Braeburn 3100 Owner's Manual

Braeburn 3100 Owner's Manual

Premier series non-programmable 2heat / 2cool & heat / cool digital thermostat
Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
3100
OWNERS MANUAL
Compatible with low voltage multi-stage
heat / cool systems with up to two stages of
heating and two stages of cooling.
READ ALL INSTRUCTIONS BEFORE PROCEEDING
YEAR
LIMITED
WARRANTY
Store this
booklet for
future reference
© 2004 Braeburn Systems LLC All Rights Reserved.
Premier Series
Non-Programmable
2 Heat / 2 Cool & Heat / Cool
Digital Thermostat
Pub. No. 3100-100-002
CONTENTS
FEATURES
1
2
SPECIFICATIONS
3
INSTALLATION
Replacing Existing Thermostat
3.1
Installing Your New Thermostat
3.2
4
TESTING YOUR NEW THERMOSTAT
PROGRAMMING
5
Default Thermostat Settings
5.1
Setting Temperature Differential and Residual
5.2
Cooling Fan Feature
Setting First Stage Differential
5.2.1
Setting Second Stage Differential
5.2.2
Setting Residual Cooling Fan Feature
5.2.3
6
ADDITIONAL OPERATION FEATURES
Review Set Temperature
6.1
Changing Set Temperature
6.2
Compressor Protection
6.3
High Temperature Safety Switch
6.4
Changing Fahrenheit (˚F) to Celsius (˚C)
6.5
Resetting Thermostat
6.6
LED Status Indicator
6.7
TROUBLESHOOTING
7
8
WIRING DIAGRAMS
WARNING!
Important Safety Information
• Always turn off power to the air conditioning or heating system prior to installing,
removing, cleaning or servicing thermostat.
• Read this manual thoroughly prior to installing, programming or operating this
thermostat.
• This thermostat is designed for use with a 24 Volt-AC low voltage multi-stage
heat / cool system.
• Do not use this thermostat on systems with voltages higher than 30 Volt-AC.
• This thermostat requires 24 Volt AC power for normal operation and control of the
heating or cooling system.
• In the event of an AC power outage, the first and second stage temperature
differentials, residual cooling fan feature and the setpoint will return to their
default system values. The user can change the default settings once power is
restored.
• Wiring must conform to all building codes and ordinances as required by local and
national code authorities having jurisdiction.
• Do not short (or jumper) across terminals on the gas valve or at the heating or
cooling system control board to test the thermostat installation. This could
damage the thermostat and void the warranty.
• Do not select COOL mode of operation if the outside temperature is below 50( F
(10( C). This could possibly damage the controlled cooling system and may cause
personal injury.
• This thermostat should only be used as described in this manual. Any other use is
not recommended and will void the warranty.
1
