Low Sound Levels; Secure Operation; Fast Installation; Individual Room Comfort - Carrier 40MVC Product Data

LOW SOUND LEVELS

When noise is a concern, the duct- -free split systems are the answer.
The indoor units are whisper quiet. There are no compressors
indoors, either in the conditioned space or directly over it, and
there is none of the noise usually generated by air being forced
through ductwork.
When sound ordinances and proximity to neighbors demand quiet
operation, the 38MVC,MVQ unit is the right choice: The
advanced, horizontal airflow design distributes air more evenly
over the coil.

SECURE OPERATION

If security is an issue, outdoor and indoor units are connected only
by refrigerant piping and wiring to prevent intruders from crawling
through ductwork. In addition, since 38MVC,MVQ units can be
installed close to an outside wall, coils are protected from vandals
and severe weather.

FAST INSTALLATION

This compact duct- -free split system is simple to install.
mounting bracket is standard with the indoor units and only wire
and piping need to be run between indoor and outdoor units. These
units are fast and easy to install ensuring minimal disruption to
customers in the home or workplace. This makes the
38/40MVC,MVQ duct- -free split systems the equipment of choice,
especially in retrofit situations.
SIMPLE SERVICING AND
MAINTENANCE
Removing the top panel on outdoor units provides immediate
access to the control compartment, providing a service technician
access to check unit operation. In addition, the draw- -thru design of
the outdoor section means that dirt accumulates on the outside
surface of the coil. Coils can be cleaned quickly from the inside
using a pressure hose and detergent.
On all indoor units, service and maintenance expense is reduced
due to easy- -to- -use cleanable filters. In addition, these high wall
systems have extensive
troubleshooting.
self- -diagnostics to assist
BUILT- - IN RELIABILITY
Duct- -free split system indoor and outdoor units are designed to
provide years of trouble- -free operation.
The high wall indoor units include protection against freeze- -up
and high evaporator temperatures on heat pumps.
The condensing units and heat pumps are also protected. There is
a three minute time delay before the compressor will start. The
compressor is also protected by the over- -current protection. On
size 18k and 24k heat pumps, there is high temperature protection.

INDIVIDUAL ROOM COMFORT

Maximum comfort is provided because each space can be
controlled individually based on usage pattern. The air sweep
feature provided permits optimal room air mixing to eliminate hot
and cold spots for occupant comfort. In addition, year- -round
comfort can be provided with heat pumps.
ECONOMICAL OPERATION
The duct- -free split system design allows individual room heating
A
or cooling when required. There is no need to run large supply- -air
fans or chilled water pumps to handle a few spaces with unique
load patterns. In addition, because air is moved only in the space
required, no energy is wasted moving air through ducts.
EASY- -TO- - USE CONTROLS
The high- -wall units have microprocessor- -based controls to
provided the ultimate in comfort and efficiency. The user friendly
wireless remote control provides the interface between user and the
unit.
ACCESSORIES
Customizing these duct- -free split systems to your application is
easily accomplished.
(permitting cooling operation down to - -20_F (- -28.89_C)outdoor
ambient) is easily added on all units.
Adding a condensate pump accessory to the high wall fan coil
provides installation flexibility.
in
AGENCY LISTINGS
All systems are listed with ARI (Air Conditioning & Refrigeration
Institute), and ETL.
2
Low- -ambient temperature capability
