- Page 1 NETCOM POE REMOTE POWER SUPPLY ETHERNET SWITCH USER'S MANUAL NETCOM POE Switch User’s Manual...
-
Page 2: Related Manuals
PREFACE Version directions: This manual corresponds to NETCOM POE series versionV1.1. NETCOM PSE NETCOM POE Series 1. NETCOM POE01 2 .NETCOM POE04 3. NETCOM POE08 Target reader The reader of this manual is NETCOM POE series users Related Manuals This manual explores "Installation Manual" of NETCOM POE series... -
Page 3: Table Of Contents
CONTENTS Chapter 1 System Overview.................. 4 1.1 Features and functions ................4 1.2 Technical features and Specifications ............6 Chapter 2 Electrical connection and structure............9 2.1 The structure and outline picture of NETCOM POE8 ......9 2.2 Display and control panel ..............12 Chapter 3 installation and debugging .............. -
Page 4: Chapter 1 System Overview
Chapter 1 System Overview Content Features and functions Operating environment Technical features and parameters This chapter describes features and functions of NETCOM POE series 1.1 Features and functions NETCOM POE which is designed specifically for Telecom carrier . The device implemented advanced MCU control technology. Total power, individual port power, port status and device temperature are displayed on LCD real time. - Page 5 9. Extend the cable transmit distance, furthest to 300m. ( only for 4 port POE) 10. Effective short circuit, overload and total power protection 11. Each port with indicator light, alarm light, device alarm light 12. Metal case, with wall mounting hole...
-
Page 6: Technical Features And Specifications
1.2 Technical features and Specifications Technology Specifications IEEE 802.3 10Base-T Ethernet IEEE standard IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3x Flow Control and Back Pressure IEEE 802.3af Power Over Ethernet IEEE 802.3at Power Over Ethernet Back-plane( switch ):1.0Gbps switching structure Transfer Rate: 14,880pps for Ethernet port 148,800pps for Fast Ethernet port... - Page 7 200m （only for POE04 switch ) Cable extend distance Support A B mode POE PINs Positive (VCC+)：RJ-45 pin 1，2，4，5 Negative (VCC-)：RJ-45 pin 3，6，7，8 Data (1，2，3，6) CSMA/CD Protocols External Power Adaptor (POE04) Power supply (100V-240V AC 50Hz-60Hz， DC48V/ 2.5A) Internal power adaptor (POE08) (200V-240V AC 2A 50Hz-60Hz) Implemented Overcurrent protection...
- Page 8 Dimensions and weight： NETCOM POE01 NETCOM POE04 NETCOM POE08 58mm 155.6mm 270mm Width 38mm 26mm 44mm Height 120mm 71.4mm 170mm Depth Weight <0.3kg <0.5kg <3kg NETCOM POE series protect function： Range of output over-voltage protection：52VDC Over current protection (single channel)：750mA Over voltage protection：Input voltage is over 260VAC...
-
Page 9: Chapter2 Electrical Connection And Structure
Chapter2 Electrical connection and structure Contents The structure and outline picture of NETCOM POE Display and control panel Main content: Introduce the structure and the connection way of NETCOM POE8 2.1 The structure and outline picture NETCOM POE08 NETCOM POE04 NETCOM PSE01... - Page 10 Ethernet port lights instructions： POE04 LED Description Indicator Light Color State Indicator Light signification Power Green normal power supply for device No power supply for the device The device with problem of any Alarm Flashing port or power overload Normal status Link/Act(Uplink) Green Port is connected...
- Page 11 Indicator Color State Indicator Light signification Light normal power supply for device Power Green No power supply for the device The device with problem of any port or Flashing power overload Alarm Device output port without problem Port is connected Link(Uplink) Green Device Port in the transmission or...
-
Page 12: Display And Control Panel
2.2 Display and control panel(POE08 only) The “SELECT” key: Choose a port of display The “RESET” key: Reset the entire device or the selected port Ordinary POE devices do not display how much the total power and the individual port power it used, load the equipment also can not be understand; When a port is overloaded or short circuit, you can not turn off the power output port, there are some security risks;... - Page 13 In main frame screen state, press the SELECT key, display selected port, and press the “SELECT” key continuously to choose other ports. When Channel works normally, display the power value Channel is abnormal, show-related malfunction Channel overload display "Overload" Channel short circuit: Display "fail” (4) Reset a port When a channel occurs malfunction, the device will try to return to normal working condition itself twice, if after two attempts it can not return to normal,...
- Page 14 ⑸fan start and stop The device has a monitoring temperature features, when the temperature exceeds 42 ℃, the fan start, it can help the device cool down, the fan sign are displayed on LCD When the temperature dropped below 38 ℃, the fan stop working and the fan sign is off on LCD.
-
Page 15: Chapter 3 Installation And Debugging
Chapter 3 installation and debugging Content open-case inspection installation start test Main content: Introduce common operations of installation and debugging of NETCOM POE series 3.1 Open case inspection Check the attachment whether complete, it contains: 1. POE device A user’s manual An input power cable 48V Power adaptor(POE04 only) -
Page 16: Start Test
1：The POE device must be placed far away from the heat source, source of electromagnetic interference, corrosive gases and metal dirt. 2：Do not block the cooling hole of the device. 3: Installation must be placed smoothly, without strenuous vibration. ... -
Page 17: Chapter 4 Routine Maintenance
Chapter 4 Routine maintenance Content Routine maintenance Main content: Introduce NETCOM POE series routine maintenance and operation. 4.1Routine maintenance NETCOM PSE series can operate successively; it guarantees the reliability for the power supply. To do routine maintenance is necessary, and makes the power system in the best state during the operating. (1) Clean the power source regular, prevent the dust accumulation (2) Check the connection of input and output line whether loose or poor contact, if damaged, please change in time. -
Page 18: Chapter 5 Transport And Storage
Chapter 5 Transport and storage Content Transport Storage Main content: NETCOM POE series transport and the storage that need attention 5.1 Transport NETCOM PSE series should be put gently in transit, or prevent it to severe shock. .It should be placed strictly accordance with the box direction, if violated may result in malfunction and damage.
