Assembly - Exerpeutic Inversion Table Owner's Manual

Step 1:
Stand up the base of the machine by separating the frames as shown above.
Pull the Rear/Front Frames (8, 9) as far apart as possible from each others and
align the pin holes. Then insert the Ø8x63.5mm Ring Pin (26) from inner side
into the holes on the Rear/Front Frames (8, 9) to lock the frames in place.
Hardware:
(26) Ring Pin Ø8x63.5mm
1 PC
The product weighs more than 44 lbs and should
be assembled and moved by two or more people.

ASSEMBLY

8
