Setting L E D
Item state
Ring volume 3-rx
Speaker volume 4-Lx
Microphone
5-tx
volume
Numbers of door
6-0x
station
Numbers of
7-xx
indoor monitor
Keypad sensitivity 8-sx
Slave adress
9-dx
setting for monitor
Restore to default
9-FS
setting
4. Specification
● Power Supply:
● Power Consumption:
● 7 segment LED:
● Wiring:
● Dimension:
The design and specifi cations can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
Description
Set volume for call tone,rang from 0~9.
Set volume for speaker,adjust the voice from
outdoor,rang from 0~9.
Set volume for microphone,adjust the voice from
user,rang from 0~9.
Maximum 4 door stations can be selected,this
item is used to set the numbers of door station
that can be surveilled by indoor monitor.refer to
part 2 ->Entrance Monitoring.
Maximum 32 indoor monitors can be selected,this
item is used to set the numbers of indoor monitor
that can be selected to intercom.refer to part 2
->Intercom call.
Rang from 0~2,The larger you set the value,the
stronger it will be,"0"-slow,"1"-normal,"2"-fast.
Rang from 0~3,"0"-master monitor,"1~3"-slave
monitor.
The restore to default function allows the user to
recover the settings to factory setting.Select "9-
FS" item on LED,then press Up button,"YES"will
be asked,press Up button again to restore the
settings to default.
DC24V
standby 20mA,working 70mA
4 digits dynamic
2 wires, non-polarity
187(H)X97(W)X33(D)mm
Default
6
6
6
1
04
1
0
-
