Baumatic POG4201SS Instruction Manual

60 cm gas oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction manual

Advertisement

Table of Contents
loading

Related Manuals for Baumatic POG4201SS

Summary of Contents for Baumatic POG4201SS

  • Page 1 Instruction manual...
  • Page 3 POG4201SS 60 cm gas oven...
  • Page 5 User Manual for your Baumatic POG4201SS 60 cm gas oven NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for...

  • Page 7: Table Of Contents

    Contents Environmental note Important safety information Specifications Product specifications Standard accessories Optional extras Electrical details Control panel Using your gas oven Before first use Switching the gas oven on Switching the electric grill on Operation of the fan Cooking guidelines Warnings Base burner appliances Using the electronic programmer...

  • Page 8: Environmental Note

    Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.

  • Page 9: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If yo are unsure of any of the information contained in t ooklet, please contact the Baumatic Advice Line.
  • Page 10 This appliance complies with all current European safety legislation. Baumatic do wish to emphasise that this compl iance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation.
  • Page 11 o Do not place heavy objects on the oven door or lean on the oven door when it is open, as this can cause damage to the oven door hinges. Nobody should be allowed to sit or stand on any part of the oven.
  • Page 12 Please see the specific section of this booklet that refers to installation. o Baumatic Ltd. declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.

  • Page 13: Specifications

    Specifications (IMPORTANT: The above drawing does not show the ventilation requirements that are necessary for installing this appliance, please refer to the installation instructions for this information). Product Dimensions Aperture Dimensions Height: 591 mm Height: 580 mm– 583 mm Width: 597 mm Width: 556 mm –...

  • Page 14: Standard Accessories

    Standard accessories o 2 x safety shelves o Enamelled baking tray with handle o Trivet o LPG conversion jets Optional extras o BPS2 Pizza stone Electrical details Rated Voltage: 220-240 Vac 50 Hz Supply Connection: 13 A (double pole switched fused outlet with 3mm contact gap) Fuse rating: 3 amp...

  • Page 15: Control Panel

    Control Panel Grill ON Gas oven ON indicator neon indicator neon Electric oven functions Electronic Gas oven control knob programmer control knob Using your gas oven Before first use o To remove any residue from the oven that may have been left from the manufacturing process, you should select the gas oven and set it to its maximum temperature setting.

  • Page 16: Switching The Gas Oven On

    o We would recommend that an appropriate stainless steel cleaner and polish is regularly used on the stainless steel surfaces of this appliance. Switching the gas oven on The oven has automatic ignition, to light it you should do the following:- o Open the door of the appliance.
  • Page 17 USING THE ELECTRIC GRILL SYMBOLS Pos. 0 OVEN LIGHT SPIT Switch the gas oven on and set the thermostat knob to between 150°C and 270°C. The oven door must be closed. GRILL + SPIT This type of cooking allows you to brown the food. The oven door must be kept open and the knob protection fitted.

  • Page 18: Cooking Guidelines

    Cooking guidelines o Please refer to the information given on food packaging for guidance on cooking temperatures and times. Once familiar with the performance of your appliance, temperatures and times can be varied to suit personal preference. o Preheat the oven for at least 15 minutes, before placing food into the cavity.

  • Page 19: Warnings

    Warnings o Keep the oven door open when using the grill function and make sure that the grill deflector is fitted. o Do not use aluminium foil to cover the enamelled baking tray or heat items wrapped in aluminium foil under the grill. o You should also never line the base of your oven with aluminium foil.

  • Page 20: The Oven Light

    o We would recommend that you place the enamelled baking tray into the lowest shelf position. o This will deflect some of the fierce heat generated by the base burner away from the food that you are cooking. o This will allow food to cook all of the way through, without getting burnt on the base.

  • Page 21: Electronic Clock

    ELECTRONIC CLOCK The electronic clock has a display showing the hours and minutes. When the oven is switched on for the first time or immediately after a blackout, three zeros will flash on the display. To select the time, press button A and simultaneously button B or C until the current time is shown on the display.

  • Page 22: Cleaning And Maintenance

    Any damage that is caused to the appliance by a cleaning product will not be fixed by Baumatic free of charge, even if the appliance is within the guarantee period.

  • Page 23: Replacing The Oven Bulb

    Replacing the oven bulb IMPORTANT: The oven must be disconnected from your mains supply before you attempt to either remove or replace the oven bulb. o Remove all oven shelves and the enamelled baking tray to make it easier to access the bulb. o Remove the light cover by turning it anti- clockwise.

  • Page 24: Removing The Inner Door Glass For Cleaning

    o IMPORTANT: You should make sure that the door is supported at all times and that you place the door on some padded material whilst cleaning it. o The oven door and door glass should only be cleaned using a damp cloth and a small amount of detergent.

  • Page 25: Installation

    Installation The installation must be carried out by a suitably qualified person, in accordance with the current version of the following. o UK Regulations and Safety Standards or their European Norm Replacements. o Building Regulations (issued by the Department of the Environment).

  • Page 26: Positioning

    Positioning The adjacent furniture and all materials used in the installation must be able to withstand a minimum temperature of 85°C above the ambient temperature of the room it is located in, whilst the appliance is in use. o Your appliance is heavy, so you should be careful when moving or positioning it.

  • Page 27: Installing The Oven Into The Kitchen Cabinet

    Installing the oven into the kitchen cabinet Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. o The oven must be fitted into an oven housing with the ventilation cut-outs shown in the “Ventilation requirements”...

  • Page 28: Ventilation Requirements

    Ventilation requirements o You should remove the rear panel of the housing unit before attempting to install the oven. A full depth shelf must be incorporated into the housing and positioned 50 mm below the support shelf for the appliance. o A minimum ventilation gap of 50 mm must be allowed between the rear of the support shelf and the rear of the housing unit.
  • Page 29 Additional built under ventilation requirements o Remove the horizontal strengthening support at the upper front housing unit. o If your housing unit incorporates a domestic lower drawer, this must be made non-functioning with a ventilated false front. o A 5 mm ventilation gap must be allowed between the top of the appliance and the underside of the worktop.

  • Page 30: Gas Connection

    Conversion for use on LPG and other gases must only be undertaken by a qualified person. For information on the use of other gases, please contact the Baumatic Advice Line. o The oven must be installed by a qualified person, in accordance with the current edition of the Gas Safety (Installation and Use) Regulations and the relevant building/I.E.E.

  • Page 31: Gas Safety (Installation And Use) Regulations

    o Ensure that the room containing the oven is well ventilated, keep natural ventilation holes. o Prolonged intensive use of the appliance may call for additional ventilation. o This oven is not fitted with a device for discharging the products of combustion.

  • Page 32: Gas Connection

    Gas connection ALL INSTALLATION AND SERVICE WORK MUST BE CARRIED OUT BY A CORGI REGISTERED ENGINEER. o Prior to installation, ensure that the gas supply conditions (nature of the gas and gas pressure) and the adjustment conditions are compatible. The adjustment conditions for this appliance are stated on the rating plate which can be found on the back cover.

  • Page 33: Gas Adjustment (Conversion To Lpg And Gas Adjustment)

    Gas adjustment (Conversion to LPG and gas adjustment) IMPORTANT: Your appliance must be disconnected from the electric and gas supply before completing this process. Power inputs Natural Gas Oven 2.74 kW (injector size 115) 2.74 kW (injector size 80) Grill 2.4 kW (injector size 115) 2.4 kW (injector size 80)
  • Page 34 o Remove the grill burner. o Replace the injector with one suitable for LPG (see power inputs information). It is recommended that the appropriate thread sealant is used; always check for gas tightness after assembly. o Re-fix the grill burner, no further adjustments are necessary. o Remove the control panel cover from the top of the appliance.

  • Page 35: My Appliance Isn't Working Correctly

    o Adjust the bypass setting until the correct flame picture is achieved. o Refit the control knob, then turn it to the Max position and then back to Min several times, checking that the flame is maintained. o Fully open and close the oven door several times and check that the flame is maintained.
  • Page 36 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...
  • Page 37 Czech Republic United Kingdom Baumatic CR spol s.r.o. Baumatic Ltd., Amperova 495 Baumatic Buildings, 46215, Librec 6 Bennet Road, Czech Republic Reading, Berkshire RG2 0QX +420 800 185 263 United Kingdom www.baumatic.cz Sales Telephone (0118) 933 6900 Slovak Republic Sales Fax Baumatic Slovakia, s.r.o.
  • Page 38 12300133870...
  • Page 40 Baumatic ® w w w . b a u m a t i c . c o m...
