Transferring and Deleting Data
There are three different codes to transfer and delete data in memory.
•
Transfer All Data in Memory - This will send all data in memory every time the barcode is scanned.
•
Transfer Only Unsent Data in Memory - This will send only the data in memory that hasn't already been sent when the barcode
is scanned (only in batch modes).
•
Delete Scanned Data from Memory - Scanning this barcode will erase all data in the reader's memory.
Batch Mode Disable - Default Reboot
Batch Mode Disable - Transfer Only
Unsent Data in Memory
16.0 - Batch Mode Indicators
When the CR3600 is in batch/storage mode, a storage icon will appear to indicate the range of storage space that has been used.
17.0 - Attaching the CodeXML® M3 Modem
1. Attach the 8-pin DIN end of the USB or RS232 cable provided to the CodeXML® M3 Modem (Figure 32).
USB Cable
RS232 Cable
2. Plug the USB connector into the USB port on the computer, or RS232 (Serial) cable to a serial port on the computer. Once plugged
in, the modem's blue LED light will flash (Figure 32).
USB Cable
D013597_02_CR3600_User_Manual
Batch Mode Enable - Log Only
Batch Mode Disable - Transfer
All Data in Memory
Figure 32
RS232 Cable
Batch Mode Enable - Send and Log
USB Keyboard Mode
(Batch Mode Only)
9
