Page 1: User Manual
ACE PLUS CORP. EX-G033A/EX-G033B RS-232 over CAT5 Extender (EX-G033B for Point-to-Point & EX-G033A for Cascadable) User Manual Headquarters : Page 1 of 8 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian, Taipei, Taiwan 231 TEL: +886-2-2912-4201 FAX: +886-2-2912-3164 Website: www.ace-plus.com... -
Page 2: Safety And Notice
However, like all electronic equipments, the EX-G033B/EX-G033A should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 DIP switches. After finishing the setup, the serial connection has a fixed communication channel between local and remote sites. For EX-G033A, the same source unit as EX-G033B, but on the receiving side, the receivers can be cascadable up to 32 units. This structure allows users to control tens of remote units through single Cat-5 cable.
-
Page 4: Specifications & Package Contents
Package Contents 1x User Manual Hardware Installation 1. Connect your serial RS-232 source to the EX-G033B/EX-G033A transmitting unit. 2. Connect your serial receiver to the EX-G033B/EX-G033A receiving unit. 3. Connect your CAT-5/5e/6 cable between the transmitting and receiving units. 4. Make sure your CAT-5/5e/6 cable is tightly connected and not loose. - Page 5 ACE PLUS CORP. EX-G033B-TX CAT-5e cable 1,000 meters (1,100 yards) 6-pin DIP switch setting EX-G033B-RX EX-G033A-TX 6-pin DIP switch setting CAT-5e cable 1,000 meters (1,100 yards) EX-G033A-RX Page 5 of 8 Headquarters : 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,...
-
Page 6: Dip Switch Position
ID Bits are composed of 5 bits, and the left most bit is the highest bit. As cascade bit is set to off as shown above, the EX-G033A acts exactly like EX-G033B, and all the serial command specific to EX-G033A-RX (see table 2) will be ignored. - Page 7 ACE PLUS CORP. EX-G033A Serial Command In order to control the remote units, EX-G033A-RX offers a set of serial command to setup the baud rate, ID, and enable of the feedback from the remote units. Table 1 — Serial Command Protocol...
-
Page 8: Limited Warranty
Termination Limited Warranty The SELLER warrants the EX-G033B/EX-G033A RS-232 over CAT5 Extender to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period,...
