Step 4b: Insert the LNB bracket in direction of the arrow as far as
Step 5:
For dismantling the antenna carry out step 1 - 5 in reverse
order.
20
Helpline No. UK/Northern Ireland 01422 263270
it will go into the LNB arm until the LNB bracket is
locked. While you are doing this, press the clip with the
button for installation slightly down.
Now, the antenna is completely installed. Fix the
antenna cable at the LNB. The installation of the
antenna cable is described in the section "LNB cable
installation" on page 31.
Press button
to remove.
