GE150 Pro / GE150 Pro Li
Intelligent Multi-Effects
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GE150 Pro and is the answer not in the manual?

Questions and answers

Mick
May 30, 2025

does the ge 150 pro have a count in and or a fade out on the drum machine?

0

Subscribe to Our Youtube Channel

Related Manuals for Mooer GE150 Pro

Summary of Contents for Mooer GE150 Pro

  • Page 1 GE150 Pro / GE150 Pro Li Intelligent Multi-Effects Owner’s Manual...

  • Page 2: Table Of Contents

    Looper..............................14 OTG Function ............................. 15 SYSTEM SETTINGS ..........................15 INPUT LEVEL ............................15 SCREEN .............................. 16 CAB SIM TRHU ........................... 16 OTG LEVEL ............................16 LANGUAGE ............................16 RESET ..............................16 BATTERY ..............................17 GE150 PRO SOFTWARE ......................... 18...
  • Page 3 Software window ..........................18 IR file import ............................19 Data backup ............................19 TROUBLESHOOTING ..........................20 SPECIFICATIONS ............................. 21 ANNEX 1: EFFECT MODULE DESCRIPTIONS ................... 22 FX miscellaneous modules ........................ 22 DS overdrive / distortion modules ....................22 AMPplifier modules ........................... 22 CABinet modules ..........................

  • Page 4: Precautions

    Connections Always turn off / disconnect the power to the GE150 Pro and any other equipment before connecting or disconnecting signal cables. This will help prevent malfunctions and / or damage to other devices. Also make sure to disconnect all connection cables and the power supply before moving the device.

  • Page 5: Features

     New member of MOOER GE series, using the new design language  Choice between GE150 Pro (traditional version with power adaptor) and GE150 Pro Li (version with integrated Lithium-Ion battery)  55 realistically sampled amp simulations using intelligent inverse modeling technology to recreate the sound of real amplifiers ...
  • Page 6 8. SAVE button: Press to save your settings in a Preset. 9. EXP button: Press to open the menu for expression pedal settings. If this button is lit, the on-board EXP pedal works as an expression pedal to control module parameters.

  • Page 7: Connections

    Connection to a mobile phone or a recording device for OTG audio playback and recording (see Function, see GE150 PRO SOFTWARE). 6. Power switch: Use this switch to turn the device ON / OFF 9 VDC power input: Connect the supplied power supply adaptor.

  • Page 8: Connection To A Guitar Power Amplifier And Cabinet

    This connection scenario includes a guitar amplifier with FX LOOP or a pure power amp. It is recommended to activate the AMP module when you establish connections using this application scenario. All preamp functions will be performed by the GE150 PRO in this case. 1. Connect an instrument.

  • Page 9: Connection To A Guitar Amplifier

    Connection to a guitar amplifier This connection scenario connects the output jack of the GE150 Pro directly to the input of your guitar amplifier. It is recommended to deactivate AMP and CAB modules to avoid unwanted interference with the sound characteristics of the physical amplifier and cabinet.

  • Page 10: Preset Selection

    The GE150 Pro is turned off by switching the Power switch on the back to "0". Note for the GE150 Pro Li: If the power cable is still connected after shutdown, the screen will show a graphic to indicate the battery charging status.

  • Page 11: Operation

    Effect module selection and switching The GE150 Pro has 9 built-in effect modules, including a total of 151 effect types, and supports the simultaneous use of all 9 effect modules. Each module can be configured to use one effect type.

  • Page 12: Saving Presets

     Press SELECT to confirm the setting and return to parameter selection. ANNEX 1: EFFECT MODULE DESCRIPTIONS for a list of available effect types. Note: All changes must be stored in the Preset using the SAVE button, before you switch presets. Otherwise your changes will be lost.

  • Page 13: Tap Tempo

    Expression Pedal The GE150 Pro is equipped with an on-board rocker pedal. It can be used as an Expression pedal to control one parameter of one of the modules or it can be used as a master Volume pedal.

  • Page 14: Exp Pedal As Wah Pedal (Mapping Example)

    Calibration You need to calibrate the GE150 Pro's expression pedal before you use it for the first time or if you experience erratic pedal function. The calibration is global and does not have to be repeated for each preset.

  • Page 15: Exp Pedal As Volume Pedal

    2. Volume pedal at the end of the effect chain (Master volume) This method is used to control the overall output volume of the GE150 Pro. The EXP pedal must be in Volume Mode for this to work and the EXP VOL function must be activated in the EXP menu.

  • Page 16: Tuner

    You can exit the TUNER mode by pressing any footswitch or button (except TAP). Drum Machine The GE150 Pro is equipped with a Drum Machine function providing a choice between drum rhythm patterns or metronome clicks. Press the RHYTHM button to start the DRUM Machine and open the RHYTHM menu.

  • Page 17: Looper

    Adjust the volume level of drum machine playback. Looper The GE150 Pro is equipped with a stereo phrase Looper function providing a recording time of up to 80 seconds. Press and hold footswitches C+D simultaneously to open the Looper menu.

  • Page 18: Otg Function

    Looper mode can be stopped any time by pressing the RHYTHM button. OTG Function The USB-C port on the GE150 Pro can be used to connect a mobile phone or tablet for OTG (On-The- Go) functions to for audio recording and playback.

  • Page 19: Screen

    OTG LEVEL Adjusts the output volume level of the OTG function of the USB port. LANGUAGE The GE150 Pro supports menus in Chinese and in English. RESET Select RESET to restore your GE150 Pro to factory settings. Use SELECT to confirm (YES) or cancel (NO).

  • Page 20: Battery

    BATTERY The GE150 Pro Li is a version of the GE150 Pro with built-in lithium battery. Battery power information is displayed at the top right of the main view when the device is on. The battery level is indicated in five levels: 20 % / 40 % / 60 % / 80 % / 100 %.

  • Page 21: Ge150 Pro Software

    2. Preset list This area shows all the presets stored in your GE150 Pro. You can select and activate a preset by clicking on it. You can also use the right mouse button to copy, paste, clear and rename a selected...

  • Page 22: Ir File Import

    Click on the "+" icon and a Windows Explorer prompt will be opened. Find your stored IR file and click "Open". Your file will be imported into your GE150 Pro and can now be used in the CAB module in your presets.

  • Page 23: Troubleshooting

     Ensure that the original power adapter is connected.  GE150 Pro Li (battery-powered version): Make sure the battery still has sufficient charge to meet the power demands during boot-up. Connect the original adapter before trying to start the device.

  • Page 24: Specifications

    0 - 60°C Dimensions 310 mm × 153 mm × 55 mm (LxWxH) Weight GE150 Pro: 1.1 kg (2.4 lb) / GE150Pro Li: 1.2 kg (2.6 lb) Accessories Power adapter, USB cable, Quick guide Disclaimer: Parameter updates will not be notified separately.

  • Page 25: Annex 1: Effect Module Descriptions

    Modeled after a modern 535Q Auto Wah Automatic sweeping Wah Talk Wah Ah Talking Wah algorithm from the MOOER® Red Kid with "AH" vocal effect Talk Wah Oh Talking Wah algorithm from the MOOER® Red Kid with "OH" vocal effect Touch Wah...
  • Page 26 PLX 100 Based on Marshall® Plexi 100 E650 CL Based on ENGL® E650 Clean Setting E650 DS Based on Engl® E650 Distortion Setting Powerbell CL Based on ENGL® Powerball E645 Clean Setting Powerbell DS Based on ENGL® Powerball E645 Distortion Setting Blacknight CL Based on ENGL®...

  • Page 27: Cabinet Modules

    Effect Description Model name Description Noise Killer Hard noise gate based on the Mooer® Micro Noise Killer. The effect solves noise issues quickly and efficiently with simple threshold adjustments. Intel Reducer Unlike conventional noise gates, this works by separating the conventional signal from the white noise in the signal and eliminating the white noise to achieve noise reduction while maintaining natural decay.

  • Page 28: Eq Modules

    3-band EQ with adjustable frequency bands. MODulation modules Effect Description Model name Description Phaser Based on the MOOER® Ninety Orange, standard sine waves Step Phaser Square wave phase shifter Fat Phaser Low frequency phase shifter Flanger Based on the MOOER® E-Lady, square wave effect Jet Flanger Based on the MOOER®...

  • Page 29: Reverb Modules

    REVERB modules Effect Description Model name Description Room Small room reverb Hall Concert hall reverb with rich diffusion and long decay times Church Reverb simulating large space with long decay times Plate Bright metal plate reverb Spring Vintage spring reverb Reverb with added chorus effect, adding more detail Cave Reverb reproducing the diffuse reflection of irregular surfaces in a cave...
