- Page 1 USER’S INSTRUCTION MANUAL • Multi Spray Pumps iCon-M433N | iCon-M333N iCon PUMPS • Airless Pumps MIDDLE - HIGH Pressure Range iCon-A433N | iCon-A333N...
-
Page 2: Safety Warning
Be sure to observe warnings and cautions in this instruction manual. If not, it can cause paint ejection and serious bodily injury by drawing organic solvent. ANEST IWATA ICON Pump Unit complies to ATEX regulations 2014/34/EU; Protection level: II 2G T6 • Protection level: II 2G T6 •... -
Page 3: Other Precautions
IF SOMETHING GOES WRONG, IMMEDIATELY STOP OPERATION AND FIND THE CAUSE. Do not use again until you have solved the problem. NEVER USE SPARE PARTS THAT ARE NOT ANEST IWATA ORIGINALS. WARNING BURST OF FLUID HOSE NEVER USE CRACKED, DAMAGED, BENT OR CRUSHED FLUID HOSE. - Page 4 Airless and Multi Spray iCon Pumps VERSIONS MULTI SPRAY PUMPS AIRL AIRLESS UNITS ESS UNITS ICON - M333N ICON - M433N ICON - A333N ICON - A433N 4. PRODUCT IDENTIFICATION PLATE DATA: The manufacturer’s identification plate is applied on Multi Spray and Airless Units (see picture below). It must not be removed at all, even if the equipment is resold.
-
Page 5: Technical Specifications
Airless and Multi Spray iCon Pumps 6. TECHNICAL SPECIFICATIONS VERSIONS ICON-M333N / ICON-A333N ICON-M433N / ICON-A433N Plunger Pump: PP-3260N PP-3688N Air Motor cylinder diameter: 125 mm 160 mm Weight: 40 Kg 46.5 Kg Dimensions (LxWxH): 496 x 627 x 1164 mm... -
Page 6: Configuration Of Equipment
Airless and Multi Spray iCon Pumps 7.1 INSTALLATION SCHEME OF ICON-M433N & ICON-M333N Place the equipment, on a horizontal surface floor. Secure it firmly to the floor surface by means of the cart's fastening bracket (N). (2 holes - ø 9) Firmly connect the suction hose set (E) to the paint inlet joint and the recirculation pipe (F) to the drain valve (D). -
Page 7: Safety Informations
PRESSURE INSIDE THE PUMP WILL BE RELEASED. 9. WORKABLE PRODUCTS ANEST IWATA ICON PUMPS ARE CONCEIVED TO PAINT FERROUS MATERIAL IN GENERAL, WOOD AND PLASTIC. TO USE THE EQUIPMENT WITH SPECIAL PRODUCTS ASK FOR THE APPROVAL OF THE MANUFACTURER. DO NOT USE:... - Page 8 Set the pressure regulator up slowly, to the minimum pressure required for the After flushing, drain the dirty liquid by straight and alternate movement of the pump. the drain hose. ICON-M333N / ICON-M433N ICON-A333N / ICON-A433N Flow out the cleaning liquid from Close the drain valve.
- Page 9 Turn gradually the pressure regulator, adjust air pressure to a value slightly higher recirculation hose , then close the than 2,0 bar, to enable the pump to release the air. drain valve. ICON-M333N / ICON-M433N ICON-A333N / ICON-A433N CLOSE Adjust the air pressure regulator, to Adjust the air pressure regulator, to the collect FLUID WORKING PRESSURE.
-
Page 10: Ordinary Maintenance
16.0MPa (160bar - 2.320psi) ICON-A333N 0.7MPa (7bar - 100psi) 22.4MPa (224bar - 3.248psi) 0.3MPa (3bar - 43.5psi) 10.8MPa (108bar - 1.566psi) ICON-M433N 36:1 0.5MPa (5bar - 72.5psi) 18.0MPa (180bar - 2.610psi) ICON-A433N 0.7MPa (7bar - 100psi) 25.2MPa (252bar - 3.654psi) 11. -
Page 11: Exploded Views And Spare Parts List
Airless and Multi Spray iCon Pumps 12. EXPLODED VIEWS AND SPARE PARTS LIST 12.1 AIRLESS MULTI SPRAY CONFIGURATION REF. CODE DESCRIPTION M433N M333N A433N A333N 04445670 CART SET 04445810 CART SET 14050130 PLUNGER PUMP SET PP-3688N 14050140 PLUNGER PUMP SET PP-3260N 1457000000 PAINT DELIVERY FILTER SET... - Page 12 Airless and Multi Spray iCon Pumps 12.2 WHEEL CART SET Code: 04445670 for ICON-M433N - ICON-M333N and Code: 04445810 for ICON-A433N - ICON-A333N REF. CODE DESCRIPTION M433N M333N A433N A333N 94445680 CART FRAME 04444730 HANDLE FRAME 04445720 WHEEL WASHER WHEELS (2 pcs.)+WASHERS (2 pcs.)
-
Page 13: Air Regulator Set
Airless and Multi Spray iCon Pumps 12.3 AIR REGULATOR SET Code: 94445740 for ICON-M433N | ICON-M333N REF. CODE DESCRIPTION M433N M333N 04444640 PANEL 04444800 AIR REGULATOR 04445850 T ADAPTOR 1/2" FMF 04444910 NIPPLE 1/2" 04444930 ELBOW UNION 1/2" MF 04444860 REDUCER G1/2"- G1/4"... - Page 14 Airless and Multi Spray iCon Pumps 12.5 PLUNGER PUMP SET Code: 14050130 (PP-3688N) for ICON-M433N | ICON-A433N and Code: 14050140 (PP-3260N) for ICON-M333N | ICON-A333N REF. CODE DESCRIPTION ICON-M433N ICON-M333N ICON-A433N ICON-A333N 04946700 AIR MOTOR SET 04946750 AIR MOTOR SET...
- Page 15 Airless and Multi Spray iCon Pumps 12.6 AIR MOTOR SET Code: 04946700 for ICON-M433N | ICON-A433N and Code: 04946750 for ICON-M333N | ICON-A333N...
- Page 16 Airless and Multi Spray iCon Pumps REF. CODE DESCRIPTION M433N M333N A433N A333N 94938600 BOTTOM MODULE 94944860 BOTTOM MODULE 94938620 METAL SET METAL ø 22 x ø 32 x L22 + SEEGER 94944870 METAL SET METAL ø 18 x ø 25 x L25 + SEEGER 94943830 “U”...
- Page 17 Airless and Multi Spray iCon Pumps 12.7 FLUID PUMP SET Code: 04946730 for ICON-M433N and ICON-A433N REF. CODE DESCRIPTION M433N A433N 04001520 SUCTION TUBE WITH FLANGE 04938380 SPRING HOLDER 04938370 UPPER SPRING 04938320 UPPER "V" PACKING MALE ADAPTOR UPPER "V" PACKINGS PE (3 pcs.)
- Page 18 Airless and Multi Spray iCon Pumps 12.9 AIR OPERATING VALVE SET Code: 94946720 for All Versions REF. CODE DESCRIPTION Qty. 94939360 CHANGEOVER MAIN BODY 04939410 SPOOL 94000440 O'RING ø 4 x ø 28 (2 pcs.) 04939370 CHANGEOVER BLOCK 94939380 SEAT PLATE Ref.
- Page 19 Qty. UL1000701 COMPLETE COVER SET 15x1 0040720100 FILTER 50 MESH 00407203 FILTER STOPPER 12.13 SUCTION HOSE SET WITH FILTER 15 MESH Code: 0444750 for ICON-M433N and ICON-A433N CODE DESCRIPTION Qty. 04444750 SUCTION HOSE SET with FILTER 50 MESH 04444760 FILTER 15 MESH...
-
Page 20: Troubleshooting
Airless and Multi Spray iCon Pumps 13. TROUBLESHOOTING Inconvenience Cause Check Solution a) The ball valve is not in the a) Make sure the ball valve a) Adjust the ball valve in the proper proper position. is in the proper position. position. - Page 21 Airless and Multi Spray iCon Pumps Inconvenience Cause Check Solution c) Seats and balls (inside the fluid c) Disassemble the fluid pump and c) Clean them if they are enclosed pump) are dirty or damaged. check the seat and ball conditions. with solidified paint residues.
- Page 22 ANEST IWATA Deutschland GmbH Dubai - UNITED ARAB EMIRATES Leipzig - GERMANY info@anest-iwata-me.com info@anest-iwata.de www.anest-iwataeu.com www.anest-iwata.de ANEST IWATA France S.A. ANEST IWATA Motherson Coating Equipment Ltd. Saint Quentin Fallavier, Lyon - FRANCE Noida - INDIA info@anest-iwata.fr sales@aim.motherson.com www.anest-iwata.fr www.motherson.com/anest-iwata-motherson.html ANEST IWATA U.K. Ltd.
