Connection with the Cinch cable

Connect the Cinch connectors of the Cinch cable to the "AUDIO
R" and "AUDIO L" sockets of the receiver if you want to connect a
stereo system.
Caution!
Never connect the Phono input of your stereo system to the
receiver; it may damage your stereo system.
Strictly follow the instructions for connecting the Cinch cable given
in the operating manual of your stereo system.
The Cinch cable is not included in the product contents.

Connection of an audio-digital receiver

If you want to use 5-channel audio transmission (Dolby digital
sound/AC3), you must connect your audio-digital receiver to the
coaxial output of the receiver.
Caution!
Please follow strictly the information regarding connection in the
operating manual of your audio-digital receiver.
Your TV set need not be switched on for radio reception.
