Sound Devices 788T User Manual Addendum page 17

# Setup Name
70 HP: Monitor Modes
71 HP: Favorite Mode
72 HP: Playback Mode
73 HP: Warning Bell Level
74 HP: Rec/Stop Bell
75 HP: Power Up Gain
76 Tone: Level
77 Tone: Frequency
78 Tone: Mode
79 Drive: Speed Tests
80 Balance Cal
81 Power: Ext Low Batt Volt
Description
Selects the modes and the sequence
in which they appear in the Head-
phone Source Display.
Selects the audio source monitored
when the Multi-Function Rotary
Switch is pressed during Record or
Playback.
Selects the audio source sent to the
headphones during Playback.
Sets the output level of the warning
bell.
Alerts the user with one beep at the
start of recording and two beeps
when the recording is stopped
Selects the level at which the
headphone gain level will be set upon
power up.
Sets the reference tone's output level.
Sets the tone oscillator frequency.
Selects the reference tone's
destination(s).
Performs a write/read speed test on
the internal hard drive, Compact-
Flash, and external drives. Data
transfer speed is measured in KB/s.
Calibrates the center position of the
even channel (2,4,6,8) pots when
used as the balance control for MS
recording.
Sets the external low battery warning
point. The internal low battery level is
not user-adjustable.
Options
Inputs 1,2 Inputs 3,4 (MS)
Inputs 3,4 Inputs 5,6 (MS)
Inputs 5,6 Inputs 7,8 (MS)
Inputs 7,8 Tracks L,R (MS)
Tracks L,R Tracks A,B (MS)
Tracks A,B Tracks C,D (MS)
Tracks C,D Tracks E,F (MS)
Tracks E,F Inputs 1-4, 1-4
Input 1,1 Inputs 1-6, 1-6
Input 2,2 Inputs 1-8, 1-8
Input 3,3 Tracks LA, RB
Input 4,4 Tracks LAC, RBD
Input 5,5 Tracks LACE, RBDE
Input 6,6 Tracks LRAB, LRAB
Input 7,7 Tracks LRABCD, LRABCD
Input 8,8 Tracks LRABCDEF, LRABCDEF
Track L,L Tracks LR, LR
Track R,R Tracks LRA, LRA
Track A,A Tracks LRB, LRB
Track B,B Tracks LRC, LRC
Track C,C Tracks LRD, LRD
Track D,D Tracks LRE, LRE
Track E,E Tracks LRF, LRF
Track F,F Input B-format stereo
Inputs 1,2 (MS) Track B-format stereo
Any of the HP: Monitor Modes can be selected
as the HP: Favorite Mode. See the above
chart for options.
• No change
• Same options listed in HP: Monitor Modes
off, −60 to –12 dBFS in 1 dB steps
• Disabled
• Enabled
• Last Gain
• Midpoint Gain
• Off
−40 to 0 dBFS in 1 dB steps
100–10,000 Hz in 100 Hz steps
• Disabled
• To record tracks only
• To outputs only
• To record tracks and outputs
Caution: Drive test will disable processing and
mute outputs for duration of test. Outputs will
not return until test is exited.
Place balance control to center and press to
select.
10.0–18.0 VDC, 0.1 V steps
788T User Guide Addendum
Factory
Default
1) Tracks L,R
2) Tracks L,L
3) Tracks R,R
4) Tracks A,A
5) Tracks B,B
6) Tracks C,C
7) Tracks D,D
8) Tracks E,E
9) Tracks F,F
10) Tracks LACE,
RBDF
11) Inputs 1,2
12) Inputs 3,4
13) Inputs 5,6
14) Inputs 7,8
15) Input 1,1
16) Input 2,2
17) Input 3,3
18) Input 4,4
19) Input 5,5
20) Input 6,6
21) Input 7,7
22) Input 8,8
23) Inputs1-8, 1-8
Tracks L,R
Tracks L,R
-30 dBFS
Enabled
Last Gain
-20 dBFS
1000 Hz
To record tracks
and outputs
10.5 Volts
