GV-BL1500
1.3MP H.264 Super Low Lux WDR IR Bullet IP Camera
Introduction
The Bullet Camera is specifically designed for outdoors. It adheres to the IP67 standard and has full protection against dust and jets of
water. The camera is equipped with a super low lux image sensor, which allows the camera to provide a color live view in near
darkness.
Active Tampering Alarm
Tampered
Dimensions
GV-BL1500
•
1.3 megapixel progressive scan super low lux CMOS
•
Min. illumination at 0.01 lux
•
Dual streams from H.264 and MJPEG
•
Up to 30 fps at 1280 x 1024
•
Intelligent IR
•
IR distance up to 70 m (230 ft.)
•
Vandal resistance (IK10 for metal casing)
•
Ingress protection (IP67)
•
Tolerant to extreme temperatures (‐30°C ~ 50°C/‐22°F ~ 122°F)
•
Cable‐concealed bracket preventing cable from being cut
•
One alarm input and sensor output
•
Built‐in micro SD card slot (SD/SDHC) for local storage
•
2‐way audio
•
Wide Dynamic Range (WDR)
•
3D DNR (Digital Noise Reduction)
•
Defog
•
Motion detection
•
Tampering alarm
•
Privacy mask
•
IP address filtering
•
DC 12V / AC 24V / PoE
•
Removable IR‐cut filter for Day/Night function
•
Supports iPhone, iPad, Android & 3GPP
•
31 languages on Web interface
•
ONVIF (Profile S) conformant
* No Memory Card Slot & local storage function for Argentina.
Focus Change
- 1 -
Camera Shift
December 13, 2013
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GeoVision GV-BL1500
Summary of Contents for GeoVision GV-BL1500
- Page 1 GV-BL1500 1.3MP H.264 Super Low Lux WDR IR Bullet IP Camera • 1.3 megapixel progressive scan super low lux CMOS • Min. illumination at 0.01 lux • Dual streams from H.264 and MJPEG • Up to 30 fps at 1280 x 1024 • Intelligent IR • IR distance up to 70 m (230 ft.) • Vandal resistance (IK10 for metal casing) • Ingress protection (IP67) • Tolerant to extreme temperatures (‐30°C ~ 50°C/‐22°F ~ 122°F) • Cable‐concealed bracket preventing cable from being cut • One alarm input and sensor output • Built‐in micro SD card slot (SD/SDHC) for local storage ...
-
Page 2: Specifications
Mechanical Temperature Detector Yes Pan 0° ~ 360° Camera Angle Tilt 90° ~ 180° Adjustment Rotate 0° ~ 360° Power 2‐pin terminal block, PoE Ethernet RJ‐45 1 In (RCA female for microphone) Connectors Audio 1 Out (RCA female for speaker) Digital I/O I/O Wires Auto Iris DC Drive - 2 - GV-BL1500 December 13, 2013... - Page 3 CMS Server support GV‐Control Center, GV‐Center V2, GV‐VSM Note: Specifications are subject to change without prior notice. Packing List 1. Bullet Camera 7. Silica Gel Bag x 2 2. Lens (Megapixel and Built‐In 16 IR LEDs) 8. 2‐Pin Terminal Block 3. Self Tapping Screw x 3 9. GV‐IPCAM H.264 Quick Start Guide 4. Plastic Screw Anchor x 3 10. GV‐IPCAM H.264 Software CD 5. Torx Wrench x 2 11. GV‐NVR Quick Start Guide 6. Sun‐Shield Cover Kit (1 Sun‐Shield Cover, 2 Philips Head 12. GV‐NVR Software DVD Screws, 2 Plastic Screw Spacers and 2 Hexagon Screws included) - 3 - GV-BL1500 December 13, 2013...
- Page 4 The GV‐Relay V2 is designed to expand the voltage load GV‐Relay V2 GV‐Relay V2 of GV IP devices. It provides 4 relay outputs, and each can be set as normally open (NO) or normally closed (NC) independently as per your requirement. Power Adapter Power adapters are available in 4 regions: U.S.A., Australia, U.K and Europe. GV‐POE Switch The GV‐POE Switch is designed to provide power along with network connection for IP devices. The GV‐POE Switch is available in various models with different numbers and types of ports. - 4 - GV-BL1500 December 13, 2013...
