ACE PLUS CORP.
HDMI 1.3 over CAT5 Wall Plate Extender
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : +886-2-2912-4201
Fax : +886-2-2912-3164
E-Mail: marketing@ace-plus.com
Technical Support: vincent@ace-plus.com
http://www.ace-plus.com
http://www.ace-plus.tw
Wall Plate Series
EX-G019
with IR Control Path
User Manual
Page 1 of 10
FEB
22
/ 2011
Version 1.0
Advertisement
Table of Contents
Related Manuals for Ace Plus EX-G006
Summary of Contents for Ace Plus EX-G006
-
Page 1: User Manual
ACE PLUS CORP. Wall Plate Series EX-G019 HDMI 1.3 over CAT5 Wall Plate Extender with IR Control Path User Manual Headquarters : Page 1 of 10 9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan / 2011... - Page 2 ACE PLUS CORP. Introduction The EX-G019 HDMI 1.3 over CAT5 Wall Plate Extender with IR Control Path wall plate edition boosts up your video/audio transmission distance up to 60m [200ft] in HDTV 720p/1080i format. With two low cost CAT-5/5e/6 LAN cables, users can readily extend HDTV sources from DVD players, Blu-ray Disc player, PS3, PC, and any other kinds of sources compliant with TMDS to distant display monitors including HDMI enabled TV sets, LCD PC monitors, or projectors.
-
Page 3: Specifications & Package Contents
ACE PLUS CORP. Specifications & Package Contents Model Name EX-G006 EX-G009 EX-G019 Technical EX-G006-TX EX-G006-RX EX-G009-TX EX-G009-RX EX-G019-TX EX-G019-RX Role of usage Transmitter [TX] Receiver [RX] Transmitter [TX] Receiver [RX] Transmitter [TX] Receiver [RX] HDMI compliance HDMI 1.3c HDCP compliance Video bandwidth Single-link 340MHz [10.2Gbps]... -
Page 4: Panel Descriptions
ACE PLUS CORP. Panel Descriptions Front View — Transmitting Unit [EX-G019-TX] HDMI IN E X TENDER HDMI IN: Connect to a HDMI source with a HDMI M-M cable here. IR EXTENDER: Extendable infrared sending socket for plugging in the extension cable of IR emitter\ Push button: Select CEC or IR transmission (Must be consistent with RX unit). - Page 5 ACE PLUS CORP. Front View — Receiving Unit [EX-G019-RX] HDMI OUT E X TENDER HDMI OUT: Connect to a HDMI display with a HDMI M-M cable here. EQ: Adjust the 8-level equalization control to the received HDMI signals. 0 – 7 = strongest – weakest.
-
Page 6: Definition Of Ir Earphone Jack
ACE PLUS CORP. IR Control Path IR Cables IR Emitter Cable IR Receiver Cable IR Sockets EX-G019-TX IR Extender: Plug in the IR emitter cable here to transmit all IR command signals received from the IR receiver. EX-G019-RX IR Extender: Plug in IR receiver cable connected here to receive all IR command signals from the IR remote control of the HDMI source machine. -
Page 7: Supported Ir Data Format
ACE PLUS CORP. Supported IR Data Format Data Format Suitable Recommended TOSHIBA MICOM CODE GRUNDIG CODE SONY 12 BIT CODE SONY 15 BIT CODE SONY 20 BIT CODE RCA CODE RCM CODE MATSUSHITA CODE MITSUBISHI CODE ZENITH CODE JVC CODE... - Page 8 ACE PLUS CORP. Notice 1. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C. 2. The transmission length is largely affected by the type of LAN cables, the type of HDMI sources, and the type of HDMI display.
-
Page 9: Limited Warranty
ACE PLUS CORP. Limited Warranty The SELLER warrants the EX-G019 HDMI 1.3 over CAT5 Wall Plate Extender with IR Control Path to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1... -
Page 10: Safety And Notice
ACE PLUS CORP. Safety and Notice The EX-G019 HDMI 1.3 over CAT5 Wall Plate Extender with IR Control Path has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the EX-G019 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
