Functional Control Start Up With High Evaporator Water Temperature Function This function limits the load of each compressor to a set value (default 70%) until the outlet water description temperature is over the set value (default 25°C). This function helps the start up of the unit when the water temperature is very high (35°C - 40°C) avoiding dangerous overheating of the motor and disagreeable interventions for high pressure protection.

  • Page 230: Ambient Lockout

    Functional Control ESIE07-04 3.10 Ambient Lockout Introduction The Ambient lockout function will allow you to disable the unit below a specified Ambient temperature. Function description Ambient reset ambient lockout and restart unit diff. Setpoint switch off unit En. Ambient Lockout Setpoint 05.0 ˚C Diff.

  • Page 231: Pump Control

    ESIE07-04 Functional Control 3.11 Pump Control Introduction To prevent the chiller to start up without flow, safety checks are performed. First there is a check to make sure that water flows through the system. The pump control of the user menu allows the user to define the pump lead and the pump lag time. Pump lead time Time Between Main Pump / Fan and Comp.

  • Page 232: Auto Restart After Power Failure Function

    Functional Control ESIE07-04 3.12 Auto Restart after Power Failure Function Function The Auto restart after power failure allows the unit to restart after a power failure. description When the Auto restart is enabled the unit will automatically restart after the power failure. When the Auto restart is disabled the unit will not automatically restart after the power failure.

  • Page 233: Liquid Injection

    ESIE07-04 Functional Control 3.13 Liquid Injection Function description Liq. Inj. ON Liq. Inj. OFF (del Temp.) Oil Temp. 75 C 85 C When the oil temperature (PT1000; del. temp.) is higher than 85°C (default) the liquid injection will be activated. When the oil temperature decreases to 75% the loquid injection will be disabled.

  • Page 234: Economizer Function

    Functional Control ESIE07-04 3.14 Economizer Function This economizer function is only present on the EWAD650-C21BJYNN/A and EWAD600-C10BJYNN/Z units. Function description Economizer Compressor Capacity 75 % 90 % When the compressor capacity reaches 90% the economizer will be activated. When the economizer is active, and the compressor capacity drops to 75%, then the economizer will be deactivated.

  • Page 235: Exv Pre Opening

    ESIE07-04 Functional Control 3.15 EXV Pre Opening Function Because the unit stops with a pump down, it will restart with a pre-purge (opening - closing of the description expansion valve). At start up the valve will open (up to 50%) and close to the evaporator with a certain amount of liquid. EXV PreOpening 50 % Part 2 –...

  • Page 236: Compressor Configuration

    Functional Control ESIE07-04 3.16 Compressor Configuration Function This controller screen will allow you to modify the number of compressors and evaporators on the unit. description The selection of the compressors and evaporators has to be done according to the unit. Compressor Configuration Numbers of Compressors 2 - 4...

  • Page 237: Compressor Management

    ESIE07-04 Functional Control 3.17 Compressor Management Introduction The compressor sequencing mode determines which circuit starts up first in case of a capacity demand. It prevents the unit from always starting the same circuit. Also, compressor timers are implemented to avoid too many compressor starts in 1 hour. Compressor The compressor sequence of starting up can be selected in the user menu.
  • Page 238 Functional Control ESIE07-04 Function description Min time between same comp start Min time comp ON Min time comp OFF Comp 1 Comp 1 Comp 1 Comp 1 Min time between diff comp starts Comp 1 Comp 1 Comp 2 Comp 2 2–98 Part 2 –...

  • Page 239: High Pressure Setback

    ESIE07-04 Functional Control 3.18 High Pressure Setback Introduction This is a safety prevention function, when high pressure is near to the high pressure switch setpoint. The unit will hold same capacity or will load-down to prevent the unit from tripping on the high pressure switch or transducer high pressure alarm.

  • Page 240: Lp Prevention

    Functional Control ESIE07-04 3.19 LP Prevention Introduction This is a safety prevention function, when the low pressure is near to the low pressure switch. The unit will hold same capacity or will load down to prevent the unit from tripping on the low pressure switch. Function description LP (bar)

  • Page 241: Capacity Control

    ESIE07-04 Functional Control 3.20 Capacity Control Introduction Cooling capacity control is infinitely variable by means of a capacity slide controlled by a microprocessor system. Each unit has infinitely variable capacity control from 100% down to 6.25% (four compressor units), to 8.3% (three compressor units) to 12.5% (two compressor units). This modulation allows the compressor capacity to exactly match the building-cooling load.
  • Page 242 Functional Control ESIE07-04 Pulse time The time of the pulse time is fixed (default 0.3 s). The interval time between two pulses is proportional to the PID (proportional + integral + derivative) unit request. Fixed Variable upload/download pulses Compressor Unloading Pulse Time 00.3 s Min Pulse Period...
  • Page 243 ESIE07-04 Functional Control Graph 2 The derivative part of the logic controls how the temperature reaches the setpoint. If it is getting closer – increases the time between intervals, or if it is far from the setpoint – decreases the time between intervals.

  • Page 244: Pump Down Configuration At Compressor Stop

    Functional Control ESIE07-04 3.21 Pump Down Configuration at Compressor Stop Introduction When the unit is switched off (local, remote, thermostat) the pump down procedure will be executed. Function Pump down prodecure: description request to shut down compressor close electronic expansion valve stop compressor or when one of the two conditions is met: max time of pump down = 30 seconds LP is below 1.2 bar...

  • Page 245: Pressure Safeties

    ESIE07-04 Functional Control 3.22 Pressure Safeties 3.22.1 Transducer high pressure alarm Introduction This is a software safety function. When high pressure is near to the high pressure switch setpoint, the unit will shutdown and trip on transducer high pressure alarm. Function description HP Alarm...
  • Page 246 Functional Control ESIE07-04 3.22.2 Transducer low pressure alarm Function description If LP is below possible this value to reset LP Alarm Setpoint Time When the low pressure is below the LP setpoint (for the LP alarm delay time), the unit will go into LP alarm.

  • Page 247: Lp Alarm Delay

    ESIE07-04 Functional Control 3.23 LP alarm delay Function Delay timer before the unit goes into LP alarm. description start delay: At start up the unit has a delay of 120 seconds before the unit can trip on LP alarm (low pressure bypass timer) run delay: When the unit is in operation, the low pressure can be below the LP alarm setpoint for a specified time before the unit will trip on LP alarm.

  • Page 248: Oil Management Safeties

    Functional Control ESIE07-04 3.24 Oil Management Safeties 3.24.1 Pressure ratio alarm Introduction Because the capacity control is done by oil pressure it is very important to have a minimum pressure difference between LP and HP to be able to move the sliding vane. Function When the pressure ratio is too small for a specified time, the controller will give an alarm.
  • Page 249 ESIE07-04 Functional Control 3.24.2 Pressure ratio alarm delay Function Delay time before the unit goes into pressure ratio alarm. description start up delay: At start up the unit will start to check the pressure ratio after the 180 seconds start up delay timer.

  • Page 250: Head Pressure Control

    Functional Control ESIE07-04 3.25 Head Pressure Control 3.25.1 Fan Management Purpose To regulate the high pressure There are 3 possible setting depending on the unit and options: Fan steps on/off management Phase cut fan management on all fans On/off fans + phase cut fan management Function In the controller, the fan management has to be specified.
  • Page 251 ESIE07-04 Functional Control 3.25.2 Phase cut fan management Function The fan will work according to regulation. description Through a signal 0-10 VdC (coming from the controller), it is possible to control an external regulator of speed (phase cut device). The MicroTech II controller, besides regulating the fan speed in accordance with the corresponding pressures, enables the on/off function.
  • Page 252 Functional Control ESIE07-04 Manufacturer menu Cond Regulation Regul. Band 05.0 bar Neutral Band 00.0 bar Cond. Regulation Integral Time 600 s Derivative Time 001 s These parameters are used for the PID function Maintenance menu Condensation Setpoint 09.0 bar HP (bar) 11.5 regulation Setpoint 9.0...
  • Page 253 ESIE07-04 Functional Control 3.25.4 On/off fans + phase cut (OPLA) management Function The logic of regulation of this system is only present in the units with OPLA and is similar to the two description previously described functions. The speed regulator is applied only to some fans while the others are controlled with the steps system.

  • Page 254: Heat Recovery Microprocessor Control

    Functional Control ESIE07-04 3.26 Heat Recovery Microprocessor Control Function All the units equipped with the heat recovery water condensers have an additional “microprocessor description control” to manage the heat recovery function of the unit. The microprocessor is installed inside the main control box below the MicroTech key pad as shown below.

  • Page 255: Heat Recovery Operation

    ESIE07-04 Functional Control 3.27 Heat Recovery Operation Function The unit supplied with the heat recovery condensers is equipped with an additional microprocessor description TC10 (see electrical wiring diagram) with two, three or four steps to control the hot water temperature according to the number of heat exchangers installed in the unit (one step for each compressor).

  • Page 256: Heat Recovery Microprocessor Set-Up

    Functional Control ESIE07-04 3.28 Heat Recovery Microprocessor Set-up Function The unit supplied with the heat recovery condensers is equipped with an additional microprocessor description TC10 (see electric wiring diagram) with two, three or four steps to control the hot water temperature according to the number of heat exchangers installed in the unit (one step for each compressor).

  • Page 257: Troubleshooting

    ESIE07-04 Part 3 Troubleshooting Introduction When a problem occurs, all possible faults have to be checked. This chapter gives a general idea of where to look for faults. Furthermore the general procedures for refrigeration circuit repair and for electrical circuit repair are explained. Remark Not all repair procedures are described.
  • Page 258 ESIE07-04 3–2 Part 3 – Troubleshooting...

  • Page 259: Overview Of Fault Indications And Safeties

    ESIE07-04 Overview of Fault Indications and Safeties Part 3 Overview of Fault Indications and Safeties What Is in This Chapter? Introduction In the first stage of trouble shooting sequence it is important to interpret the fault indication on the controller display. This will help you to find the cause of the problem. Overview This chapter contains the following topics: Topic...

  • Page 260: What To Do In The Event Of An Alarm

    Overview of Fault Indications and Safeties ESIE07-04 What to do in the Event of an Alarm? In the event of an alarm or a warning, the following must be done.. Step Action Result Press Alarm button to acknowledge The Alarm button LED lights up. the alarm.

  • Page 261: Overview Of Safeties

    ESIE07-04 Overview of Fault Indications and Safeties Overview of Safeties The following table shows the list of possible alarms with the identifier number, the cause and the reset type (A = auto, M = manual). Alarm Alarm cause Reset Phase monitor Intervention of the device control of phases.
  • Page 262 Overview of Fault Indications and Safeties ESIE07-04 Alarm Alarm cause Reset EXV Driver Eeprom error Driver EXV Eeprom error EXV Driver battery error Drive EXV battery error EXV not closed during power off Valve doesn’t close without power Alarms Expansion E Expansion Board Offline or not recognized 3–6 Part 3 –...

  • Page 263: Checking The Inputs And Outputs

    ESIE07-04 Checking the Inputs and Outputs Part 3 Checking the Inputs and Outputs What is in This Chapter? Introduction This chapter gives information of the configuration of the unput and output channels of the MicroTech II controller. Overview This chapter contains the following topics: Topic See page 2.2–List of Digital Inputs...

  • Page 264: List Of Digital Inputs

    Checking the Inputs and Outputs ESIE07-04 List of Digital Inputs The table below gives an overview of all the digital inputs. BOARD # 1 BOARD # 2 Compressor # 1 On/Off Compressor # 3 On/Off Compressor # 2 On/Off Compressor # 4 On/Off Evaporator Flow Switch Phase monitor Double Setpoint (Ice Mode)

  • Page 265: List Of Analog Inputs

    ESIE07-04 Checking the Inputs and Outputs List of Analog Inputs The table below gives an overview of all the analog inputs. BOARD # 1 BOARD # 2 Oil pressure # 1 Oil pressure # 3 Oil pressure # 2 Oil pressure # 4 Setpoint Override Gas temperature on compressor Gas temperature on compressor...

  • Page 266: List Of Digital Outputs

    Checking the Inputs and Outputs ESIE07-04 List of Digital Outputs The table below gives an overview of all the digital outputs. BOARD # 1 BOARD # 2 Start Compressor # 1 Start Compressor # 3 Load Compressor # 1 Load Compressor # 3 Unload Compressor # 1 Unload Compressor # 3 Liquid Injection # 1...

  • Page 267: List Of Analog Outputs

    ESIE07-04 Checking the Inputs and Outputs List of Analog Outputs The table below gives an overview of all the analog outputs. BOARD # 1 BOARD # 2 VFD output signal # 1 VFD output signal # 3 Second VFD output signal # 1 Second VFD output signal # 3 SPARE SPARE...

  • Page 268: List Of Input And Output Channels Of The Expansion Board # 1 (Option Economizer)

    Checking the Inputs and Outputs ESIE07-04 List of Input and Output Channels of the Expansion Board # 1 (Option Economizer) The table below gives an overview of all the inputs and outputs of the expansion board. Analog Input Expansion BOARD # 1 TYPE SPARE SPARE...

  • Page 269: What Is In This Chapter

    ESIE07-04 Procedure for Software Upload/Download Part 3 Procedure for Software Upload/Download What is in This Chapter? Overview This chapter contains the following topics: Topic See page 3.2–Copy from the Software Key to pCO² 3–14 3.3–Copy from pCO² to the Software Key 3–15 3.4–Installation of Winload32 on the PC and Programming a Controller 3–16...

  • Page 270: Copy From The Software Key To Pco²

    Procedure for Software Upload/Download ESIE07-04 Copy from the Software Key to pCO² Switch off the pCO and remove the "expansion memory" cover with a screwdriver (see "Copy from pCO² to the Software Key" on page 3–15/Fig. 1) Set the key selector on Insert the key in the corresponding pin connector as shown.

  • Page 271: Copy From Pco² To The Software Key

    ESIE07-04 Procedure for Software Upload/Download Copy from pCO² to the Software Key Switch off the pCO and remove the "expansion memory" cover with a screwdriver (see Fig. 1) Set the key selector on Insert the key in the corresponding pin connector as shown. (see Fig. 2) Press simultaneously the buttons UP an DOWN then supply the pCO Check the LED on the key is on (green color Wait until the request of copying appears on the LCD display, then release the buttons and confirm...

  • Page 272: Installation Of Winload32 On The Pc And Programming A Controller

    Create 2 folders 1: Carel to place progam winload in this folder 2: Carel_upload to place software program files in this folder 1. Go to the Daikin Extranet website 2. Select Software downloads 3. Select Service software 3–16 Part 3 – Troubleshooting...
  • Page 273 ESIE07-04 Procedure for Software Upload/Download Step Action Select Chiller PCO² page 1. Go to the WinLoad32 program page Part 3 – Troubleshooting 3–17...
  • Page 274 Procedure for Software Upload/Download ESIE07-04 Step Action 1. Click on winload32 to download the file 2. “file download” screen will appear 3. Click on save Download the file to your hard disk 1. Browse to the place were you want to save the file Example: save on C-drive 2.
  • Page 275 ESIE07-04 Procedure for Software Upload/Download Step Action The file “Winload32 v3.30” is now saved on the hard disk of your PC 1. Double click on the file Winzip will open : 1. Select winload32.exe 2. Press on extract Part 3 – Troubleshooting 3–19...
  • Page 276 Procedure for Software Upload/Download ESIE07-04 Step Action 1. Browse to the Carel folder 2. Press Extract. 1. Do the same (see previous screens) for the Carel drivers 2. Save the carel drivers in the Carel folder on your PC. 3. Follow the PDF instruction file in the zip archive to install the driver.
  • Page 277 ESIE07-04 Procedure for Software Upload/Download Step Action 1. Go back to the PCO² software download page on the extranet 2. Click on the model name Click to download the file Select save to download the file to your PC Part 3 – Troubleshooting 3–21...
  • Page 278 Procedure for Software Upload/Download ESIE07-04 Step Action Open the saved zip file Select the file for the unit (capacity Press extract Choose a location where you want to save the file (example: C-drive) Click extract The file is now save on the hard disk of your PC 1.
  • Page 279 ESIE07-04 Procedure for Software Upload/Download Step Action Winzip will open : 1. Select the files • If you have a 2Mb controller you can upload all languages (*.iup-files) • If you have a 1Mb controller only 2 languages can be uploaded, only extract 2 languages (*.iup-files) to the upload folder.
  • Page 280 Procedure for Software Upload/Download ESIE07-04 Step Action All program files are placed into the upload folder now Remark: • No old or other files may be placed into this (only program-files) • If you copy the files from a CD to this folder then the property of this files is “read only”...
  • Page 281 ESIE07-04 Procedure for Software Upload/Download Step Action 1. Go to the shortcut “shortcut to winload32” 2. Select properties 1. Go to target and type C:\Carel\WinLoad32.exe "C:\carel_upload" "EASY_BOOT " don’t forget the place ‘spaces’ 2. Press apply 3. Press OK Part 3 – Troubleshooting 3–25...
  • Page 282 Procedure for Software Upload/Download ESIE07-04 Step Action 1. Go to the Carel folder 2. Open Winload32 1. Go to the tab: “Application” 2. Open the Carel_upload folder to activate 3. If OK you will see the files that are in the Carel_upload folder 5.
  • Page 283 ESIE07-04 Procedure for Software Upload/Download Step Action 1. Go to the tab: “Bios” 2. Open the Carel_upload folder to activate 3. If OK you will see the BIOS file that is in the Carel_upload folder 1. Go to the tab: “Boot” 2.
  • Page 284 Procedure for Software Upload/Download ESIE07-04 Step Action 1. Go to the tab: “Public Variables” 2. Open the Carel_upload folder to activate 1. Go to the tab: “LogProject” 2. Open the Carel_upload folder to activate This is the folder where you can find the “program report” to check if uploading was successfully done.
  • Page 285 ESIE07-04 Procedure for Software Upload/Download Step Action 1. Double click “shortcut to winload32” 2. The white screen will appear and the program is now waiting for the controller. 3. When you see this screen you can now put power supply to the controller. 4.
  • Page 286 Procedure for Software Upload/Download ESIE07-04 Step Action Please check that you have 4 times “UPLOAD COMPLETED SUCCESSFULLY” 3–30 Part 3 – Troubleshooting...

  • Page 287: Copy Software From Winload32 To The Software Key

    ESIE07-04 Procedure for Software Upload/Download Copy Software from WinLoad32 to the Software key Optional: Carel RS Converter (software Winload + drivers: are available on intranet) Switch off the pCO and remove the "expansion memory" cover with a screwdriver (see "Copy from pCO²...
  • Page 288 Procedure for Software Upload/Download ESIE07-04 3–32 Part 3 – Troubleshooting...

  • Page 289: Evaporators

    ESIE07-04 Procedure to Protect Compressor in Case of Frozen Evaporator Part 3 Procedure to Protect Compressor in Case of Frozen Evaporator What is in This Chapter? Overview This chapter contains the following topics: Topic See page 4.2–Procedure to Protect Compressor in Case of Frozen Evaporator 3–34 Part 3 –...
  • Page 290 Procedure to Protect Compressor in Case of Frozen Evaporator ESIE07-04 Procedure to Protect Compressor in Case of Frozen Evaporator If water is detected in the compressor after an evaporator damage, the following procedure should be executed within the first day. Step Action Supply the compressor crank case heater.
  • Page 291 ESIE07-04 Procedure to Clear the Refrigerant Circuit in Case of Frozen Evaporators Part 3 Procedure to Clear the Refrigerant Circuit in Case of Frozen Evaporators What Is in This Chapter? Overview This chapter contains the following topics: Topic See page 5.2–Procedure to Clean the Refrigerant Circuit in Case of Frozen Evaporators 3–36 Part 3 –...

  • Page 292: Procedure To Clean The Refrigerant Circuit In Case Of Frozen Evaporators

    Procedure to Clear the Refrigerant Circuit in Case of Frozen Evaporators ESIE07-04 Procedure to Clean the Refrigerant Circuit in Case of Frozen Evaporators If water is detected in the refrigerant circuit after an evaporator damage, the following procedure should be executed to clear the system. Step Action Inspection and cleaning of compressor.

  • Page 293: Procedure For The Changing And Configuration Of The Display

    ESIE07-04 Procedure for the Changing and Configuration of the Display Part 3 Procedure for the Changing and Configuration of the Display What Is in This Chapter? Overview This chapter contains the following topics: Topic See page 6.2–Changing the Display 3–38 6.3–Configuration Procedure for the pLan Settings 3–39 Part 3 –...

  • Page 294: Changing The Display

    Procedure for the Changing and Configuration of the Display ESIE07-04 Changing the Display To change the display, proceed as follows: Step Action Switch off the power supplly to the chiller. Remove the old display Put the dipswitches of the new display on the right address. Place the new display in the same way as the old display.

  • Page 295: Configuration Procedure For The Plan Settings

    ESIE07-04 Procedure for the Changing and Configuration of the Display Configuration Procedure for the pLan Settings This procedure must be done in case a terminal is replaced or added (remote controller) in the pLan or if settings are changed. To start configuration, proceed as follows: Step Action Result...
  • Page 296 Procedure for the Changing and Configuration of the Display ESIE07-04 Step Action Result At the end of the operations turn off and restart the system. Remark: It is possible after restart that the terminal is stuck in a unit. This is due to the fact that the memory of the drivers remains fed by the buffer battery and keeps on processing the data contained in the preceding configuration.

  • Page 297: Procedure For The Changing And Configuration Of The Pco² ("I/O Board")

    ESIE07-04 Procedure for the Changing and Configuration of the PCO² (“I/O Board”) Part 3 Procedure for the Changing and Configuration of the PCO² (“I/O Board”) What Is in This Chapter? Overview This chapter contains the following topics: Topic See page 7.2–Changing the PCO²...

  • Page 298: Changing The Pco² Controller

    Procedure for the Changing and Configuration of the PCO² (“I/O Board”) ESIE07-04 Changing the PCO² controller To change the PCO² Controller, proceed as follows: Step Action Switch off the power supply to the chiller. Remove the old PCO² controller Place the new PCO² controller in the same way as the old PCO² controller. Change the PCO²...

  • Page 299: Procedure For The Changing Of The Electronic Expansion Valve Driver

    ESIE07-04 Procedure for the Changing of the Electronic Expansion Valve Driver Part 3 Procedure for the Changing of the Electronic Expansion Valve Driver What is in This Chapter? Overview This chapter contains the following topics: Topic See page 8.2–Changing the Expansion Valve Driver 3–44 Part 3 –...

  • Page 300: Changing The Expansion Valve Driver

    Procedure for the Changing of the Electronic Expansion Valve Driver ESIE07-04 Changing the Expansion Valve Driver To change the expansion valve driver, proceed as follows: Step Action Switch off the power supply to the driller. Remove the old EV driver Place the new EV driver in the same way as the old EV driver.

  • Page 301: What Is In This Chapter

    ESIE07-04 Procedure for the Changing and Configuration of the Expansion I/O Board (Optional) Part 3 Procedure for the Changing and Configuration of the Expansion I/O Board (Optional) What is in This Chapter? Overview This chapter contains the following topics: Topic See page 9.2–Changing the PCO²...

  • Page 302: Changing The Pco² Expansion Board

    Procedure for the Changing and Configuration of the Expansion I/O Board (Optional) ESIE07-04 Changing the PCO² Expansion Board To change the PCO² expansion board, proceed as follows: Step Action Switch off the power supply to the chiller. Remove the old expansion board driver Place the new expansion board in the same way as the old expansion board.

  • Page 303: What Is In This Chapter

    ESIE07-04 Manual Upload or Download Control Test Procedure Part 3 Manual Upload or Download Control Test Procedure 10.1 What is in This Chapter? Overview This chapter contains the following topics: Topic See page 10.2–Manual Upload or Download Control Test Procedure 3–48 Part 3 –...
  • Page 304 Manual Upload or Download Control Test Procedure ESIE07-04 10.2 Manual Upload or Download Control Test Procedure Introduction This function must only be used for testing of the unit, e.g. during commissioning or trouble shooting. Description This function allows setting the compressor to a fixed capacity step, without thermostat control. The unit is still protected by the normal safeties.

  • Page 305: Troubleshooting Chart

    ESIE07-04 Troubleshooting Chart Part 3 Troubleshooting Chart 11.1 What is in This Chapter? Overview This chapter contains the following topics: Topic See page 11.2–Troubleshooting Chart 3–50 Part 3 – Troubleshooting 3–49...

  • Page 306: Compressor Will Not Run

    Troubleshooting Chart ESIE07-04 11.2 Troubleshooting Chart Problem Possible causes Possible corrective steps 1 Main power switch is open. 1 Close switch. 2 Unit system switch is open. 2 Check the unit status on the control panel. Close switch. 3 Circuit switch is in pump-down 3 Check the circuit status on the position.
  • Page 307 5 There is high discharge 5 See corrective steps for high pressure. discharge pressure. 1 There is a compressor internal 1 Contact Daikin. Compressor problem. noisy or vibrating 2 The oil injection is not adequate. 2 Contact Daikin.

  • Page 308: Low Discharge Pressure

    Troubleshooting Chart ESIE07-04 1 There is wind effect at low 1 Protect the unit against ambient. excessive wind into the vertical coils. 2 The condenser fan control is not 2 Check if the unit set-up in the correct. microprocessor matches the unit Low discharge model number.
  • Page 309 ESIE07-04 Troubleshooting Chart 1 The “Q7” selector switch doesn’t 1 Replace the selector switch. work. 2 There is no heating load 2 Add additional equipment. required. 3 The flow switch is not operating. 3 Check the water pump. Unit does not 4 The 4-way solenoid valve is not 4 Check the solenoid valve and if switch to heat...
  • Page 310 Troubleshooting Chart ESIE07-04 3–54 Part 3 – Troubleshooting...

  • Page 311: Prestart System Checklist

    ESIE07-04 Prestart System Checklist Part 3 Prestart System Checklist 12.1 What is in This Chapter? Overview This chapter contains the following topics: Topic See page 12.2–Prestart System Checklist 3–56 Part 3 – Troubleshooting 3–55...
  • Page 312 Prestart System Checklist ESIE07-04 12.2 Prestart System Checklist Chilled water Piping complete Water system filled, vented Pump installed, (rotation checked), strainers cleaned Controls (3 way valves, face and bypass dampers, bypass valves, etc) operable Water system operated and flow balanced to meet unit design require- ments Heat recovery condensers Piping and headers complete...

  • Page 313: Commissioning And Test Run

    ESIE 07-04 Part 4 Commissioning and Test Run Introduction Commissioning and test run are well known practices in service engineering. This part contains a systematic approach on test run checks and test values, which guarantees a high quality installation and operation of the units. What is in this part? This part contains the following chapters: Chapter...
  • Page 314 ESIE 07-04 4–2 Part 4 – Commissioning and Test Run...

  • Page 315: Pre-Test Run Checks

    ESIE07-04 Pre-Test Run Checks Part 4 Pre-Test Run Checks What Is in This Chapter? Introduction This chapter contains checks you have to carry out before every test run. Overview This chapter contains the following topics: Topic See page 1.2–General Checks 4–4 1.3–Water Piping Checks 4–5...

  • Page 316: General Checks

    Pre-Test Run Checks ESIE07-04 General Checks Checklist The table below contains the general checklist. Step Check whether... There is external damage. The unit is properly supported and/or has a proper foundation. The unit is installed horizontally with a deviation of maximum 1°. Anti-vibration pads are required.

  • Page 317: Water Piping Checks

    ESIE07-04 Pre-Test Run Checks Water Piping Checks Checklist The table below contains the water piping checklist. Step Check whether... A filter is installed in front (less than 1 meter) of the water inlet of the heat exchanger. The heat exchangers are sensitive to dirt and small particles (maximum filter mesh of 1mm). The water volume is within the limits.
  • Page 318 Pre-Test Run Checks ESIE07-04 Evaporator Condenser The water pressure should not exceed the maximum working pressure of 10 bar. 4–6 Part 4 – Commissioning and Test Run...

  • Page 319: Water Pump Diagram

    ESIE07-04 Pre-Test Run Checks Water Pump Diagram Water pump The illustration below shows the water pump diagrams for the different pumps (option OPSP or diagram OPTP). Water flow (l/s) Note: For an effective hydraulic lift, subtract the evaporator pressure drop from the total hydraulic lift. Pump A STANDARD 550-600...

  • Page 320: Water Pressure Drop: Table For Matching Unit Sizes

    Pre-Test Run Checks ESIE07-04 Water Pressure Drop: Table for Matching Unit Sizes Table Unit size Note: Unit size matching system used for evaporator pressure drop curves, partial heat recovery ratings and pressure drop curves for partial and total heat recovery. 4–8 Part 4 –...

  • Page 321: Evaporator Pressure Drop: Ewad-Bjynn, Ewad-Bjynn/Q And Ewad-Bjynn/A

    ESIE07-04 Pre-Test Run Checks Evaporator Pressure Drop: EWAD-BJYNN, EWAD-BJYNN/Q and EWAD-BJYNN/A Evaporator The illustration below shows the water pressure drop through evaporator for EWAD-BJYNN pressure drop EWAD-BJYNN/Q and EWAD-BJYNN/A. M - N - O - P I - K - L B - C D - E 60 70 80 90 100...

  • Page 322: Evaporator Pressure Drop: Ewad-Bjynn/Z

    Pre-Test Run Checks ESIE07-04 Evaporator Pressure Drop: EWAD-BJYNN/Z Evaporator The illustration below shows the water pressure drop through evaporator for EWAD-BJYNN/Z. pressure drop I - K - L B - C 70 80 90 100 Water flow rate (l/s) Note: For matching unit size, see table on page 4–8.

  • Page 323: Pressure Drop For Partial Heat Recovery: Ewad-Bjynn

    ESIE07-04 Pre-Test Run Checks Pressure Drop for Partial Heat Recovery: EWAD-BJYNN Pressure drop for The illustration below shows the water pressure drop through evaporator for EWAD-BJYNN. partial heat S - T - U recovery O - P - Q E - F - G - H - I 8 9 10 Water flow rate (l/s) Note:...

  • Page 324: Pressure Drop For Total Heat Recovery: Ewad-Bjynn, Ewad-Bjynn/Q, Ewad-Bjynn/A And Ewad-Bjynn/Z

    Pre-Test Run Checks ESIE07-04 Pressure Drop for Total Heat Recovery: EWAD-BJYNN, EWAD-BJYNN/Q, EWAD-BJYNN/A and EWAD-BJYNN/Z Pressure drop for The illustration below shows the water pressure drop through evaporator for EWAD-BJYNN, total heat recovery EWAD-BJYNN/Q, EWAD-BJYNN/A and EWAD-BJYNN/Z. S-T-U O - P - Q F - G - H - I - J 9 10 70 80 90 100...

  • Page 325: Water Flow And Pressure Drop Precautions

    ESIE07-04 Pre-Test Run Checks 1.10 Water Flow and Pressure Drop Precautions Evaporator water Balance the chilled water flow through the evaporator. The flow rates must fall between the minimum flow and pressure and maximum values. Flow rates below the minimum values shown will result in laminar flow that will drop reduce efficiency, cause erratic operation of the electronic expansion valve and could cause low temperature cut-out.

  • Page 326: Electrical Checks

    Pre-Test Run Checks ESIE07-04 1.11 Electrical Checks Checklist The table below contains the electrical checklist. Step Check whether... The main fuses, earth leak detector and main isolator are installed. The main power supply voltage deviates less than 10% from the nominal value. The flow switch and pump contact are properly wired.

  • Page 327: Maintenance

    Preventive maintenance should be set up for operation at maximum capacity or to avoid damage. The following chapters explain how to or when to maintain the units. It is also applicable on other types of Daikin chillers. What is in this part?
  • Page 328 ESIE07-04 5–2 Part 5 – Maintenance...

  • Page 329: What Is In This Chapter

    ESIE07-04 Maintenance Part 5 Maintenance What Is in This Chapter Introduction As shown in the table below, we have grouped the maintenance in maintenance of the main parts (condenser, compressor and evaporator) and periodical checks. Precautions Correct choices and decisions have to be made before any maintenance is done. Opening the refrigerant circuit may cause a loss of refrigerant or lead to system contamination.

  • Page 330: System Maintenance

    Maintenance ESIE07-04 System Maintenance General To ensure proper operation at peak capacity and to avoid damage to package components, a program of periodic inspections should be set up and followed. The following items are intended as a guide and are to be used during inspection and must be combined with sound coming from compressor and electrical practices to ensure troublefree performance.
  • Page 331 ESIE07-04 Maintenance Evaporator The units are supplied with new optimised counter-flow evaporator, single refrigerant pass. It is direct expansion (2 evaporators for units with 4 compressors) with refrigerant inside the tubes and water outside (shell side) with carbon steel tube sheets, with straight copper tubes that are spirally wound internally for higher efficiencies, expanded on the tube plates.

  • Page 332: Lubricating Oils

    No maintenance is ordinary required except the occasional removal of dirt and debris from the outside surface of the fins. Daikin recommends the use of foaming coil cleaners available at air conditioning supply outlets. Use caution when selecting such cleaners as some may contain potentially harmful chemical.

  • Page 333: Charging The Refrigerant

    ESIE07-04 Maintenance When the system has been opened for extensive repairs, as for an overhaul, it is advisable to use the method of the evacuation as follows: 1 Evacuate the refrigerant system by the vacuum pump reaching the value of 200 Pa (1.5 mm Hg). 2 Break the vacuum with nitrogen until the atmospheric pressure is reached.

  • Page 334: Preventive Maintenance Schedule

    Maintenance ESIE07-04 Preventive Maintenance Schedule Overview SCHEDULE Operation TYPE OF OPERATION Six- Ref. No. Weekly Monthly Yearly Monthly Reading and recording of suction pressure Reading and recording of discharge pressure Reading and recording of supply voltage Reading and recording of current intensity Check refrigerant charge and possible moisture in the circuit refrigerant through the liquid sight glass...

  • Page 335: Start-Up And Shut-Down

    ESIE07-04 Maintenance Start-up and Shut-down Start-up Verify that all shut-off valves are open. Prior to starting the unit, open the water circulation pump(s) and regulate the flow through the evaporator and through the heat recovery condensers (if supplied) in accordance to the setting conditions of the unit.

  • Page 336: Seasonal Shut-Down

    Maintenance ESIE07-04 Seasonal Shut-down Procedure Turn the Q1 selector to Off position. The compressor will carry out its pump-down cycle and then stop. Repeat the sequence for all the selectors Q2, (Q3 and Q4) to stop all the other compressors. Switch the “Q0”...

  • Page 337: Maintenance Shut-Down

    ESIE07-04 Maintenance Maintenance Shut-down Procedure Turn the Q1 selector to Off position. The compressor will carry out its pump-down cycle and then stop. Repeat the sequence for all the selectors Q2, (Q3 and Q4) to stop all the other compressors. Switch the “Q0”...

  • Page 338: Periodical Checks

    Maintenance ESIE07-04 Periodical Checks Electrical checks The table below contains the electrical checks. Inspection checks and actions Remarks Check that all electrical wiring is properly — connected and securely tightened. Check the electrical components for damage or loss. — Check if the power supply corresponds with the —...
  • Page 339 ESIE07-04 Maintenance Noise checks The table below contains the noise checks. Inspection checks and actions Remarks Check for any abnormal noise. — Locate the noise producing section and search the cause. If the cause of the noise cannot be located, contact your dealer.
  • Page 340 Maintenance ESIE07-04 5–14 Part 5 – Maintenance...

  • Page 341: Periodical Checks

    ESIE07-04 Index 3–38 changing the display ............. . 3–44 changing the expansion valve driver .
  • Page 342 ESIE07-04 correction factors 1–29 altitude ..............1–29 ethylene glycol and low ambient temperature .
  • Page 343 ESIE07-04 3–48 manual upload or download control test procedure ........oil management safeties 2–109 high oil DP alarm.
  • Page 344 ESIE07-04 EWADC11-C12BJYNN/A, EWADC11-C12BJYNN/A+OPRN, EWADC11-C12BJYNN/A+OPLN, 1–88 EWADC12-C13BJYNN, EWADC12-C13BJYNN+OPRN and EWADC12-C13BJYNN+OPLN . 1–90 EWADC13BJYNN/A, EWADC13BJYNN/A+OPRN and EWADC13BJYNN/A+OPLN ..EWADC14BJYNN/A+OPSP, EWADC14BJYNN/A+OPRN+OPSP and 1–94 EWADC14BJYNN/A+OPLN+OPSP ..........1–92 EWADC14BJYNN/A, EWADC14BJYNN/A+OPRN and EWADC14BJYNN/A+OPLN .
  • Page 345 ESIE07-04 technical specifications 1–10 EWAD-BJYNN with OPLN ........... . 1–8 EWAD-BJYNN with OPRN .
  • Page 346 ESIE07-04 Index...

This manual is also suitable for:

Ewad550-c12bjynn/qEwad650-c21bjynn/aEwad600-c10bjynn/z

Table of Contents
