5 Create
By pressing the 5 key, the create menu will be displayed. Here, a
new channel can be created.
Option
Satellite
TP Index
TP Frequency
Symbol Rate
Polarity
Name
Video PID
Audio PID
PCR PID
Helpline No. UK/Northern Ireland 01422 263270 Helpline No. UK/Northern Ireland 01422 263270
Description
Satellite selection
(example: Astra1 19° East)
Selection of the created transponder on the selected
satellite.
Data corresponding to the selection of the created
transponder.
Data corresponding to the selection of the created
transponder.
Data corresponding to the selection of the created
transponder.
Determination of the channel name.
By pressing the OK key, an editing mask will be
displayed. By pressing the keys CH , CH , V- and V+,
the curser can be moved over the keyboard. The
selected field is marked yellow. To select it press the OK
key. The cursor jumps to the next place.
Select the symbol group with the keys 1, 2 and 3 of the
remote control.
For deleting a symbol mark the "DEL" field and press the
OK key.
Select the "OK" field as soon as the channel name is
complete and press the OK key to confirm. The changed
channel name will be accepted.
If you want to exit the keyboard without any change,
press the EXIT key or markt the "Cancel" field and press
the OK key to confirm.
Video PID input with the 0-9 keys of the remote control
Audio PID input with the 0-9 keys of the remote control
PCR PID input with the 0-9 keys of the remote control
