Carrier 40MVC Product Data page 9

PHYSICAL DATA (CONT.)
Indoor Unit 40MVQ
System Voltage
Nominal Capacity (Btuh)
Operating Weight lb (kg)
Refrigerant Type
Metering Device
Charge lb (kg)
Indoor Fan
Rpm/Cfm (High)
Rpm/Cfm (Medium)
Rpm/Cfm (Low)
Motor (Watts / hp)
Blower Diameter ... Length (in)
Indoor Coil
Face Area (sq. ft)
No. Rows
Fins per inch
Circuits
Controls
Remote Controller
Fan Mode
Auto Changeover
Dehumidification Mode
Demand Defrost
Sleep Mode
Diagnostics
Timer Mode
Freeze Protection
Test Mode
Auto Restart
Auto Sweep
Control Voltage
Refrigerant Lines
Connection Type
Liquid Line (in) OD
Vapor Line (in) OD
Maximum Length* ft (m)
Max Lift (Fan Coil Above) ft (m)
Max Drop (Fan Coil Below) ft (m)
Condensate Drain
Size (in)
External Finish
* Refer to Long Line Application section on page 21
009 012
115 115 or 208/230
9000 12000
17.6 (8) 25.3 (11.5)
2.35 (1.1) 3.0 (1.4)
1250/325 1270/425
1000/260 1100/365
800/190 1000/340
20 / .034 25 / .044
3.84 ... 25.87 4.17 ... 25.2
2.15 2.54
2
19.5 19.5
2
13 VDC 13 VDC
1/4" 1/4"
3/8" 1/2"
65 (19.8) 65 (19.8)
35 (10.7) 35 (10.7)
35 (10.7) 35 (10.7)
.65 (OD) .53 (ID) .65 (OD) .53 (ID)
White White
9
018
208/230
18000
39.6 (18)
R---410A
Capillary Tube at Outdoor
4.5 (2.0)
1070/630
1000/570
960/500
31 / .075
4.21 ... 37.6
4.36
2 2
19.5
3 6
Integrated Microprocessor
Wireless
High/Medium/Low/Auto
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Pulse DC
Flare
1/4"
1/2"
100 (30.5)
50 (15.2)
50 (15.2)
.65 (OD) .53 (ID)
White
024
208/230
24000
39.6 (18)
5.3 (2.4)
1070/750
1000/660
960/585
50 / .112
4.21 ... 37.6
4.36
2
19.5
6
Pulse DC
3/8"
5/8"
100 (30.5)
60 (18.3)
60 (18.3)
.65 (OD) .53 (ID)
White
