Mooer SuperRender Owner's Manual page 2

Operation
Basic Using
01 Power On
Plug the cable of AC Adapter (9V, 300mA, center negative) into the
[DC 9V] Jack will turn the device on.
02 Selecting Modes
Press [MODE] button to select effect mode, the corresponding LED
will be lit up to instruct the current mode.
03 Setting Pedal Range
Press [PEDAL RANGE SETTING] button to select pedal setting
status. Choose "Full Raise" to set how much pitch will be bent when
the pedal was completely uplifted; choose "Full Down" to set how
much pitch will be bent when the pedal was completely pressed
down.
Rotate [VALUE/MEMORY] knob to change pitch value (change
detune depth in Detune Mode), the setting range is semitones to
semitones ( ~ in Detune Mode).
Memory
01 Using Memory
Super Bender has 10 memories for storing all parameters. Press
[VALUE/MEMORY] button to switch to Memory state, the memory
number ( ~ ) will appear on the middle display, rotate
[VALUE/MEMORY] knob to change memory.
When in memory state, press [VALUE/MEMORY] button to exit.
02 Storing
Hold [VALUE/MEMORY] button to store a memory, then the memory's
number on the middle display will begin to flash, at that time, rotate
[VALUE/MEMORY] knob to change patch number, when you got the
expectant position, press [VALUE/MEMORY] button again to confirm
the memory storing, the memory's number on the display will stop
flashing.
Pedal Reset
The responsivity of the pedal on Super Bender can be reset as necessary.
If the effect change seems insufficient when pushing the pedal down, or if
the tone changes excessively even when the pedal is only lightly pushed,
or if the factual pitch range is not the same as the setting value, adjust the
pedal as follows:
a. Hold down [TRUE BYPASS] footswitch while power on, the indication
" " will appear on the LED display, and then release the [TRUE
BYPASS] footswitch.
b. Fully raise the pedal then push the pedal fully down and release it.
c. Press [VALUE/MEMORY] button, the indication " " will appear
on the LED display, the Pedal Reset adjustment is complete, and Super
Bender will return to the normal using status. If the indication "
shown, repeat the procedure from step b.
Factory Reset
Factory Reset function will initialize all setting of Super Bender. All the
memories will be erased and overwritten by the presets.
To do the factory reset, conform to the following instructions:
Hold down the [MODE] and [VALUE/MEMORY] button simultaneously
while power on, " " will appear on the display and last flashing.
At that time, press [VALUE/MEMORY] button to confirm, "
be flashing in a faster speed for 2 seconds, then turn to display "
at a steady status for 3 second, then back to the normal state, the factory
reset operation have been done.
Note: If you want to quit Factory Reset halfway, hold [MODE] button for 2
seconds, then the Factory Reset will be canceled.
Specification
No. of Effect Types: 3 (Harmony, Pitch Shift, Detune)
Preset Patch Memory:
10 Memories
Guitar Input:
1/4" monaural jack
Input impedance: 1 M ohms
Output:
1/4" monaural jack
Output impedance: 100 ohms
Power requirements:
AC adapter 9V DC, 300 mA (center minus plug)
Dimensions:
210 mm (D) x 161 mm (W) x 63 mm (H)
Weight: 1360 g
Accessories:
Owner's Manual, AC adapter DC 9V
" is
Troubleshooting
Can not power on
Check power connection.
------ Make sure the power is connected correctly.
Check the adapter.
------ Make sure the adapter is the one supplied with the unit.
No sound or low volume
Check connection of cables.
------ Make sure all the cables are connected firmly.
" will
Check the volume of guitar and amplifier.
"
------ Make sure each equipment's volume is set to an appropriate level.
High noise
Check the adapter.
------ Make sure the adapter is the one supplied with the unit.
Check the cables.
------ Make sure the cables are connected firmly and have no quality
problem.
Connection
01 Basic Connection
02 Connecting OverDrive or Distortion Effects
If you are using an OverDrive/Distortion pedal, have the device connected
in front of Super Bender.
OverDrive
Distortion
MOOER AUDIO CO.,LTD
www.mooeraudio.com
