- Page 1 P619SS-ANZ 60 cm Built in fan oven P629BS-ANZ/P629SS-ANZ P639BS-ANZ/P639SS-ANZ 60 cm Built in multifunction oven...
- Page 2 User Manual for your Baumatic P619SS-ANZ 60 cm 4 Function fan oven P629BS-ANZ/P629SS-ANZ 60 cm 7 Function multifunction oven P639BS-ANZ/P639SS-ANZ 60 cm 9 Function multifunction oven NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance.
-
Page 3: Table Of Contents
11 - 12 Cooling fan Control panel 13 - 14 Oven programmer/timer display Setting and using the oven programmer/timer – P619SS-ANZ Selecting manual operation mode Setting the minute minder function Setting and using the oven programmer/timer – P629BS-ANZ/ P629SS-ANZ/P639BS-ANZ/P639SS-ANZ 16 – 20... -
Page 4: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this... - Page 6 Child Safety o Baumatic strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 7 This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o Baumatic Ltd. declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.
-
Page 8: Specifications
Specifications P619SS-ANZ Product dimensions Aperture dimensions Height: 590 mm Height: 580 – 583 mm Width: 595 mm Width: 560 mm Depth: 550 mm Depth: 550 mm Product specifications o 4 oven functions o Energy efficiency class: A o Gross oven capacity: 59 litres... -
Page 9: P629Bs-Anz/P629Ss-Anz
o Removable side racks Optional extras o TEL2KIT Telescopic runners kit o SCL7KIT Stay-clean liners kit o BPS2 Pizza stone Electrical details Rated Voltage: 220 - 240 Vac 50 Hz Supply Connection: 13 A (double pole switched fused outlet with 3mm contact gap) Max Rated Inputs: 2.35 kW Mains Supply Lead:... - Page 10 o Oven light o LED full programmer o Cooling fan o Thermostatically controlled grill o Triple-glazed removable door o Mark resistant coating (P629SS-ANZ only) Standard accessories o Enamelled baking tray with handle o 2 x Safety shelves o Trivet o Removable side racks o Removable roof liner o Telescopic runners- 1 level Optional extras...
-
Page 11: P639Bs-Anz/P639Ss-Anz
P639BS-ANZ/P639SS-ANZ Product dimensions Aperture dimensions Height: 590 mm Height: 580 – 583 mm Width: 595 mm Width: 560 mm Depth: 550 mm Depth: 550 mm Product specifications o 9 oven functions o Energy efficiency class: A o Gross oven capacity: 59 litres o Net oven capacity: 50 litres o Oven light o LED full programmer... -
Page 12: Cooling Fan
o BPS2 Pizza stone o Telescopic runners – 2 levels Optional extras o SCL7KIT Stay-clean liners kit Electrical details Rated Voltage: 220 - 240 Vac 50 Hz Supply Connection: 13 A (double pole switched fused outlet with 3mm contact gap) Max Rated Inputs: 3.35 kW Mains Supply Lead:... -
Page 13: Control Panel
Control Panel P619SS-ANZ 1) Oven function selector knob 2) Power indicator light 3) Minute minder/manual operation control knob 4) Oven operating light 5) Thermostat control knob P629BS-ANZ/P629SS-ANZ... -
Page 14: Oven Programmer/Timer Display
P639BS-ANZ/P639SS-ANZ 1) Oven function selector knob 2) LED display 3) Thermostat control knob 4) Power indicator light 5) Oven operating light 6) Timer minute minder button 7) Timer duration button 8) Timer end cook button 9) Timer manual operation button 10) Timer minus button 11) Timer plus button Oven programmer/timer display (P629BS-ANZ/P629SS-... -
Page 15: Setting And Using The Oven Programmer/Timer - P619Ss-Anz
Setting and using the oven programmer/timer – P619SS-ANZ Selecting manual operation mode Before you can select a cooking function or set a temperature, you must set the appliance into manual operation mode. o Turn the manual operation control knob (3) anti-clockwise, so that it points to the word ON. -
Page 16: Setting And Using The Oven Programmer/Timer - P629Bs-Anz
Setting and using the oven programmer/timer – P629BS-ANZ/P619SS-ANZ/P639BS-ANZ/P639SS-ANZ Selecting manual operation mode After your appliance is connected to your mains supply for the first time, the numbers on the timer display will flash. Before you can select a cooking function or set a temperature, you must set the appliance into “manual operation”... -
Page 17: Setting The Duration Function
o Important: The oven will continue to heat once the alarm has been silenced. If you have finished cooking, then you should turn the oven function selector and thermostat control knob to 0. Setting the duration function This function will allow you to set a countdown time similar to the minute minder function. -
Page 18: Setting The End Cook Function
Setting the end cook function This function is similar to the duration function, however instead of selecting a period of time that you wish the oven to switch off after. You select the time of day that you wish the oven to switch off at. -
Page 19: Setting The Start And End Time Function
Setting the start and end time function This function will allow you to set a time in the future that the oven switches on at and a time that the oven will switch off at. o Use the thermostat control knob (3) to set the temperature that you require. -
Page 20: Adjusting The Audible Signal
Adjusting the audible signal o The audible signal has three different settings, low, medium and high. o To adjust the level of the audible signal, make sure that the timer is in manual mode. Then press and hold the minus button and you will hear the current level that is set. -
Page 21: Selecting Manual Operation Mode
When a function is selected, the power indicator light will come on. P619SS-ANZ oven functions LIGHT MODE: Separate light control which allows the oven light to be switched on, even when the oven is not heating. -
Page 22: P629Bs-Anz/P629Ss-Anz Oven Functions
DEFROST MODE: The fan runs without heat to reduce the defrosting time of frozen foods. The time required to defrost the food will depend on the room temperature, the quantity and type of food. Always check food packaging for the defrosting instructions. -
Page 23: P639Bs-Anz/P639Ss-Anz Oven Functions
P639BS-ANZ/P639SS-ANZ oven functions CONVENTIONAL OVEN (top and lower element): This method of cooking provides traditional cooking, with heat from the top and lower elements. This function is suitable for roasting and baking on one shelf only. GRILL MODE: This method of cooking utilises the inner sections of the top element, which directs heat downwards onto the food. -
Page 24: Thermostat Control Knob
Thermostat control knob The oven thermostat control knob sets the required temperature of the oven. It is possible to regulate the temperature within a range of 50 - 250°C. Oven operating light This light will come on to indicate that oven’s heating elements are in... -
Page 25: Warnings
o If there is no guidance given on the food packaging specifically for cooking in fan oven mode, you can generally reduce the cooking time and temperature by 10% from the information given for conventional oven cooking. o Make sure that frozen foods are thoroughly thawed before cooking, unless the instructions on the food packaging advise that you can “cook from frozen”. -
Page 26: Shelf Levels
o When removing the baking tray, you should ALWAYS use an oven glove. o Warning: Accessible parts may become hot during use. Young children should be kept well away from the oven when it is in use. Shelf levels o Safety shelf (A) o Removable side racks,... -
Page 27: Removable Oven Roof Liner (P629Bs-Anz/P629Ss-Anz/P639Bs-Anz/ P639Ss-Anz Only)
Any damage that is caused to the appliance by a cleaning product will not be fixed by Baumatic free of charge, even if the appliance is within the guarantee period. Removable... -
Page 28: Removing The Oven Door For Cleaning
o Remove the light cover by turning it anti-clockwise. o Unscrew the bulb clockwise and remove it from its holder. o Replace the bulb with a 25 W/300°C, screw type pygmy. o Do not use any other type of bulb. o Place the lamp cover back into position. -
Page 29: Installation
as the hinge mechanism has a strong spring. o Do not immerse the door in water at any time. INSTALLATION The installation must be carried out by a suitably qualified person, in accordance with the current version of the following. o AS/NZS 3000: 2007 Wiring Regulations o 2010 Electricity Safety Regulations Before connecting the appliance, make sure that the supply voltage... -
Page 30: Installing The Oven Into The Kitchen Cabinet
Installing the oven into the kitchen cabinet Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. o The oven must be fitted into an oven housing with the ventilation cut-outs shown in the “Ventilation requirements”... - Page 31 (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a standard kitchen unit). (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a tall housing unit). o Ensure that the oven has been securely fixed into the housing unit.
-
Page 32: My Appliance Isn't Working Correctly
My appliance isn’t working correctly o The oven isn’t coming on. * Check that the oven is in manual operation mode. * Check that you have selected a cooking function and a cooking temperature. o There appears to be no power to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly. - Page 33 o The oven light is not working. * Refer to pages 27 - 28 and follow the “Replacing the oven bulb” section. o I am getting condensation in my oven. * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc.
- Page 34 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...
-
Page 35: Contact Details
Service Telephone 1800 444 357 Website www.thinkappliances.com Applico Ltd. Private Bag 92900 Onehunga, Auckland 1061, New Zealand Website www.baumatic.co.nz United Kingdom Baumatic Ltd., Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Sales Telephone (0118) 933 6900 Website: www.baumatic.co.uk...
