For safe operation
Danger of overheating
Operate at ambient temperature of 5℃~
40℃.
Operating at a temperature range other
than that designated can cause accident,
Use at
failure or bodily injury such as burns due to
designated
overheating.
temperature
Danger of dust
Be sure site is free from dust.
Sucking in of dust can cause failure.
Avo i d d u s t
Danger of overheating
Install where equipment is not exposed to
direct sunlight.
Vacuum pump exposed to direct sunlight
can overheat, resulting in failure.
Avo i d d i r e c t
s u n l i g h t
Danger of problem recurrence
and failure
If protective device or thermal protector
activates, be sure to turn off electric
source and inspect causes to solve the
Inspect cause of
problem. Do not operate until problem is
solved. Operation while problem is left
problem
unsolved can cause problem recurrence
and failure.
Danger of foreign matter entering
inlet
When checking turning direction, be
careful not to enter foreign matter into an
Prevent foreign
inlet. Foreign matter entering inlet can
cause failure.
matter from
entering
Danger of vacuum break and
pollution
Be sure to close isolation valve between
vacuum pump and vacuum system
(chamber) during startup and stop.
Start-up or stop with isolation valve in the
Start or stop
open position can draw back gas and
after closing
debris attached to inside of pump to
isolation valve
vacuum chamber due to pressure
differential, resulting in vacuum break and
pollution on vacuum chamber side.
CAUTION
Danger of overheating
Install in a well-ventilated area. Poor ventilation
can disrupt cooling and cause accident, failure or
bodily injury such as burns since this vacuum
pump is an air-cooled type.
P a y a t t e n t i o n
t o
ve n t i l a t i o n
Danger of unbalance
Be sure to install on solid and level floor (less than
5° inclination).
Uneven installation can cause failure and
movement of vacuum pump. If installation floor is
I n s t a l l o n a
unstable, fix pump base with 4-φ11 holes of pump
s o l i d , l e ve l
leg (ISP-250C) or 4-M10 tap section pump base
(ISP-500C).
f l o o r
Motor burnout
Before doing any wiring, check electric source and
voltage. Single-phase is a multi voltage type of
AC100V/AC200V. Three-phase is a multi voltage
type of AC200V/AC400V. Voltage can be changed
at terminal block. This pump is wired to 200V
when delivered to you. Check your electric source,
Check voltage
voltage, and wire correctly to terminal block.
Improper wiring and incorrect voltage can cause
motor burnout.
Danger of exhaust disruption
Remove blank flange from inlet and outlet.
Operation with blank flange being fitted can disrupt
exhaust or cause blank flange to fly by exhaust
impetus, resulting in accident, failure, or bodily
injury from contact with flying objects.
Remove blank
flange
Danger of exhaust disruption
When connecting exhaust piping to vacuum pump
and when combining piping with another vacuum
pump, pay attention to piping size and length so
that it does not cause exhaust resistance. Exhaust
Pay attention to
resistance can disrupt air flow, resulting in failure
exhaust
and over-current.
resistance
Danger of abnormal sound and failure
Open inlet to atmosphere for about 5 seconds
before restarting vacuum pump.
If not, it can unbalance temperature inside vacuum
pump, resulting in failure.
Op e n a i r
i n l e t
-4-
