15.1 Part Identification
The key number in diagram 15.1 and the first column of the list
will help identify the spare part.
15.2 Ordering
When ordering any spare part, please quote the part number
and the description from the list together with the model name
and serial number information from the data label.
The data label is positioned on the inner case front, see diagram
8.2 Installation Instructions.
Key No. Part No.
1 457412
2 205765
3 203433
4 202627
5 203518
6 202435
7 801183
8 202529
9 202712
10 204546
11 227066
12 202810
13 801169
14 227003
15 227002
16 202226
17 202240
18 227071
19 227083
20 457068
21 227004
22 800153

15 Spare Parts

Description
Fan assembly
Main injector assembly
Pilot burner
Spark electrode
Pilot injector
Thermocouple
Boiler overheat cutoff assembly
Domestic hot water limit control
Piezo unit
Pressure gauge assembly
Control board (inc 16,17)
Transformer
Gas Control valve assembly
Thermistor Domestic Hot Water
Flow Sensor
Fuse 2 type T2A x 20mm
Fuse 1 type 3.15ATx 20mm
Air Pressure switch
Fan Resistor
Low Water Pressure Switch
Thermistor Central Heating
Automatic Air Vent (inc seal)
43
G.C. No.
E26742
E26741
379485
278131
381656
378204
E27356
*****
E26688
E26683
*****
E26700
E26726
*****
E04063
278136
278414
E26891
*****
E26723
E26743
313285
221680G
