Specifications - Tevion DIGITAL MINI SATELLITE SYSTEM User Manual

Specifications

Receiver
Dimensions in mm (W × D × H)
Weight in grammes
Input frequency range
IF band width
LNB power
LNB control
DiSEqC control
Symbol rate
Input speed
Error correction (FEC)
Aspect ratio
Video resolution
Audio mode
Connection options
LNB IF input
TV SCART (output only)
VCR SCART (output and input)
RCA (CINCH)
SPDIF, COAXIAL
Helpline No. UK/Northern Ireland 01422 263270 Helpline No. UK/Northern Ireland 01422 263270
210 × 145 × 45
Receiver 553 g
Remote control 80 g (without batteries)
950 MHz ~ 2'150 MHz
55 MHz / 8 MHz (below 5MS/s)
13V/18V GS, 0.30 A max.
overload protection
22 kHz ± 2 kHz, 0.6 V pp ± 0.2 V
Version 1.0, Version 1.2, tone burst A/B
1 ~ 35 MS/s
Max. 15 Mbit/s
1/2, 2/3, 3/4, 5/6, 7/8, auto
4:3 letterbox, 4:3 PanScan, 16:9
720 x 576 (Pal), 720 x 480 (NTSC)
Left, right, stereo, AC3 digital sound
Type F, IEC 169-24
Video CVBS, Audio L, R
Video CVBS, Audio L, R
Audio L,R
Digital audio output
